RGN 7116L Operating Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Operating Manual
--Stapler 7116L – long nose--
NOTE: Please read and fully understand the instructions in this
manual before operating the pneumatic power tool. Carefully read
through this OPERATOR'S MANUAL to ensure efficient, safe
operation. It is recommended that the Manual be kept readily available
as an important reference when using this tool.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 7116L and is the answer not in the manual?

Questions and answers

Related Manuals for RGN 7116L

Summary of Contents for RGN 7116L

  • Page 1 Operating Manual --Stapler 7116L – long nose-- NOTE: Please read and fully understand the instructions in this manual before operating the pneumatic power tool. Carefully read through this OPERATOR'S MANUAL to ensure efficient, safe operation. It is recommended that the Manual be kept readily available...
  • Page 2 IMPORTANT INFORMATION WARNING: The warnings, cautions and instructions discussed in this instruction manual cannot cover all possible conditions and situations that may occur. It must be understood by the operator that common sense and caution are factors which cannot be built into this product, but must be supplied by the operator. When using the tool, basic safety precautions should always be followed to reduce the risk of personal injury and damage to equipment.
  • Page 3 WARNING: The operating instructions shall draw attention to the following a) Only those fasteners listed in the operating instructions may be used in the fastener driving tools; NOTE: The fastener driving tool and the fasteners listed in the operating instructions must be seen as one unit system in terms of technical safety.

  • Page 4: Safety Information

    SAFETY INFORMATION WARNING: BEFORE USING THE TOOL, READ CAREFULLY AND UNDERSTAND THE FOLLOWING SAFETY INSTRUCTIONS.FAILURE TO FOLLOW WARNING COULD RESULT IN DEATH OR SERIOUS INJURY. 1. WEAR SAFETY GLASSES OR GOGGLES. Danger to the eyes always exists due to the possibility of dust being blown up by the exhausted air or of a fastener flying up due to the improper handling of the tool.
  • Page 5 6. DO NOT USE A WRONG FITTING. The connector on the tool must not hold pressure when air supply is disconnected. If a wrong fitting is used, the tool can remain charged with air after disconnecting and thus will be able to drive a fastener even after the line of air is disconnected, possibly causing injury.
  • Page 6 14. DO NOT DRIVE FASTENERS CLOSE TO THE EDGE AND CORNER OF THE WORK AND THIN MATERIAL The work piece is likely to split and the fastener could fly and hit someone. 15. DO NOT DRIVE FASTENERS ON THE TOP OF OTHER FASTENERS. Driving fasteners of the top of other fasteners may cause deflection fasteners which could cause injury.

  • Page 7: Technical Data

    TECHNICAL DATA Stapler 7116L – long nose Type of tool Dimensions 190 mm X 45 mm X 220 mm Weight (without fasteners) 1.1 kg Actuation mode Single-sequential actuation Magazine capacity 190 Staples Maximum allowable pressure 8 bar (120 psi) Recommended pressure range...

  • Page 8: Maintenance And Inspection

    MAINTENANCE AND INSPECTION Read the section title SAFETY. SERVICE AND REPAIRES All quality tools will eventually require servicing or replacement of parts due to wear from normal use. It is recommended that these operations should be performed by a professional technician.

  • Page 9: General Warranty Conditions

    GENERAL WARRANTY CONDITIONS Warranty will be honored, only if: 1. Clean, dry, regulated compressed air has been used at air pressure not exceeding the maximum indicated on the tool casting; 2. No evidence of abuse, abnormal conditions, accident, neglect, misuse or improper modifications or storage of the product exists;...
  • Page 10 PARTS LIST – 7116L – long nose CODE Description CODE Description 511120 O-RING 2.5X1.8 322700 LOCK PAWL 511100 O-RING 12.2X1.75 421510 COVER 511060 O-RING 15.5X1.75 322660 BACK COVER 511110 O-RING 16.4X1.8 410620 BUMPER 511080 O-RING 16X1.25 110490 BODY 511090 O-RING 8X2.6...
  • Page 11 TOOL SCHEMATIC -7116L – long nose...
  • Page 12 IMPORTER: NOBE ApS Bjødstrupvej 10 DK – 8410 Rønde Denmark Tel: + 45 8615 1913 E-Mail: info@nobe.dk www.nobe.dk / www.rgneurope.com --Stapler 7116L – long nose-- 2016...
