- Page 1 Hardware Manual Analog input module - R560 2021-01-13 ClimaCheck Sweden AB, Box 46, SE-131 06 Nacka, Sweden Visiting address: Gamla Värmdövägen 6, SE-131 37 Nacka Sweden Tel.: +46 (0)8-50 255 250, Email: info@climacheck.com Web: www.climacheck.com...
-
Page 2: Table Of Contents
Configuration ........................ 4 Change Modbus address .................... 4 Change Analog input mode ..................6 Configuration on PA Pro II ..................6 ClimaCheck Onsite portable version ................. 8 Electrical wiring diagram ....................9 R560 Hardware Manual – 2021-01-13 Page 2 of 9... -
Page 3: Technical Data
1 Technical data This section covers the basic technical data of the R560 unit, see the product sheet for more details. 1.1 Power supply In ClimaCheck onsite systems, the R560 unit is supplied with 24V DC via the serial communication cable connected to the panel. -
Page 4: Configuration
This section explains how to change Modbus address and analog input configuration between 4- 20mA and V/PT input. In most cases the R560 modules will be delivered pre-configured to fit the system, but changes in the setup compared to the order may cause a need for change of these settings. - Page 5 Table 1, Modbus address dip switch R560 Hardware Manual – 2021-01-13 Page 5 of 9...
-
Page 6: Change Analog Input Mode
2.3 Configuration on PA Pro II It is possible to use the R560 with PA Pro II. To configure, the R560 script needs to be uploaded to the PA Pro. Contact ClimaCheck support for more information. With the script in place, follow the... - Page 7 50 Bar pressure transducer with 0-5V output 150 Bar pressure transducer with 0-5V output Resistance, 0-1600 Ω Current, 4-20 mA (check section 2.2) 0-25 mm/s Vibration sensor with 4-20mA output Resistance, 0-5000 Ω R560 Hardware Manual – 2021-01-13 Page 7 of 9...
-
Page 8: Climacheck Onsite Portable Version
3 ClimaCheck Onsite portable version Each portable R560 has 8 tele plug inputs and 4 DIN 5D inputs to be used with the standard PT1000 temperature sensors and pressure transducers. Inputs 3, 4, 7 and 8 are connected to tele plug inputs and inputs 1,2,5 and 6 have both a tele plug and a DIN 5D each to be able to handle both types of sensors, see electrical wiring diagram and Table 4. -
Page 9: Electrical Wiring Diagram
4 Electrical wiring diagram R560 Hardware Manual – 2021-01-13 Page 9 of 9...
