Product Code: 2079
Specifications:
•
•
•
•
•
•
About the TradeQuip brand
The 'TradeQuip' brand of workshop equipment, is designed for use in a demanding workshop
environment by professional users. With proven and
reliability, 'TradeQuip' branded products offer the very best in performance for an affordable
price. All backed by a 1year trade guarantee across 1,000+ distributors Australia wide.
Safe Working Capacity: 900kgs
Maximum Reach of Boom: 1290mm (400kg) 870mm (900kg)
Min Lift Radius: 930mm
Max Lift Radius: 1800mm
Swivel Base Plate: 275 x 275mm
Mounting Base Holes: 8 holes - 16mm (dia) x 110mm (centre-centre)
Made in China to TQB Brands Pty Ltd specifications
Visit us at www.tqbbrands.com.au
Product Code: 2079
SWIVEL BASE
UTILITY CRANE
trusted "Made
for
the Trade"
Page 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TradeQuip 2079
Summary of Contents for TradeQuip 2079
- Page 1 • Mounting Base Holes: 8 holes - 16mm (dia) x 110mm (centre-centre) About the TradeQuip brand The 'TradeQuip' brand of workshop equipment, is designed for use in a demanding workshop environment by professional users. With proven and trusted “Made the Trade”...
-
Page 2: Table Of Contents
09/21 Product Code: 2079 WARNING IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE WARNING The instructions and warnings contained in this manual should be read and understood before using or operating this equipment. Do not allow anyone to use or operate this equipment until they have read this manual and have developed a thorough understanding of how this equipment works. - Page 3 09/21 Product Code: 2079 STANDARD OPERATING PROCEDURE DO NOT use this machine unless you have been trained and assessed to a competent level in its sate use and operation, and have been given permission to use this DO NOT tilt the unit...
-
Page 4: Assembly, Operation, Preventitive Maintenance
The telescopic boom design with manual hydraulic hand pump pivots the boom up and down and swivels 360° for maximum accessibility. Get extra lift where you need it most with this Tradequip Utility Crane that easily lifts loads to 900kg. - Page 5 09/21 Product Code: 2079 Secure the Base (J) to the utility bed, garage floor, or where the hoist will be used. Insert the assembled parts (Main Post, Boom and Hydraulic Ram) to the Base. Insert the Boom Extension (B) into the Boom.
- Page 6 09/21 Product Code: 2079 3. BEFORE USE Prior to each use conduct a visual inspection checking for abnormal conditions, such as cracked welds, leaks, and damaged, loose, or missing parts. Prior to first use bleed the hydraulic system to eliminate any air that may have entered during shipping.
- Page 7 09/21 Product Code: 2079 6. STORAGE Crane boom must always be stored and secured in the down position when not in use. This is to protect the chrome ram from elements/corrosion etc and to safely drive the vehicle without having the boom swing around dangerously.
-
Page 8: Parts List
09/21 Product Code: 2079 PARTS LIST Part # Description Part # Description Chain and Hook Bolt M14x90 Boom Extension Flat Washer ˚14 Boom Lock Washer ˚14 Main Post Nut M14 Handle Bolt M16x110 Hydraulic Ram Flat Washer ˚16 Pump Handle Lock Washer ˚16... -
Page 9: Warranty
WARRANTY TradeQuip products have been carefully tested and inspected before shipment and are guaranteed to be free from defective materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the guarantee period is ninety days from the date of purchase.
