M-system 18TG Instruction Manual page 2

TERMINAL CONNECTIONS
Connect the unit as in the diagram below or refer to the connection diagram behind the front cover.
■ EXTERNAL DIMENSIONS unit: mm (inch)
8–M3.5
SCREW
■ CONNECTION DIAGRAM
1
INPUT
2
7 (.28)
24 (.94)
5 +
OUTPUT 2
6 –
OUTPUT 1
OUTPUT 2
POWER
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
2–M3
SCREW
7 (.28)
32 (1.26) 78 (3.07)
■ TERMINAL ASSIGNMENTS
7 8
5 6
1 2
3 4
18TG
EM-1839 Rev.5 P. 2 / 3
