CONTENTS CONTENTS Important Safety Instructions Safety Information Preparation What's Included Front View Rear View Installing the Stand Removing the Stand for Wall-Mounting Remote Control Connecting External Devices Customizing TV Settings Initial Setup Navigating the Setup Settings Streaming Media Viewing Photos Listening to Music Source Setup...
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS • Please keep the unit in a well-ventilated environment. • Read these instructions – All the safety and operating instructions should be read before this WARNING: To reduce the risk of fire or electric shock, product is operated. do not expose this apparatus to rain or moisture. • Keep these instructions –...
SAFETY INFORMATION SAFETY INFORMATION To ensure reliable and safe operation of this equipment, please carefully read all the instructions in this user guide, especially the safety information below. Electrical Safety • The TV set should only be connected to a main power supply with voltage that matches the label at the rear of the product.
PREPARATION PREPARATION What's Included TV Set Remote Control with Batteries TV Stand Four Screws Quick User Manual Start Guide User Manual Quick Start Guide...
PREPARATION Front View 1. POWER Switch the TV between On / Standby mode. 2. SOURCE Press to select among different input signal sources. 3. MENU Display the OSD (on screen display) menu. 4. CH Press to select a channel. 5. VOL +/- Press to adjust the volume. 6. POWER Indicator Illuminate blue when the TV is turned on.
PREPARATION Rear View HDMI HDMI 1. Power Cord 8. DTV/TV Input Connect to AC power outlet. Connect to the antenna (75Ω VHF/UHF) 2. Headphone Socket socket with the RF coaxial cable. Connect to the Headphones. 9. OPTICAL Output 3. USB Port Connect a digital sound system to this Connect to a USB storage device to play jack.
PREPARATION Installing the Stand • 1. Lay the TV face-down on a flat, cushioned surface to avoid damaging or scratching. • 2. Fix the Left Base Stand to the main unit using 2pcs provided screws. • 3. Fix the Right Base Stand to the main unit using 2pcs provided screws.
CUSTOMIZING TV SETTINGS CUSTOMIZING TV SETTINGS Initial Setup • Connect the power cord to the power socket after you have completed all the physical connections. At this stage, the TV will enter Standby Mode and the red LED indicator will illuminate. • In Standby Mode, press the button on the main unit or on the remote control to turn the TV on.
CUSTOMIZING TV SETTINGS :Exit MENU • If channels can not be found, this frame will be displayed automatically. Navigating the Setup Settings • Press the MENU button to display the main menu. • Use buttons to select SETUP menu and then press buttons to navigate and select the available menu.
CUSTOMIZING TV SETTINGS STREAMING • Press the MENU button on the main unit or on the remote control to display the STREAMING. Then press buttons to select the desired APP and press OK button to view what you want. Or press the hotkey on the remote control to enter the APP directly.
CUSTOMIZING TV SETTINGS MEDIA NOTE:Portable storage devices( USB disk or Hard disk) should be inserted. • Press the MENU button on the main unit or on the remote control and then press buttons to select the MEDIA, and then press OK button to enter. Viewing Photos MEDIA Device Found: 1...
CUSTOMIZING TV SETTINGS Listening to Music MEDIA Device Found: 1 Return WMAW WMEW MUSIC PHOTOS WMDW WMTW Device : 1 Directories:10 Files:0 Total:10 MEDIA Crazy in love.mp3 Vol.7 Status: Play 00 01 14 00 04 16 • After entering MEDIA, press buttons to select MUSIC and then select the disk type to enter.
CUSTOMIZING TV SETTINGS SETUP • Press the MENU button on the main unit or on the remote control to display the main interface. Then press buttons to select SETUP menu and press button to select the desired option. SETTINGS • Press buttons to select SETTINGS menu and then press OK button to enter.
CUSTOMIZING TV SETTINGS PICTURE • Press buttons to select PICTURE menu and then press OK button to enter. Press buttons to select the following picture options and then press buttons to adjust each option’s setting. Cycle among picture mode: Dynamic/Movie/User/ Standard.
COSTOMIZING TV SETTINGS CHANNEL • Press buttons to select CHANNEL menu and then press OK button to enter. Press buttons to select the following channel options and then press buttons to adjust each option’s setting. Air/Cable Select antenna between Air and Cable. First, select your cable system from Auto/STD/IRC/HRC.
Select a period of time after which the TV automatically switches to standby mode: Off/5/10/…/180/240 min. Sleep Timer Alternative: You may press the SLEEP button repeatedly to select the number of minutes directly. Select a Time Zone: Hawaii/ Alaska/ Pacific/ Mountain/ Time Zone Central/ Eastern/ Atlantic/ Newfoundland.
Page 21
• If there is a new version, it will be downloaded in the background. When you want to enter the app, a menu bar will pop up reminding you that upgrade software is downloading. Please try later... • After the download completed, it can upgrade automatically after users press the standby button.
LOCK • Press buttons to select LOCK menu and then press OK button to enter. Use the 0-9 buttons to input 4-digit password to enter the LOCK menu. • Press buttons to select the following lock options and then press buttons to adjust each option’s setting.
PARENTAL CONTROL PARENTAL CONTROL Press the MENU button on the main unit or on the remote control and then press buttons to select LOCK menu. Use the 0-9 buttons to input the 4-digit password to enter the LOCK menu. If used, this option feature can "block'' undesirable programming from appearing on the TV.
Page 24
PARENTAL CONTROL • Motion Picture Association of America (MPAA) Rating System Grade Meaning General Audiences Content not offensive to most viewers. Parental Guidance Content is such that parents may not want their Suggested children to view the program. Program is inappropriate for preteens, with a greater Parents Strongly PG-13 degree of offensive material suggested than a PG...
TROUBLESHOOTING TROUBLESHOOTING If your TV does not operate normally or cannot be turned on, please check the following troubleshooting questions. Remember also to check any other connected electronic device, such as DVD or Blu-ray player to pinpoint the problem. If the TV still fails to operate normally, please contact technical support. The TV does not operate properly The TV does not respond • The TV may freeze up during use.
TROUBLESHOOTING The audio function does not work • Press the VOL +/- buttons. • Sound muted? Press the MUTE button. Picture OK but no sound • Try another channel. The problem may be caused by the broadcaster. No output from one of the • Adjust the Balance settings in the AUDIO menu.
SPECIFICATION SPECIFICATION Panel Size 49.5 inch diagonally Display Type DLED Panel Technology Panel 60 Hz Vs. 120 Hz 60 Hz Display Resolution 1080P HDMI Support Up to 1080P Panel Resolution 1920 x 1080 Aspect Ratio 16:9 Dynamic Contrast Ratio-Panel 2400~3000:1 Response Time (G To G) 6.5 ms Lamp Life (Typ. Hours)
PARTS : For a period of one (1) year from the date of original consumer purchase, SEIKI will supply, at no charge to the original consumer, new, rebuilt or refurbished replacement parts in exchange for defective parts. After the one (1) year Warranty period, you must pay for the costs of all parts.
OTT APP SERVICE If you want to know about these APP information or get more service. Please refer to following content. • Netflix You can call the following telephone for more help: 866-579-7172 If your matter is regarding customer service, please refer to https://contactus.netflix.com/help for alternative contact information.
