Summary of Contents for Xo XOGRIDDLE30 Series
- Page 1 XO PRO-GRADE GRIDDLE MODEL XOGRIDDLE30_...
- Page 2 REGISTRATION HELPS YOU BY - Ensuring warranty coverage should you need service Providing ownership verification for insurance purposes Let’s XO notify you in the event of product changes or recalls. WARNING DANGER If you smell gas: - Do NOT store or use gasoline or other flammable liquids or...
- Page 3 these are the models covered in this book XOGRIDDLE30N XOGRIDDLE30L record your serial number here in case you need it later...
-
Page 4: Where Things Are
9 - 2 2 Product Dimensions Cutout Dimensions Location Venting Gas and Electrical Connections Operating 23 - 2 6 Meet your XO Controls Lighting the Burners Griddle Safety Tips Maintenance 27 - 3 0 Care of Stainless Steel General Cleaning... -
Page 5: Installation Checklist
National Electrical Code. Appliance must be connected to a GFI protected three prong outlet. Minimize the length of your gas run - XO recommends a minimum 3/4” ID gas supply line. All joints and connections must be leak tested prior to first use. -
Page 6: Product Specifications
product specifications OVERALL PRODUCT WIDTH 30” OVERALL PRODUCT DEPTH 28 3/4” OVERALL PRODUCT HEIGHT 13 3/6” CUTOUT WIDTH 28 3/4” CUTOUT DEPTH 24” CUTOUT HEIGHT 10 7/8” COOKING SURFACE WIDTH 28” COOKING SURFACE DEPTH 18” COOKING AREA TOTAL 504 sq in FUEL (Specify) Natural Gas* - or - Propane 2.08 mm... - Page 7 notice: commonwealth of massachusetts Massachusetts requires all gas be installed using a plumber or gas fitter carrying the appropriate Massachusetts license. All permanently installed natural gas or propane installations require a “T” handle type manual gas valve be installed in the gas supply line to this appliance. This does not apply to portable propane installations using a 20lb cylinder.
- Page 8 your safety matters Read this manual carefully and completely before installing or using your griddle to reduce the risk of fire, burn hazard or other injury and to ensure proper installation and servicing. Never use rusted, dented or damaged propane cylinders. Never store additional or empty propane cyliners in the griddle cabinet or in the vicinity of this or any other gas or electrical appliance.
-
Page 9: Product Dimensions
product dimensions SIDE FRONT 21-1/2” 546mm 24-5/8” 625mm 30” 28-3/4” 760mm 730mm XOGRIDDLE30 BOTTOM please read and follow all safety instructions... -
Page 10: Cutout Dimensions
- use the smaller dimension cutouts: 10 7/8” H x 24” D x 28 3/4” W COMBUSTIBLE CONSTRUCTION When installing your XO griddle in a location built using combustible materials such as wood or vinyl - you must install the XOG30JACKET liner first - use the larger cutout dimensions: 12”... - Page 11 Keep all gas supply lines as short and straight as possible. Piping long distances, changes in direction and reduced pipe diameters all contribute to press drop and reduced performance of your outdoor cooking appliances. XO Recommends a minimum 3/4” ID gas supply line. ON THE LEVEL During installation, using a carpenter’s spirit or electronic level make certain you griddle is...
-
Page 12: Overhead Clearance
(continued) NON-COMBUSTIBLE CONSTRUCTION Your XO griddle is designed easy placement in a non-combustible structure such as an island or similar outdoor structure built of masonry or Hardibacker. In such an installation, the griddle has a perimeter flange that rests on the countertop allowing the unit to simply slide into place in the prepared cutout. - Page 13 (continued) WIND | COMBUSTION AIR | HEAT Your XO griddle is a high performance cooking machine. As such it requires plenty of air to support combustion at the burners. Air flow is designed to enter at the front around the control panel and super-heated air is exhausted through the long horizontal vent at the back of the griddle.
-
Page 14: Important Note
venting your island Proper venting is required for all island or counter construction to prevent the accidental formation of pockets of flammable gas. This requirement applies to both Natural Gas and Propane installations. There should be at least 2 vents per side, one mounted near the top of the counter, the second must be installed a minimum of... -
Page 15: Gas Connections
PRESSURE REGULATOR CAN RESULT IN FIRE AND SERIOUS PERSONAL INJURY AND WILL VOID THE WARRANTY XO cooking appliances are factory set to use either propane (LP) or natural gas (NAT). It is critical that the gas you use matches that which the grill was set up for. You can verify that by checking the rating plate. - Page 16 WARNING Regulators set for Natural Gas and LP (Liquid Propane) are NOT interchangable. Use ONLY the regulator supplied with your XO. NEVER connect to an unregulated gas supply. Always use a professional to connect to your natural gas supply.
- Page 17 connecting to a permanently plumbed gas line Follow the example diagrams below to connect your griddle to a permanently plumbed system. For Natural Gas, use of a Stainless Steel Flexline is recommended to make the final connection For a hard piped LP (propane) system attaching to a portable cart, a 12’ XOLQD detachable supply hose is recommended.
