HP StorageWorks Optical 30ux Getting Started

hp
StorageWorks
Optical 30ux
A
E
B
G
Accessories:
A. Power cord (U.S.)
B. Terminator
C. UDO media
D. Driver CD
E. Documentation CD
J
Not Included:
J. LVD SCSI adapter
for host system
Caution: Components can be
damaged by electrostatic discharge.
Make sure you are properly grounded
when touching static-sensitive
components.
Note: The following is an overview
of the installation procedure.
For detailed information, refer to the
setup guide that shipped with this
product.
Getting
Started
C
D
H
F
F. Getting Started poster
G. Setup Guide
H. Warranty information
I. Safety Guide
K
K. LVD SCSI cable
L. Non-U.S. power cord
FRONT VIEW:
A. Disk slot
B. Activity indicator
C. Power indicator
D. Eject tool
access hole
E. Eject button
I
BACK VIEW:
A. SCSI ID switch
B. Power connector
C. On/Off switch
D. SCSI port with
terminator
E. SCSI port with
SCSI cable
L
Note:
Optical 30ux User's Guide for detailed
information regarding these features.
1
Note the
environmental
considerations. Sufficient clearance
is necessary to ensure adequate air circulation.
A
C
A
B
See the HP StorageWorks
Getting Connected
7.5 cm (3 in)
B
D
E
E
D
C
