Summary of Contents for Eminence ASD 1001

  • Page 1 PRO AUDIO GUITAR BASS EMINENCE DONGGUAN...
  • Page 2: Professional Series

    PROFESSIONAL SERIES 12" 15" EPA-CN2512 EPA-CN2515 EPA-CN2512 SPECIFICATION Nominal Basket Diameter 12", 305mm Nominal Impedance* 8 ohms Power Rating** 225W Resonance 49Hz Usable Frequency Range 49Hz-3.5kHz Sensitivity*** 99.5 Magnet Weight 7 oz Gap Height .28", 6.99mm Voice Coil Diameter 2.5", 63.5mm THIELE &...
  • Page 3 6" 8" EPA-S1506 EPA-S1506 SPECIFICATION Nominal Basket Diameter 7", 165mm Nominal Impedance* 8 ohms Power Rating** 100W Resonance 111Hz Usable Frequency Range 103Hz-6.0kHz Sensitivity*** 94.7 Magnet Weight 20 oz Gap Height .24", 5.99mm Voice Coil Diameter 1.5", 38.1mm THIELE & SMALL PARAMETERS Resonant Frequency (fs) 111Hz DC Resistance (Re)
  • Page 4 STANDARD SERIES 10" 12" EPA-S2510 EPA-S2510 SPECIFICATION Nominal Basket Diameter 10", 254mm Nominal Impedance* 8 ohms Power Rating** 275W Resonance 60Hz Usable Frequency Range 70Hz-3.7kHz Sensitivity*** Magnet Weight 56 oz Gap Height .39", 10.01mm Voice Coil Diameter 2.5", 63.5mm THIELE & SMALL PARAMETERS Resonant Frequency (fs) 60Hz DC Resistance (Re)
  • Page 5 STANDARD SERIES 15" EPA-S3015 EPA-S3015 SPECIFICATION Nominal Basket Diameter 15", 381mm Nominal Impedance* 8 ohms Power Rating** 425W Resonance 43Hz Usable Frequency Range 44Hz-2.5kHz Sensitivity*** Magnet Weight 80 oz Gap Height .39", 10.01mm Voice Coil Diameter 3.0", 76.2mm THIELE & SMALL PARAMETERS 43Hz Resonant Frequency (fs) DC Resistance (Re)
  • Page 6 GUITAR 12" EGTR-S1712-8 EGTR-S1712-8 SPECIFICATION Nominal Basket Diameter 12", 305mm Nominal Impedance* 8 or 16 ohms Power Rating** Resonance 85Hz Usable Frequency Range 80Hz-4.5kHz Sensitivity*** 100.8 Magnet Weight 38 oz Gap Height .32", 8.00mm Voice Coil Diameter 1.75", 44.5mm THIELE & SMALL PARAMETERS 85Hz Resonant Frequency (fs) DC Resistance (Re)
  • Page 7 1 3/8" 18 NEF ext. OEM INFORMATION/CAB DESIGN Eminence is pleased to provide turn-key manufacturing for all your enclosure needs. We specialize in taking your design from start to finish. From woodworking, to crossovers, HF products and cosmetics, you can...
  • Page 8 All speakers are tested at 1W/1M using a variety of test set-ups for the appropriate impedance | LMS using 0.25" supplied microphone (software calibrated) mounted 1m from wall/baffle | 2 ft. X 2 ft. baffle is built into the wall with the speaker mounted flush against a steel ring for minimum diffraction | Hafler P1500 Trans-Nova amplifier | 2700 cu.ft.
