Summary of Contents for Centro 3
- Page 1 Centro 3 Assembly Instructions (with spacer bars)
- Page 2 Stand base on the ground. connector bar grooves Repeat for other base posts. Loosen grub screws and slide shown in stage 3. both connector bars half way out of groove and retighten. Repeat for other base posts. Note: Base plates pre-assembled on kits supplied in carry bag only.
- Page 3 Slot vertical rails onto spacer Slot spacer bars into bars leaving space at bottom The side straight vertical assembled post approx for the horizontal graphic graphic rails should now be 150mm from top and base. rail. Secure in place by assembled.
- Page 4 Slot second horizontal rails onto all vertical rails and Connect first horizontal tighten grub screws. rails to vertical rails and tighten grub screws as before. Adjust height of vertical rails if necessary to ensure assembly is square. Affix graphic panels to the graphic fixing strips, starting from the top and side, working across the...
- Page 5 Centro 3 Assembly Instructions (no spacer bars)
- Page 6 Stand base on the ground. connector bar grooves Repeat for other base posts. Loosen grub screws and slide shown in stage 3. both connector bars half way out of groove and retighten. Repeat for other base posts. Note: Base plates pre-assembled on kits supplied in carry bag only.
- Page 7 Connect first horizontal rails at the bottom of posts, leaving a 10mm gap between underside of rail and surface of base plate. Tighten clamp screws to secure in place. Remove four internal clamps Insert internal clamps into from the spacer bars by both ends of the 750mm removing grub screw and horizontal rails and secure...
- Page 8 The side straight 950mm Slot second horizontal rails graphic rails should now onto all vertical rails and be assembled. Note fit clamps into 8-way post. position of graphic fixing Tighten clamp screws to strips, which should align. secure assembly. Connect assembled vertical Affix graphic panels to the rails to the bottom horizontal graphic fixing strips,...
