Summary of Contents for Tecnoclima WIMBLEDON 145
- Page 1 TECHNICAL INFORMATION ASSEMBLY, USE AND MAINTENANCE AUTONOMOUS MONO-BLOCK AIR TREATMENT UNIT WIMBLEDON MODEL - 1 -...
-
Page 2: Compliance
TECNOCLIMA Technical Assistance Service, which is specifically skilled and trained to maintain the highest efficiency level of the machine at the lowest operating costs and which can provide you with original spare parts, if needed. -
Page 3: Table Of Contents
GENERAL INFORMATION CONTENTS GENERAL INFORMATION: Compliance Pin number Range Warranty Contents General instructions Basic Safety rules Disposal information Appliance description Identification Structure Heat exchanger scheme Dimension and weight Technical data Information requirements 2016/2281 INSTALLATION AND SETTING INSTRUCTIONS: Product receipt Movement and transport Transport locks Position Clearance area... -
Page 4: General Instructions
GENERAL INFORMATION GENERAL INSTRUCTIONS This instruction manual is an integral part of the equipment and delivery, and must be preserved with care. In case of equipment resale, the manual must be delivered to the new owner or user. In case of loss of or damages to this manual, you are kindly requested to contact the Manufacturer or the Technical Assistance Service of your area. -
Page 5: Basic Safety Rules
GENERAL INFORMATION Bear in mind that if you use products powered trough electric power, gas, etc., you should comply with some basic rules, such as: Children and non-assisted disabled persons should not use the air treatment unit. It is forbidden to activate electric devices or appliances, such as circuit breakers, domestic appliances etc. if you notice a smell of fuel or unburnt products. -
Page 6: Appliance Description
GENERAL INFORMATION DESCRIPTION The air treatment unit essentially represents a thermal group that exchanges the combustion products of a forced-air gas burner with an air flow generated by a group of highly efficient fans. The air to be heated is sucked by the latter and when it touches the hot surfaces of the heat exchanger, the air temperature rises;... - Page 7 GENERAL INFORMATION “TR” Safety thermostat : The air treatment unit is equipped with a safety thermostat whose sensor is placed on the air outlet. It stops the burner if the air is anomalously overheated It has to be manually reset, after restoring normal operating conditions.
-
Page 8: Identification
GENERAL INFORMATION IDENTIFICATION The warm air heaters can be identified through: • The Technical Plate, applied to the equipment, and indicating its technical/performance data. MANUFACTURER’S IDENTIFICATION DATA AIR TREATMENT UNIT Model Production number Country Category Codes Type Year Max thermal capacity Max thermal power Max air capacity m ³... -
Page 9: Structure
GENERAL INFORMATION STRUCTURE 1) Smoke pipe 11) Condensate drain fitting 2) Combustion chamber 12) Smoke discharge Kit 3) Front fume manifold 13) Lower struts 4) Rear fume manifold 14) Outside air controlling shutter 5) Heat exchanger inspection shutters 15) Gravity shutter on outside air 6) Fume exhaust fitting 16) Protection net 7) Burner head... -
Page 10: Heat Exchanger Scheme
INSTALLATION AND SETTING INSTRUCTIONS HEAT EXCHANGER SCHEME Axonometric image of the heat exchanger: Combustion products • create an inversion in the combustion chamber; • are transferred into the first smoke collector and then flow into the first row of exchanging elements;... -
Page 11: Dimension And Weight
DIMENSIONS AND WEIGHT - 11 -... -
Page 12: Technical Data
TECHNICAL DATA TYPE MAX NOMINAL THERMAL POWER 152,3 247,5 (burned) Kcal/h 130.980 212.850 MAX NOMINAL THERMAL POWER 148,2 240,0 (useful) kcal/h 127.450 206.400 PERFORMANCE AT MAX. THERMAL POWER 1) 97,3 96,9 MAX. PRESSURE IN COMBUSTION CHAMBER mbar GROSS SMOKE TEMPERATURE (2) °C ... -
Page 13: Information Requirements 2016/2281
INFORMATION REQUIREMENTS 2016/2281 TYPE Type of installation: Type of fuel: Gassoso Gassoso Capacity: rated,h Useful efficiency 92,5 95,4 95,4 Electric power consumption: 0,18 0,18 0,18 0,18 0,01 0,01 Other items: s,flow 86,7 86,6 Refferd to the high heating value (Hs): •... -
Page 14: Product Receipt
PRODUCT RECEIPT The air treatment unit is supplied together with: • Document envelope including: User guide Warranty certificate Spare parts catalogue Barcode tags Condensate discharge syphon Level switch MOVEMENT AND TRANSPORT The machine is used through a forklift: GENERAL INSTRUCTION TO MOVE AND TRANSPORT THE APPLIANCE WARNING! The appliance should be moved by adequately equipped persons and with tools suitable for the appliance weight. -
Page 15: Transport Locks
INSTALLATION AND SETTING INSTRUCTIONS TRANSPORT LOCKS To prevent damage to the appliance during transportation, some red mechanical locks can be used, limiting the movement of some internal elements. Their identification and the instructions to remove them are specified on a self-sticking tag placed on the appliance. THE LOCKS MUST BE REMOVED BEFORE THE FIRST COMMISSIONING. -
Page 16: Clearance Area
INSTALLATION AND SETTING INSTRUCTIONS CLEREANCE AREA The machine shall be easily and safely reached without needing special equipment (ladders - movable platforms -etc.). Around the machine, minimum distances shall be complied with so that the control and/or maintenance operations can be performed and that no obstacles block the air flow. WARNING! Any Laws or specific regulations requirements (e.g. - Page 17 Connection of the air treatment unit to the flue: Condensate drain fitting. T-shape joint Flue. Bracket. Flue. Terminal. WARNING! All stove components must be CEE certified. There must be a condensate drain at the lowest part of the smoke duct (see diagram), in order to avoid condensate backflow from the chimney flue to the air treatment unit.
