Summary of Contents for Cadence Home Cinema XLNS-12
- Page 1 HOME CINEMA SERIES XLNS-12 / XSUB-12 ACTIVE POWERED SUB WOOFER INSTALLATION GUIDE...
- Page 2 Thank you for purchasing a Cadence Cinema Home Series Active Powered Subwoofer. SOME BASIC ACOUSTIC FACTS: The acoustic characteristics of a sub woofer are such that the bass waves will travel along the floor of your room. You may therefore position the sub woofer in any place as the wave is non directional.
-
Page 3: Signal Input
Once again, experiment with various settings until you find the combination perfect for you. The availability of this fine tuning is what separates a cheap basic audio system from a Cadence Cinema Series Home Theater System. AUTO TURN ON CIRCUIT: The sub woofer features an Auto Turn On circuit. - Page 4 XLNS-12 / HIGH LEVEL CONNECTION SYSTEM OPTION 1 LEFT SATELLITE SPEAKER XLNS-12 HIGH LEVEL CONNECTION SYSTEM OPTION 2 LEFT SATELLITE SPEAKER speaker output speaker output AMPLIFIER OR RECEIVER LOW LEVEL LOW LEVEL INPUT INPUT ACTIVE SUBWOOFER XLNS-12 ACTIVE SUBWOOFER XLNS-12...
- Page 5 XSUB-12 / HIGH LEVEL CONNECTION SYSTEM OPTION 1 LEFT SATELLITE SPEAKER XSUB-12 HIGH LEVEL CONNECTION SYSTEM OPTION 2 LEFT SATELLITE SPEAKER speaker output speaker output AMPLIFIER OR RECEIVER Design by Germany R I S K O F E L E C T R I C S H O C K , D O N O T O P E N...
- Page 6 XLNS-12 / XSUB-12 LOW LEVEL RCA CONNECTION SYSTEM XLNS-12 / XSUB-12 LOW LEVEL RCA CONNECTION SYSTEM If your receiver has only one sub woofer RCA out put, you must purchase an RCA “Y” Adaptor for proper hook-up to the sub woofer.
-
Page 7: One Year Warranty
Our liability applies only to any actual factory defective Cadence unit, we will not be held responsible for damages occurring to other units in the system or due to improper installation or use and from electronics or enclosures not properly secured. -
Page 8: Features And Specifications
LED Power-On Indicator. Gold Plated Banana Plug T erminals. Cabinet Size: 16.5”(W) x 15.5” (D) x 17.5”(H) MODEL XLNS-12 High Power, Active 12" Sub W oofer. Built-in , Class A 300 W att Power Amplifier. Front Firing Sub W oofer with "Bass-Reflex, T uned Port System".
