Use this product according to this instruction manual. Please keep this instruction manual for future reference.
GENERAL:
AMT Multitone Appliances are UL Listed for Fire Protective Service, General Signaling Service and UL Standard 464 for Audible Signal Appliances. They are
listed for both indoor and outdoor use with the backboxes specified in these instructions. (See Mounting Options A,B,C,D,E,F,G). Cooper Notification's AMT
Appliances are unique multitone alarm appliances with separate input terminals for each sound. They are the ideal choice for Halon Protection Systems and
emergency signaling systems where distinctive multiple alarm conditions are required. Eight groups of three self-prioritized sound outputs are provided with
separate electrically isolated input terminals for each sound (see Table 2 and 4 for sound selections). Sound output can be field set to provide either HIGH (HI)
dBA or STANDARD (STD) dBA sound output level. AMT Multitone Appliances can be field set for either 12VDC or 24VDC operation and are designed for
use with either filtered or unfiltered (full-wave-rectified) input voltage. All inputs are polarized for compatibility with standard reverse supervision of circuit
wiring by Fire Alarm Control Panel (FACP).
NOTE: All CAUTIONS and WARNINGS are identified by the symbol
WARNING: PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE USING THIS PRODUCT. FAILURE TO COMPLY WITH
ANY OF THE FOLLOWING INSTRUCTIONS, CAUTIONS AND WARNINGS COULD RESULT IN IMPROPER APPLICATION,
INSTALLATION AND/OR OPERATION OF THESE PRODUCTS IN AN EMERGENCY SITUATION, WHICH COULD RESULT IN PROPERTY
DAMAGE AND SERIOUS INJURY OR DEATH TO YOU AND/OR OTHERS.
WARNING: THE AMT MULTITONE APPLIANCES MUST BE FIELD SET TO THE DESIRED INPUT VOLTAGE, dBA SOUND OUTPUT
LEVEL AND ALARM TONE BEFORE THEY ARE INSTALLED. THIS IS DONE BY PROPERLY INSERTING A JUMPER PLUG AND
ADJUSTING A FOUR POSITION SWITCH IN ACCORDANCE WITH THESE INSTRUCTIONS. INCORRECT SETTINGS WILL RESULT IN
IMPROPER PERFORMANCE AND MAY DAMAGE THE PRODUCT, WHICH COULD RESULT IN PROPERTY DAMAGE AND SERIOUS
INJURY OR DEATH TO YOU AND/OR OTHERS.
SPECIFICATIONS:
Tone
Bell
1560 Hz Modulated (0.07 Sec. ON/Repeat)
Code 3 Tone
500 Hz (ANSI S3.41 Temporal Pattern)
Vibrating Chime
700Hz (1.0 Sec. Decay/Repeat)
WARNING:
CHECK THE MINIMUM AND MAXIMUM OUTPUT OF THE POWER SUPPLY AND STANDBY BATTERY AND
SUBSTRACT THE VOLTAGE DROP FROM THE CIRCUIT WIRING RESISTANCE TO DETERMINE THE APPLIED VOLTAGE TO THE
SIGNALING APPLIANCE.
WARNING: FOR UL APPLIANCES THESE APPLIANCES WERE TESTED TO THE OPERATING VOLTAGE LIMITS OF 16-33 VOLTS
FOR 24V APPLICATIONS AND 8.0-17.5 VOLTS FOR 12V APPLICATIONS USING FILTERED (DC) OR UNFILTERED FULL-WAVE-
RECTIFIED (FWR). DO NOT APPLY 80% AND 110% OF THESE VOLTAGE VALUES FOR SYSTEM OEPRATION.
WARNING: MAKE SURE THAT THE TOTAL RMS CURRENT REQUIRED BY ALL APPLIANCES THAT ARE CONNECTED TO THE
SYSTEM'S PRIMARY AND SECONDARY POWER SOURCES, NAC CIRCUITS, OR COOPER NOTIFICATIONS POWER SUPPLIES DO NOT
EXCEED THE POWER SOURCES' RATED CAPACITY OR THE CURRENT RATINGS OF ANY FUSES ON THE CIRCUITS TO WHICH
THESE APPLIANCES ARE WIRED. OVERLOADING POWER SOURCES OR EXCEEDING FUSE RATINGS COULD RESULT IN LOSS OF
POWER AND FAILURE TO ALERT OCCUPANTS DURING AN EMERGENCY, WHICH COULD RESULT IN PROPERTY DAMAGE AND
SERIOUS INJURY OR DEATH TO YOU AND/OR OTHERS.
Copyright 2015 Cooper Wheelock Inc., dba Cooper Notification. All rights reserved.
Thank you for using our products.
INSTALLATION INSTRUCTIONS
AMT MULTITONE APPLIANCES
Table 1: dBA Ratings for AMT Multitone Appliance
Tone
Bell
Code 3 Tone
Vibrating Chimes
Table 2: Current Ratings for AMT Multitone Audible Appliances
Tone
Description
AMT-12/24-NYC
. All warnings are printed in bold capital letters.
Rated Reverberant dBA At 10 Feet Per UL 464
At Minimum
Input Voltage
HI
STD
82
75
85
79
79
73
24VDC
HI
STD
0.057
0.026
0.060
0.030
0.041
0.020
At Nominal
Input Voltage
HI
STD
85
79
88
82
82
75
Maximum RMS Current
(AMPS)
24VRMS
12VDC
HI
STD
HI
STD
0.040
0.028
0.117
0.031
0.051
0.031
0.168
0.052
0.044
0.029
0.090
0.028
12VRMS
HI
STD
0.150
0.057
0.216
0.100
0.108
0.042
P83611 J
Sheet 1 of 4
