Summary of Contents for DRAGONFRAME DDMX-512
- Page 1 DDMX-512 DMX Lighting Controller User Guide v1.2 DZED Systems LLC 407 Bryant Circle, Suite B Ojai CA 93023 U.S.A. support@dragonframe.com +1.800.530.9124 Dragonframe DDMX-512 User Guide Pg. 1...
- Page 2 Dragonframe DDMX-512 User Guide Pg. 2...
- Page 3 Interact with external devices using the built-in relay switch, digital input and digital output. Hardware Warranty The DDMX-512 comes with a two year hardware warranty. You can find the warranty on the product page for the DDMX-512, in the Resources section. Dragonframe DDMX-512 User Guide Pg. 3...
- Page 4 GND and lO. CONNECTING THE DDMX-512 TO A RELAY SWITCH The DDMX-512 has an internal relay that can be used for connecting to an external device that needs a switch closure. Connect your external device to the two connectors labeled RELAY.
- Page 5 POWER DDMX-512 is a “high current” USB peripheral, drawing up to 220mA with all outputs active and fully loaded. As such it must be plugged directly into either a computer port or a powered USB hub. Your power source must provide at least 4.5 Volts.
