INSTALLATION MANUAL
LCD display C965
EVLCD-CMS-C965

Advertisement

loading
Need help?

Need help?

Do you have a question about the C965 and is the answer not in the manual?

Questions and answers

Summary of Contents for EVBIKE C965

  • Page 1 INSTALLATION MANUAL LCD display C965 EVLCD-CMS-C965...
  • Page 2 INSTALATION Thank you for purchasing EVBIKE product and we hope that you will become a happy user. Carefully read the entire manual prior to installation and first use! If you find any fact in the manual that would prevent you from using our product, please contact your reseller for further discussion and keep the original packaging.

  • Page 3: Electrical Parameters

    ELECTRICAL PARAMETERS 36V/48V battery supply Rated operating current: 10mA Max operating current : 30mA Off leakage current < 1uA Buzzer tone > 55db ( 20cm) Output current to the controller : 50mA Operating temperature : -18°C ~ +60°C Storage temperature: -30°C ~ +70°C DIMENSION &...
  • Page 4 FEATURES Two-way serial communication, 5-way button, very easy to operate. Speed display: AVG SPEED, MAX SPEED, real time SPEED. Kilometer / Mile: Can be set according to customers’ habits. Smart battery indicator: Provide a reliable battery indicator, it will not fluctuate with the motor on/off.

  • Page 5: Lcd Instruction

    LCD INSTRUCTION: FUNCIONAL DESCRIPTION Power On/Off Press and hold Power button for 1 second can turn on/off the Display. The Display will automatically shut down when there is no operate & ride for 5 minutes. ASSIST operating Short press UP/DOWN button can change the ASSIST level. Top ASSIST level is 9, 0 for neutral. Level quantities can be adjusted according to the customer requirements.
  • Page 6 Speed mode switch Short press LEFT button can change the speed mode, Speed->AVG Speed->MAX Speed. *If there is no operation for 5 seconds, the display will return Speed (Real-Time) display automatically. Mileage mode switch Short press RIGHT button can change the mileage mode, Trip->ODO-> Time. Headlight / backlight On / Off Press and hold UP button for 1 second can turn on/off the headlight/backlight.

  • Page 7: Parameter Settings

    6 km - walk Press and hold DOWN button for 1 seconds can get into 6km walk mode, out of the mode when release the button. Data cleanup Press and hold RIGHT button for 1 seconds can cleanup the several temporary data, the temporary data include AVG Speed / MAX Speed / Trip / Time.
  • Page 8 Kilometer / Mile The location of speed display symbol S7, press UP/DOWN button rotate display the symbol km/h / MPH (Km / Mile). Temperature ℃ /℉ : the location of speed display symbol CF, press UP/DOWN button rotate display the symbol ℃ / ℉. Light sensitive The location of speed display symbol bL0, press UP/DOWN button display symbol 0~5 , 0 indicate automatic headlight/backlight OFF.
  • Page 9 Backlight brightness: The location of speed display symbol bL1, press UP/DOWN button display symbol 1~5 to change the brightness of the backlight. Buzzer On / Off The location of speed display symbol bEP, press UP/DOWN button rotate display symbol 0/1, 0 indicates buzzer off, 1 indicates buzzer on.
  • Page 10 Power display The location of speed display symbol Pod, press UP/DOWN button display symbol 0/1, represent whether to show the power indicate on LCD. Maintain remind The location of speed display symbol nnA(ma), press UP/DOWN button rotate display symbol 0/1, 0 represent maintain reminding off, 1 represent maintain reminding on.
  • Page 11 Password The location of speed display symbol PSd, remind to input passwords, press UP/DOWN buttons to setup password value (0~9), press LEFT/RIGHT buttons to switch the password item, password is 4 digits, the default password is "1919". Press POWER button when password adjustment is completed. Display will return to the Voltage set item if the password is incorrect.
  • Page 12 ERROR CODE DEFINE C965 can give warning when E-bike has error, LCD display error icon and error code in speed position, Error code from 01H~30H, definition see the table below: Importer: PHOYLO LTD, CZ684609501, Enterprise House, Pass Street 2, 0L9 6HZ Oldham,...

  • Page 13: Assembly Instruction

    ASSEMBLY INSTRUCTION Please pay attention to the screw’s torque value, damaged caused by excessive torque is not within the scope of the warranty. There are two installation methods for the clamp, forward or backward, according to user’s demands. Different assembly methods will need different cable length. Clamps suit for 3 size of handlebar diameter, 31.8mm, 25.4mm, 22.2mm, there are different transfer rings for 25.4mm and 22.2mm, transfer ring must assembly in right direction, see the figure below, pay attention to the green arrow position.
  • Page 14 WARNING There is waterproof membrane inside the sound hole. Don’t insert sharp object into the hole, it will causes waterproof failure. Sun exposure may cause high temperature indicate, this is not display’s failure. OUTPUT WIRE INSTRUCTIONS Importer: PHOYLO LTD, CZ684609501, Enterprise House, Pass Street 2, 0L9 6HZ Oldham, Manchester, UK...
