Axon Synapse 2AS12 Technical Manual

Dual 12bit composite decoder with 5 line comb filter and frame synchronizer

Advertisement

Quick Links

2AS12
Dual 12bit composite decoder with 5 line
Comb filter and frame synchronizer
____________________________________________

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Synapse 2AS12 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Axon Synapse 2AS12

  • Page 1 2AS12 Dual 12bit composite decoder with 5 line Comb filter and frame synchronizer ____________________________________________...
  • Page 2 TECHNICAL MANUAL 2AS10 Dual 12 bit composite decoder with 5 line Comb filter and frame synchronizer. Lange Wagenstraat 55 NL-5126 BB Gilze The Netherlands Phone: +31 161 850 450 Fax: +31 161 850 499 E-mail: Info@axon.tv Web: www.axon.tv...
  • Page 3 ● NEVER operate this product in an explosive atmosphere. Warranty: Axon warrants their products according to the warranty policy as described in the general terms. That means that Axon Digital Design BV can only warrant the products as long as the serial numbers are not removed.
  • Page 4: Table Of Contents

    Table of Contents Chapter 1 Introduction to Synapse An introduction to Synapse Local Control Panel Remote Control Capabilities Introduction to TWINS Chapter 2 Unpacking and Placement Unpacking Placing the card Chapter 3 A Quick Start When powering-up Default settings Changing parameters and settings Front Panel Control Example of changing parameter using Front Panel control...
  • Page 5: Introduction To Synapse

    High density, intuitive operation and high quality processing are key Synapse features of this system. Synapse offers a full range of converters and processing modules. Please visit the AXON Digital Design Website www.axon.tv to obtain the latest information on our new products and updates.
  • Page 6 • Superb flexibility for the customer: TWINS and other Synapse cards can be housed independently or in the same Synapse frame. TWINS is an important enhancement of AXON’s Synapse range and is another example of how AXON translates future proof and customer compatibility into products.
  • Page 7: Unpacking And Placement

    2 Unpacking and Placement Unpacking The Axon Synapse card must be unpacked in an anti-static environment. Care must be taken NOT to touch components on the card – always handle the card carefully by the edges. The card must be stored and shipped in anti-static packaging. Ensuring that these precautions are followed will prevent premature failure from components mounted on the board.
  • Page 8: A Quick Start

    3 A Quick Start When Powering-up On powering up the Synapse frame, the card set will use basic data and default initialisation settings. All LEDs will light during this process. After initialisation, several LEDs will remain lit – the exact number and configuration is dependant upon the number of inputs connected and the status of the inputs.
  • Page 9: Front Panel Control

    Example of With the display as shown below changing parameters using RRC18 [Select Card] front panel control >S01=2AS12 Pressing the ► selects the 2AS12 in frame slot 01. The display changes to indicate that the 2AS12 has been selected. In this example the Settings menu item is indicated.
  • Page 10: Synapse Setup Software

    Synapse Setup Software can be used to change the settings of Synapse Setup Synapse modules from a PC, either locally or remotely. The software Software enables communication based on TCP/IP between the Setup PC and Synapse frames/modules. Each Synapse frame is addressed through its rack controller’s unique IP address, giving access to each module, its menus and adjustment items.
  • Page 11: The 2As12 Card

    See chapter 10 for connections. Miscellaneous The 2AS12 cards fit into the Axon SFR04 & SFR18 racks. LEDs at the front of the board indicate the presence of an Input signal, Connection & Processor Errors. The 2AS12 can be controlled by Axon Synapse set-up software.
  • Page 12: Settings Menu

