Equipment Wiring - Comfast CF-WR619AC Quick Installation Manual

1

Equipment wiring

1.1 If you use broadband dial-up Internet access, please connect in
sequence 1, 2, 3, 4 as shown in the figure below; If you use
residential broadband to access the Internet, please connect in the
order of 2, 3, 4 as shown in the figure, and connect the router
The WAN port directly accesses the broadband of the community.
Dial-Up Internet
Internet
●
2
Power
LAN
●
Fiber / Tel
1
RESET
LINE
Modem
Broadband Internet
Ethernet Port
●
2