-
Page 18: Condensate Drain Connection
INSTALLATION AND SETTING INSTRUCTIONS The chimney flue must guarantee minimum depression, as provided for by Technical Standards in force, taking into consideration that the pressure is “zero” at the joining point with the smoke duct. Non-insulated exhaust ducts are a source of potential hazard. Inadequate or wrongly sized chimney flues or smoke ducts may amplify the combustion noise and negatively influence the combustion parameters. -
Page 19: Condensate Drain Siphon (Supplied With The Machine)
INSTALLATION AND SETTING INSTRUCTIONS Position of condensate drain fittings – air treatment unit: TYPE (mm) (mm) (mm) 1.235 1.185 The air treatment unit is provided with two condensate drain fittings, which must be connected to the drain system. The fittings must never be clogged. CONDENSATE DRAIN SYPHON (SUPPLIED WITH THE APPLIANCE) In order to prevent leakage of combustion products from the condensate drain and the backflow of sewage fumes, the siphons should be installed (one for each condensate drain system) -
Page 20: Level Switch (Supplied With The Machine)
INSTALLATION AND SETTING INSTRUCTIONS Connection to the condensate drain fittings condensate condensate drain drain WARNING Pipes with external diameter ranging between 24 and 30 mm are to be used in connecting the air treatment unit to the syphon. The head must not be smaller than 25 mm. The total weight of the condensate drain system must not weigh on the equipment, and must be suitably and separately mounted. -
Page 21: Air Outlet-Intake Connection
INSTALLATION AND SETTING INSTRUCTIONS Level switch installation: ELECTRICAL CONNECTION COLLEGAMENTO ELETTRICO INTERRUTTORE LEVEL SWITCH DI LIVELLO WARNING! The normally closed (N.C.) level switch contact should be connected in series to the gas burner thermostat line. The flame must be immediately put out when the level switch starts to operate. AIR OUTLET –... -
Page 22: Combustion Air
COMBUSTION AIR The air treatment unit is to be installed as provided for by the Standards in force; the unit is to be used only in sufficiently aired places. Always ensure that the combustion air socket is not clogged (ex. must be free from leaves, pieces of paper, nylon strips, etc.). -
Page 23: Air Outlet Temperature Probe
INSTALLATION AND SETTING INSTRUCTIONS The table below shows indicative information about the gas burner pre-adjustment: Functioning of the burner at its MAX. nominal thermal IMPUT: DESCRIPTION UNIT TYPE 1 TYPE 2 Brand RIELLO RIELLO Model BS 3/M RS 34/M MZ Position of combustion head notch Position of air shutter... -
Page 24: Safety Thermostats
INSTALLATION AND SETTING INSTRUCTIONS LIMIT SAFETY THERMOSTATS “LM” safety thermostat: The air treatment unit is equipped with a safety thermostat whose sensor is placed on the air outlet. It stops the burner if the air is anomalously overheated. It has to be manually reset, after removing the cause that has caused its intervention. - Page 25 INSTALLATION AND SETTING INSTRUCTIONS Pre-calibration of the safety thermostats with automatic reset (TR1): TYPE TYPE 1 TYPE 2 PRE-CALIBRATION VALUE °C Pre-calibration of the safety thermostats with automatic reset (TR2): TYPE TYPE 1 TYPE 2 PRE-CALIBRATION VALUE °C Check of the calibration of the safety thermostat “TR”: When the appliance is running normally, lower the temperature of the safety thermostat until it is triggered.
