Summary of Contents for Temperature Guard CM705E
- Page 1 Operation Manual For model CM705E or CM705E-W (rev 8 or higher) Table of Contents Index Page Number General Description and part numbers Installation Wiring Diagram Testing the programmed numbers Sensors Checking Status Daily Status What is an alarm condition?
- Page 2 General Description The CM705E is an environmental monitor with built in Ethernet (wired or wireless) and Cellular alarming and reporting capabilities. This unit can monitor up to eight temperature sensors, power, and four dry contact inputs, in addition to its optional built in temperature and humidity sensor.
- Page 3 Select a location with access to cellular signal, power and Ethernet if purchased with the network adapter. Use only the provided 5VDC power adapter. Wire all inputs to be used. Wiring diagram below. CM705E Wiring Diagram (side view of enclosure)
- Page 4 At boot up, the unit will search for attached sensors. The unit will never alarm on a sensor it does not detect at boot up. If you need to add a sensor, turn off the CM705E, wire in the sensor, then turn the unit back on. If you need to remove a sensor, remove the wires from the unit, and reboot the unit.
- Page 5 LCD Screen and Cancel Alarm Push button The Cancel Alarm push button, located on the top of the unit, is used to silence the buzzer during alarms and scroll through inputs for information. Buzzer will re-alarm if reminders are enabled. If one or more sensors are in alarm, the in alarm sensor(s) will be shown after the second screen, then all others not in alarm in numerical order.
- Page 6 The dry contact inputs are on the right side of the display of the main screen. The closed square means the input is closed, an open square is an open input. Top square is Input #1, second is Input #2 etc. If the input is set to water sensor, the open square is no water detected, the closed square is a wet condition.
- Page 7 The CM705E must be plugged in and network cable attached to the network. Turn the Guard off. Hold down the Alarm Cancel button and turn the CM705E on. The screen will display Release Push button. Release it before the 5 second count- down.
- Page 8 Part Numbers Model Number Description CM705E-AT-R3 Wired Ethernet model shipped without a sim card. Unit will work on the AT&T network. Wired Ethernet model shipped without a sim card. Unit CM705E-VZ-R3 will work on the Verizon network only. CM705E-W-AT-R3 Wireless Ethernet model shipped without a sim card.