    5 Settings Menu Introduction The settings menu displays the current state of each setting within the 2AS12 and enables the item to be changed or adjusted. Settings can be changed using the front panel of the Synapse frame (SFR18, SFR08 or SFR04) or Synapse Setup software. Please refer to chapter 3 for information on the Synapse front panel control and Synapse Setup software.
  • Page 13 Ref-Input This setting allows the user to determine which reference input is used to lock the 2AS12. Input 1 is the uppermost input of on the RRC18 rack controller connection panel at the rear of the SFR18. 1 and 2 are the options. The SFR04 has only one reference input.
  • Page 14 In 625/50 the adjustment range of V_Delay is 0-624 lines (one TV frame). In 525/60 the adjustment range is 0-524 lines (one TV frame). The default setting is 0 lines. The delay of the card is indicated by the tracking pulse on the BNC output.
  • Page 15 Off the vertical data is passed. Default setting is OFF. A_Adj-gain This is the adjustment menu for the MANUAL mode as set in the menu item gain mode.. The adjustable range is from 0.25 to 2.99 insetps of 0.1 The default setting is 1.00 A_Hue The selectable NTSC hue range is from –180 to +180 degrees.
  • Page 16 equipment that process wide screen manipulation, aspect ratio converters for example. B_VI-Ins: The Video Index data insertion recognises 16 different modes. These modes are divided into 2 groups, 4:3 and 16:9, each group having 8 sub-categories numbered 0-7. Valid data ranges are 4:3_0, 4:3_1, 4:3_2, etc., to 16:9_0, 16:9_1, 16:9_2 etc The default is Off B_Blank-ANC...
  • Page 17 B_Y-peaking B_Y-Peaking: this filter is to compensate the luma signal around the subcarrier frequency notation in dB. Selectable values, + 4.5, +1.25, 0, -1.25, -1.75, -3.dB. The default setting is 0dB. B-Freeze B_Freeze enables the capture of one Video Field. The settings of Freeze are On or Off.
  • Page 18: Status Menu

    6 Status Menu Introduction The status menu indicates the current status of each item listed below. Standard-Det 625 and 525 line standards can be detected as the valid input signal format – following are recognised as valid inputs: • NTSC-MJ •...
  • Page 19: Events Menu

    7 Events Menu Introduction An event is a special message that is generated on the card asynchronously. This means that it is not the response to a request to the card, but a spontaneous message. What is the Goal of The goal of events is to inform the environment about a changing condition on the card.
  • Page 20 What information is The message consists of the following items; available in an 1) A message string to show what has happened in text, for event? example: “INP_LOSS”, “REF_LOSS”, “INP_RETURN”. 2) A tag that also shows what happens, but with a predefined number: e.g.
  • Page 21 The Priority The priority is a user-defined value. The higher the priority of the alarm, the higher this value. Setting the priority to Zero disables the announcement of this alarm. Alarms with priorities equal or higher than the Error Threshold setting of the RRC will cause the error LED on the Synapse rack front panel to light.
  • Page 22: Led Indication

    8 LED Indication Error LED The error LED indicates an error if the internal logic of the 2AS12 card is not configured correctly or has a hardware failure. Input LED_A This LED indicated the presence of a valid video signal on the input.
  • Page 23: Block Schematic

    9 Block Schematic 2AS12 SDI OUT A-1 Frame CVBS IN A Composite Synchro- EDH INSERT SDI OUT A-2 Decoder nizer VI INSERT SDI OUT A-3 SDI OUT B-1 Frame CVBS IN B Composite Synchro- EDH INSERT SDI OUT B-2 Decoder nizer VI INSERT SDI OUT B-3...
  • Page 24: Connector Panel

    10 Connector Panel RJ-45 BPL11 RJ 45 FREEZE-1 FREEZE-2 TRACKING 1 TRACKING 2 SCHIELDING PIN 1 SCHIELDING PIN 2 RJ 45 DIN 41612 J1 = CVBS_A INPUT J2 = SDI_A_Out J3 = SDI_A_Out J4 = SDI_A_Out J5 = RJ45 J6 = CVBS_B INPUT J7 = SDI_B_Out J8 = SDI_B_Out...
  • Page 25 J9 = SDI_B_Out !Unused inputs and outputs must be terminated with the correct impedance!