- Page 18 WARNING Regulators set for Natural Gas and LP (Liquid Propane) are NOT interchangable. Use ONLY the regulator/hose assembly supplied with your XO. Always turn valve OFF when not in use. Do not store a spare LP-gas cylinder under or near this appliance.
- Page 19 gas connections - lp (propane) Connect and tighten the swivel nut of the gas hose to the griddle manifold connection located at the right, rear of the unit. The connection must angle down, away from the griddle to keep the gas line away from the heat generated during use. CONNECTING THE TANK TO THE REGULATOR Turn all control knobs to the OFF position.
- Page 20 fuel type conversion All units ship set up at the factory for either Natural Gas or Propane. They can be converted if required, however this conversion should only be undertaken by a qualified technician experienced in gas appliance repair and service. All the necessary components for the conversion can be found in kit form along with specific instructions to complete the conversion.
- Page 21 electrical hook up and safety WARNING - ELECTRICAL GROUNDING Product installation must meet local electric codes or, in the absence of local codes, the latest edition of the National Electrical Code ANSI/NFPA No. 70 or the Canadian Electrical Code CGA 1.662005. Use only a Ground Fault Interrupter (GFI) protected circuit with this outdoor cooking appliance.
-
Page 22: Electrical Wiring
electrical wiring Griddle burner ignition does not require electricity, however the control LED light do. Your griddle control lighting is powered by a 12VDC transformer which must be plugged into a properly grounded GFI protected outlet. If you are uncertain if an existing outlet meets this requirement, consult a licensed electrician. - Page 23 Get ready for a unique grilling experience with your new XO Griddle, packed with features that will enhance your outdoor kitchen and expand your culinary boundaries. PRO-GRADE 304 Stainless Steel Welded Construction Massive, Solid 304 Stainless Steel Cooking Surface Twin 18,000 BTU Stainless Steel “U”...
- Page 24 controls LIGHTS ON/OFF BUTTON LEFT RIGHT BURNER BURNER CONTROL CONTROL ignition OFF POSITION LIGHTING/HIGH POSITION KNOBS TURN ON COUNTER CLOCK WISE AND SHUT OFF CLOCKWISE. please read and follow all safety instructions...
- Page 25 important griddle safety tips NEVER leave the griddle unattended, Before the first use - you MUST lift the griddle plate and ensure that all tie downs have been removed from the burners. These are just to prevent shifting during shipping. Avoid loose fitting clothing while operating your griddle.
-
Page 26: Lighting The Burners
lighting the burners LIGHTING WITH FLAME THROWER IGNITION OFF POSITION LIGHTING/HIGH POSITION To light a burner, remove the lid and open the gas isolation or tank valve. Push and hold the control knob in - this will start the flow of gas. Wait 3 to 5 seconds. While holding the knob in, turn the knob to the left to the 9 o’clock position An audible click will sound and the burner will ignite. -
Page 27: Maintenance
CARE OF STAINLESS STEEL XO outdoor kitchen products are precision crafted from high quality 304 Stainless Steel but to keep keep it looking and working its best, here are best practices for cleaning Stainless, • After each use, wipe down the exterior of the griddle to remove grease and splatters. -
Page 28: Before The First Use
CLEANING THE GRIDDLE Regular cleaning and care for your Xo Griddle will keep it looking and functioning its best. The cook surface is designed to hold a fine layer of cooking oil creating a ‘seasoning’ on its surface. -
Page 29: Cleaning The Burners
maintenance - burners WARNING WHEN YOUR GRIDDLE ARRIVES - THE BURNERS ARE SECURED IN PLACE BY CABLE TIES TO PREVENT DAMAGE IN SHIPPING. THESE MUST BE REMOVED PRIOOR TO INITIAL USE. WARNING: Before attempting any burner maintenance ensure the gas supply is OFF and all control knobs are in the OFF position. - Page 30 maintenance WARNING Spiders and small insects can spin webs and nest in the griddle burner venturis which can obstruct gas flow, causing it to ignite outside the burner tube. This type of “FLASHBACK FIRE” can cause serious damage to the griddle and create a dangerous operating condition.
-
Page 31: How To Obtain Parts
how to obtain parts Parts not under warranty can be ordered directly on our website www.xoappliance.com. Parts under warranty can be obtained by contacting our service department through our website or by call 973-403-8900. You will need the following information found on the Model Name Plate, located on the drip tray of your unit. - Page 32 parts...
- Page 33 service & maintenance record DATE OF INSTALLATION: DATE OF SERVICE: WORK PERFORMED: DATE OF SERVICE: WORK PERFORMED: DATE OF SERVICE: WORK PERFORMED: DATE OF SERVICE: WORK PERFORMED: DATE OF SERVICE: WORK PERFORMED: DATE OF SERVICE: WORK PERFORMED: DATE OF SERVICE: WORK PERFORMED: DATE OF SERVICE: WORK PERFORMED:...
- Page 34 notes...
- Page 35 we’ve got your back WARRANTY TERMS FOR Stainless Steel Outdoor Cooking Appliances griddle...
- Page 36 now you’re cooking 973-403-8900 OR VISIT US ONLINE WWW.XOAPPLIANCE.COM...
