Summary of Contents for Ultrasonic 2400FA
- Page 1 OPERATIONAL & INSTRUCTION MANUAL Model: 2400FA (120v 1Ø) UltraSonic LLC 1200 Ferris Road Amelia, Ohio 45102 Tel: 513-502-9746 Fax: 513-436-1527 info@ultrasonicllc.com www.ultrasonicllc.com SAFETY REQUIREMENTS...
-
Page 2: Safe Operation
UltraSonic LLC for safe and proper procedures. SAFE OPERATION Do not immerse hands or other body parts in the ultrasonic tank. Cleaning agents and contaminants can cause skin irritation and exposure to high intensity ultrasonic energy should be avoided. -
Page 3: Installation And Initial Setup
3” above the low water control switch. Use only UltraSonic LLC approved cleaning agents and be sure you use the proper, recommended concentrations (typically 10% of approved soap per tank volume for general purpose cleaning). - Page 4 Unit is now ready to clean parts, see NORMAL OPERATION procedures. Fill out WARRANTY REGISTRATION form, page 15 (serial # plate located on back panel of unit) and send back to UltraSonic LLC to ensure activation of your warranty.
- Page 5 UltraSonic LLC. Model Ultra 2400FA...
-
Page 6: Control Panel Functions
Machine Power: P. Machine On/Off Power Navigation Functions: 1. Cycle Start – Starts Pre-set Timers for Ultrasonic and Agitation 2. Stop – Stops Ultrasonic and Agitation 3. Heater – Manual Start/Stop (Overrides 7-Day Temperature Timer) 4. Ultrasonic – Manual Start/Stop Ultrasonic Timer 5. -
Page 7: Display Panel
UltraSonic LLC. Model Ultra 2400FA Control Panel Button/Light Functions: • Cycle Start Button: After pressed Starts the UltraSonic and Agitation timers and Will run according to timer settings (Green Lamp), when Finished the Filtration timer will run according to timer Setting (Yellow Lamp), when cycle is complete or in rest (Red Lamp). - Page 8 UltraSonic LLC. Model Ultra 2400FA • Ultrasonic Timer Set: In Menu Press UP Button until Ultrasonic Set press Menu Button until Timer use Up/Down Buttons to set time, press Menu Button to Save. Press UP Button to move to next setting.
-
Page 9: Normal Operation
Do Not Plug in Machine until unit is full of water and cleaning solution, doing so may cause damage to your UltraSonic tank and Void warranty MAINTENANCE Preventative - There is a minimum of preventive maintenance required. The overall environment around the unit needs to be kept clean, dry and dust free. -
Page 10: Equipment Cleaning
O-rings), hand tighten the canister in place to ensure a tight fit, use wrench to snug canister, do not over tighten. NOTE: Consult your UltraSonic LLC representative for recommended schedule for filter and solution changes based on your application. - Page 11 In general, clean large numbers of parts a few at a time using shorter cleaning cycles. Contaminated Solution - As contaminants build up in the solution the ultrasonic performance drops. The cavitation bubbles waste their energy imploding on the contaminants and not on the part surface.
-
Page 12: Electrical Controls
UltraSonic LLC. Model Ultra 2400FA SPECIAL NOTE: PLEASE RETAIN ORIGINAL SHIPPING CRATE Our service tech will help troubleshoot any problem and instruct user on the safe and proper procedures for repairs. SUPPLIES AND SPARE PARTS For ordering supplies, accessories, or spare parts: ... - Page 13 UltraSonic LLC. Model Ultra 2400FA KM 3 Agitation Motor Contactor QF 0 Main Ground Fault Breaker QF 1 Heater Circuit Breaker QF 2 UltraSonic Circuit Breaker QF 3 Agitation Circuit Breaker with overload RECT 1 24v Power Supply Transformer 120v...
- Page 14 UltraSonic LLC. Model Ultra 2400FA...
- Page 15 UltraSonic LLC. Model Ultra 2400FA...
-
Page 16: Warranty Registration
Except as specifically provided herein; UltraSonic LLC grants no other warranty, either expressed or implied. UltraSonic LLC shall in no event be liable for damages of any kind as a result of or relating to the sale or use of the products whether such damages are... - Page 17 I have received a copy of the Operational & Instruction Manual. I am aware that all personnel attempting to operate, maintain, or service the UltraSonic LLC Cleaning Equipment are required to read & understand the Operational & Instruction Manual. Signed _________________________________________ Print Name ________________________________Title _______________________ INSTRUCTIONS: Fill out information, sign, email (info@ultrasonicllc.com)
