Summary of Contents for Esatto EBF196W
- Page 1 Product: Model Code/s: 196L Bar Fridge EBF196W User Manual Exactly what you need Version: Online: V1.3 1221 esatto.house...
- Page 2 User Manual Appliances Exactly what you need...
- Page 3 Contents Page 5 Page 6 Welcome Safety Warnings Page 10 Page 11 Product Overview Getting Started Page 11 Page 14 Installation Using Your Refrigerator Page 15 Page 15 Usage Tips Energy Saving Tips Page 16 Page 18 Maintenance Specifications...
- Page 4 User Manual Residentia Group Online Postage Telephone — www.residentia.group PO Box 5177 1300 11 4357 Head Office www.esatto.house Burnley, Victoria 165 Barkly Avenue Australia 3121 Socials Burnley, Victoria @esatto.house Australia 3121 — 600 546 656...
- Page 5 It is important that you read through the following use and care manual thoroughly to familiarise yourself with the installation and operation requirements of your appliance to ensure optimum performance. Again, thank you for choosing an Esatto appliance and we look forward to being of service to you. Kind Regards,...
- Page 6 User Manual Safety Warnings IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE Read this manual thoroughly before first use, even if you are familiar with this type of product. The safety precautions enclosed herein reduce the risk of fire, electric shock and injury when correctly adhered to. Make sure you understand all instructions and warnings.
- Page 7 • Please pull out the plug in case of power failure or cleaning. Do not connect the refrigerator to power supply within five minutes to prevent from damages to the compressor due to successive starts. WARNING • Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
- Page 8 User Manual Safety Warnings (Continued) WARNING • When positioning the appliance, ensure the supply cord is not trapped or damaged. • Auxiliary Items: Do not use an inverter, adaptor or extension cord with this appliance. If the cord is too short, have a qualified electrician install an outlet near the appliance. Use of an extension cord and an inverter can negatively affect the performance of the unit.
- Page 9 WARNING Do not use mechanical devices or other means to accelerate the defrosting process. Never use a sharp or metal instrument to remove frost or clean the appliance. Use a plastic scraper, if necessary. Service: Do not attempt to repair, modify or replace any part of the appliance unless specifically recommended in this manual.
- Page 10 User Manual Product Overview Your Refrigerator LED lamp Temperature control knob Door tray Shelf Fruit and vegetables Adjusting procedures: a. Turn the feet clockwise to raise the refrigerator; b. Turn the feet counterclockwise to lower the refrigerator; c. Adjust the right and left feet based on the procedures above to a horizontal level.
- Page 11 Getting Started Unpacking • Packaging materials: This appliance has been packaged to protect it against transportation damage. Remove all packaging materials from around and inside the appliance and keep the original packaging carton and materials in a safe place. It will help prevent any damage if the product needs to be transported in the future, and you can use it to store the appliance when it is not in use.
- Page 12 User Manual Installation (Continued) Installation Cont. Electrical connection WARNING • It must be possible to disconnect the appliance from the mains power supply; the plug must therefore be easily accessible after installation. • Before plugging in your new fridge, let it stand upright for at least 2 hours. This will allow the refrigerant gases to settle into the compressor and reduce the possibility of a malfunction in the cooling system.
- Page 13 Then remove the door, the bottom hinge and adjustable foot. Install the bottom hinge and adjustable foot on the other side of the fridge and dismantle the door stopper and install it on the other side Install the door to the bottom hinge, install the upper hinge,upper hinge cover and hole cover on the...
- Page 14 User Manual Using Your Refrigerator Temperature Controls • Turn the temperature control knob to MAX, to lower the internal fridge temperature. • Turn the temperature control knob to MIN, to increase the internal fridge temperature. • The text on the knob only represents the temperature level, but is not associated with a specific temperature, •...
- Page 15 Usage Tips • Do not store food uncovered in the fridge. Always use good quality, fridge-proof packaging to maintain food quality. Remove air from packages of solid food and seal bags tightly before freezing. • Keep portions small to ensure they are frozen (and subsequently defrosted) rapidly.
- Page 16 User Manual Maintenance and Cleaning Defrosting • Unplug the power cord. • Remove the food from the refrigerator and place it properly to prevent food from melting. • Clear the drain pipe (to use soft materials to prevent damage to the liner), combined with the defrost preparation of water containers (pay attention to clean the compressor compartment water tray, •...
- Page 17 Contact our after sales support on 1300 11 43 57 for advice. Our after sales support centre stocks a selection of spare parts for the Esatto 192L Refrigerator. To enquire about purchasing a part, call us on 1300 11 43 57 or email support@residentiagroup.com.au...
- Page 18 User Manual Specifications Model: EBF196W Product Dimensions: W: 550mm, D: 575mm, H: 1232mm Weight (Net/Gross): 39/43kg Net Capacity: 196L Energy Rating: 4 Stars MEPS Standards This product complies with AS/NZS IEC 62552.1/2/3:2018 electrical safety, and with EN 55014-1:2006+A1:2009 A2:2011 for electromagnetic compatibility.
- Page 19 FAQs and Troubleshooting Problem Possible Cause Possible Solution The appliance • The appliance is not plugged in. • Plug in the appliance. does not • The appliance is turned off. • Turn on power point. operate. • The circuit breaker tripped or a •...
- Page 20 User Manual Attach your receipt to this page...
- Page 21 Purchase Details For your records, please record details of your purchase below and staple your receipt to this page. Your serial number can be found on the rear of your refrigerator STORE DETAILS STORE NAME ADDRESS TELEPHONE PURCHASE DATE PRODUCT DETAILS MODEL NO.
- Page 22 User Manual Warranty Information WARRANTY TERMS AND CONDITIONS IN THIS WARRANTY REFRIGERATION APPLIANCES ‘acceptable quality’ as referred to in clause 10 of this warranty has the same meaning referred to in This document sets out the terms and conditions of the the ACL;...
- Page 23 You will bear the cost of transportation, travel and For Appliances and services provided by Residentia delivery of the Appliance to and from Residentia Group in Australia, the Appliances come with a Group or its ASR. If you reside outside of the service...
- Page 24 This page User Manual is intentionally left blank Appliances Exactly what you need A RESIDENTIA GROUP INITIATIVE...