-
Page 26: Wiring Diagram
INSTALLATION AND SETTING INSTRUCTIONS WIRING DIAGRAM Cod. 10023495-TC Wiring diagram - TYPE 1: - 26 -... - Page 27 INSTALLATION AND SETTING INSTRUCTIONS - 27 -...
- Page 28 INSTALLATION AND SETTING INSTRUCTIONS Wiring diagram - TYPE 2: - 28 -...
- Page 29 INSTALLATION AND SETTING INSTRUCTIONS - 29 -...
- Page 30 INSTALLATION AND SETTING INSTRUCTIONS Wiring diagram - connection to the modulating gas burner regulator (RFW 40): - 30 -...
- Page 31 INSTALLATION AND SETTING INSTRUCTIONS Legend: Main switch LM 1-2 Safety thermostat with manual reset TR 1-2 Safety thermostat with automatic reset ST 1-2 Fire shutter switch Condensate safety switch Fan start timer Fuses Fuses Fuses KM 1-2 Contactor RT 1-2 Thermal relay Burner relay Alarm relay...
-
Page 32: Electric Connection
INSTALLATION AND SETTING INSTRUCTIONS ELECTRIC CONNECTION The machines are provided with an installed and wired electric panel. The electric connections to be made by the fitter are: general power supply. blown gas burner, gas supply train and burner accessories; safety thermostats installation and connection; installation and connection of temperature probes;... -
Page 33: Start-Up And Stop Of The Treated Air Fan
INSTALLATION AND SETTING INSTRUCTIONS START/STOP OF TREATED AIR FAN The fan unit should operate continuously. FAN SPEED SETTING The pulley installed on the fan motor has a variable pitch diameter The appliance is delivered with the transmission ratio regulated at an intermediate position. During the installation - first start-up phase, it is mandatory to check the transmission ratio and adjust it, if necessary, in order to guarantee a nominal air flow compatible with the load loss of the air distribution system. -
Page 34: Controls
INSTALLATION AND SETTING INSTRUCTIONS WARNING! It is forbidden to stop the equipment by disconnecting the main electric power, since the non performance of the exchanger post-ventilation shall lead to thermal inertia and consequently to the triggering of the safety thermostats which require manual release. Besides, repeated operations might damage the equipment CHECKS In order to ensure that the machine works properly, some basic parameters should be checked. -
Page 35: Electric Panel Controls
TECHNICAL ASSISTANCE INSTRUCTIONS ELECTRICAL PANEL CONTROLS The electrical panel has the following controls and signalling devices: MAIN SWITCH Installed on the equipment electrical main panel; it stops the main electric power supply to the equipment. BUNER BLOCK INDICATOR Red device, installed on the appliance electrical panel; it signal when the gas burner has stopped. VOLTAGE INDICATOR Green device, installed on the appliance electrical panel;... -
Page 36: Maintenance
TECHNICAL ASSISTANCE INSTRUCTIONS MAINTENANCE Periodic cleaning and maintenance operations should be performed to preserve the equipment and ensure its correct functioning. Any operation should be performed by skilled and trained personnel, who have to start the work when the equipment has cooled down and after having disconnected the electric and fuel supplies. The use of protection gloves is recommended. -
Page 37: Limit Thermostat Maintenance
TECHNICAL ASSISTANCE INSTRUCTIONS LIMIT THERMOSTAT MAINTENANCE Check the correct functioning of the LM and TR safety thermostats on at least an annual basis. Manually rotate the graduated dial to simulate its activation, which is verified when the burner switches off. Ensure also that the system is regularly restored by adjusting the release push-button. -
Page 38: Assistance
TECHNICAL ASSISTANCE INSTRUCTIONS ASSISTANCE Hot air generators assembly, operating and maintenance are to be performed by qualified technical personnel. To have information about the nearest authorised Assistance Centre, please contact the Seller who shall give you all the necessary information in this regard. MODULATING THERMAL POWER REGULATOR For all information and instructions concerning the modulating thermal power regulator, refer only to the manual provided together with the appliance. -
Page 39: Notes
TECHNICAL ASSISTANCE INSTRUCTIONS NOTES - 39 -... - Page 40 38057 PERGINE VALSUGANA (TRENTO) ITALY Viale dell’Industria, 19 tel. (0461) 53 16 76 fax (0461) 51 24 32 www.tecnoclimaspa.com tecnoclima@tecnoclimaspa.com Since our Company is constantly committed to improve its products, their esthetical features, size, technical data, fittings, and additional devices might change. 12/17_Rev.02...
