Summary of Contents for ICS Lifeline M95-600 Series
- Page 1 INSTRUMENTATION AND CONTROL SYSTEMS, INC. UNINTERRUPTIBLE POWER SYSTEM DRAWING NO. 8060180 MODEL M95-600 SERIES ISSUED: 5-21-07 PART NO. 9300057 REV B: RELEASED INSTRUMENTATION AND CONTROL SYSTEMS INC. 520 WEST INTERSTATE ROAD ADDISON, ILLINOIS 60101 USA TEL (630) 543-6200 FAX 630-543-6244...
- Page 2 Proprietary Notice This equipment was designed and manufactured under several patents owned by ICS, Inc. The user of these patented circuits or reproductions of the drawings, schematics, etc. may not occur except by written permission from ICS, Inc.
- Page 3 Mounting This unit is designed for either shelf or wall mounting. A minimum of 6” per side and 2” above the cabinet is necessary for the cooling and mounting purposes. Consideration should be given to the proximity of the incoming and output power.
-
Page 4: Description Of Operation
2.4.2 After the UPS starts up, verify that all three LED indicators on the front panel are illuminated. 2.4.3 Turn on the battery circuit breaker (handle in the up position). The characteristic sound of the main transformer in the UPS may change somewhat due to charging of the battery system. - Page 5 Operation From AC Input When the line power is normal, the static switch connects the line to the load through an inverter which filters and regulates the power to the load. The inverter also charges the battery. It is also possible to operate the system without the use of the battery. In this case, the unit provides excellent regulation and filtering of the incoming AC line but without battery backup capability.
-
Page 6: Maintenance
Maintenance CAUTION: Disconnect AC & DC power before performing any maintenance. The unit is basically free from any maintenance except for keeping it clean and dirt- free. If the unit is mounted in a dirty environment it may well be necessary to vacuum it occasionally to keep it free from lint and dirt particles. - Page 7 TABLE 4.1: BASIC TROUBLESHOOTING GUIDE CHECK OR CHECK BATTERY REPLACE PRINTED PROBLEM REPLACE F1 CIRCUIT BREAKER CIRCUIT BOARD OTHER No AC output when commercial power is present No AC output when commercial power Check Battery is not present Battery does not charge Check Battery Output voltage low...
-
Page 8: Warranty
( the time and place to be mutually agreed upon and ICS Inc. at its option, to be present thereat) and if the apparatus is found not to be in conformity with this warranty, ICS Inc. will, at its option, and expense either repair the same or supply a replacement therefore. - Page 9 There is no further warranty, either express or implied, in connection with the design, sale or use of any ICS, Inc.’s products except as to title; and ICS, Inc.’s liability to its warranty shall in no event exceed the cost of correcting defects in the apparatus sold.
-
Page 10: Specifications
TECHNICAL INFORMATION FOR MODEL 9300057 UPS Specifications Input Power DC: 48VDC nominal, 55AH sealed lead-acid battery Charging Current: 2ADC Input Power AC: 120VAC, +10/-15%, 60Hz, 8AAC nominal, single phase Rated Output Power: 120VAC, 60Hz, 5.0AAC (600VA/W), single phase Load Power Factor: 0.8 to 1.0 Output Voltage Regulation: +/-3% Output Waveform: Sinusoidal with 5% maximum total harmonic distortion Efficiency: Up to 85% at nominal line, battery voltage and full load... - Page 11 BATTERY WIRES 8GA AWG MIN. ALL OTHER WIRES 18GA AWG MIN. * TOTAL UPS LOAD WITH BATTERY BACKUP: 5AAC MAX. 2 HOURS BACKUP TIME AT 5.0 AAC OUTPUT 4 HOURS BACKUP TIME AT 2.5AAC OUTPUT ** CONNECT TO EARTH GROUND...
-
Page 12: Cabinet Dimensions
CABINET DIMENSIONS... - Page 13 NOTES: 1. DIMENSIONS ARE FOR REFERENCE ONLY 2. DESCRIPTION: UNINTERRUPTIBLE POWER SUPPLY – LIFELINE SERIES 3. SPECIFICATIONS: WEIGHT: 120 LBS. PLUS EXTERNAL BATTERIES AND RACK INPUT POWER DC: 48VDC NOMINAL, 55AH BATTERY INPUT POWER AC, 60HZ, 8AAC, NOMINAL REGULATED OUTPUT POWER: 120VAC, 60HZ, 5.0AAC OUTPUT WAVE FORM: SINUSOIDAL 5% MAX TOTAL HARMONIC DISTORTION CHARGING CURRENT: 2ADC EFFICIENCY: UP TO 85% NOMINAL LINE, BATTERY VOLTAGE AND FULL LOAD...
- Page 14 OPERATING INSTRUCTIONS FOR UPS PART NO. 9300057 DRAWING N0. 8060181 ISSUED 06/16/94 REV. A: RELEASED Mount this sheet in a frame and locate it adjacent to the unit. Refer to Drawing/Manual No. 8060180, issued 06/16/94 for complete information. 1. Ratings: Input AC Power: 120VAC, 60Hz., 8AAC nominal Input DC Power: 48VDC, 55AH Battery Output AC Power:120VAC, 60Hz., 5AAC...
