- Page 1 INSTRUCTION MANUAL 20V Cordless Vacuum Cleaner Model # PS76168A Have product questions or need technical support? Please feel free to contact us! Website: www.Amerisuninc.com www.powersmartusa.com Toll free: 1-800-791-9458 M-F 9-5 EST Email: support@amerisuninc.com...
-
Page 3: Table Of Contents
Assembly instruction…………………………………………….………. 10 Operating instruction…………………………………………………..11 Maintenance……………………………………………………...………. 13 Trouble shooting…………………………………………………………. 14 Exploded view…………………………………………………………… 15 Parts list…………………………………………………………………... 16 Warranty…………………………………………………………………. 17 TECHNICAL DATA Cordless Vacuum Cleaner Model # PS76168A Rated voltage: 20 V Vacuum: ≥10Kpa Air flow: 21CFM Noise: ≤ 75db Container capacity: 2.6 Gallons... -
Page 4: Introduction
INTRODUCTION ® Thank You for Purchasing a PowerSmart Product. This manual provides information regarding the safe operation and maintenance of this product. Every effort has been made to ensure the accuracy of the ® information in this manual. PowerSmart reserves the right to change this product and specifications at any time without prior notice. -
Page 5: General Safety Rules
GENERAL SAFETY RULES Safety is a combination of common sense, staying alert, and knowing how your power tool works. SAVE THESE SAFETY INSTRUCTIONS. WARNING: Do not operate this unit until you read this instruction manual for safety, operation and maintenance instructions. Failure to follow all instructions listed below may result in electric shock, fire, and/or serious personal injury. -
Page 6: Special Safety Rules For Cordless Vacuum Cleaner
POWER TOOL USE AND CARE Do not force power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it is designed. Do not use the power tool if switch does not turn it on or off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired. - Page 7 Sparks inside the motor can ignite flammable vapors or dust. To reduce the risk of fire or explosion, do not use near combustible liquids, gases, or dusts, such as gasoline or other fuels, lighter fluid, cleaners, oil-based paints, natural gas, coal dust, magnesium dust, grain dust, aluminum dust, or gun powder.
-
Page 8: Symbols
Disconnect battery pack from vacuum and unplug vacuum from the power supply before making any adjustments, changing accessories, servicing, moving or storing the vacuum. Such preventative safety measures reduce the risk of starting the appliance accidentally. Avoid accidental starting. Be sure the switch is in the OFF position before inserting the battery pack ... -
Page 9: Knowing Your Cordless Vacuum Cleaner
KNOWING YOUR CORDLESS VACUUM CLEANER Fig.1 On/Off switch Blowing port Vacuum port Handle Battery Latch Container Caster Hose Extension tube Floor brush Unpacking Unpack the power tool and all its parts, and compare against the list below. Do not discard the carton or any packaging materials. -
Page 10: Assembly Instruction
ASSEMBLY INSTRUCTION WARNING: Do not use this product if any parts on the packing list are already assembled to your product when you unpack it. Parts on this list are not assembled to the product by the manufacturer and require customer installation. Use of a product that may have been improperly assembled could result in serious personal injury. -
Page 11: Operating Instruction
Fitting the suction hose and tube Connect the suction hose to the container by screwing the rotatable plastic end piece of the suction hose into the hose connection securely. CONNECTING AND REMOVING BATTERY IMPORTANT! The battery pack is not charged when it is purchased. Before using the power tool for the first time, place the battery pack in the battery charger and charge. - Page 12 VACUUM USE WARNING: To reduce the risk of damage to the motor,use this machine to vacuum dry material only and do not operate without the filter in place . Ensure the HEPA type filter or cloth filter is always fitter before the use. ...
-
Page 13: Maintenance
MAINTENANCE WARNING: In order to avoid personal injury and the risk of fire and electric shock, remove the battery pack before adjusting, inspecting, or cleaning the power tool. WARNING: When servicing, use only identical replacement parts. Use of any other parts could create a hazard or cause product damage. -
Page 14: Trouble Shooting
TROUBLE SHOOTING WARNING: Read instruction manual first! Remove battery pack from the tool before making adjustments or assembling accessories. Problem Possible Cause Possible Solution Battery pack not installed Check battery pack installation. properly Vacuum will not operate Check battery pack charging Battery pack not charged. -
Page 15: Exploded View
EXPLODED VIEW... -
Page 16: Parts List
PARTS LIST Item Stock# Description Qty. PS76168A-001 Handle PS76168A-002 Cover PS76168A-003 On/Off Switch PS76168A-004 Platen PS76168A-005 Motor PS76168A-006 Foam PS76168A-007 Electrical plug-in PS76168A-008 Motor seal ring PS76168A-009 Motor base PS76168A-010 HEPA filter PS76168A-011 Cloth filter PS76168A-012 Container PS76168A-013 Caster PS76168A-014... -
Page 17: Warranty
TWO (2) YEARS LIMITED WARRANTY ® PowerSmart is committed to building tools that are dependable for years. Our warranties are consistent with our commitment and dedication to quality. TWO (2) YEARS LIMITED WARRANTY OF POWERSMART PRODUCTS FOR HOME USE. PowerSmart (“Seller") warrants to the original purchaser only, that all PowerSmart consumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase.
