MU1 | User Manual TABLE OF CONTENT Introduction ............................. 4 1.1 Packing List ............................4 1.2 Overview ............................5 Safety Guidelines ..........................6 Installation and Operation ......................8 3.1 Mounting and Adjustment......................8 3.2 Power Supply and Manual Motor Control ................11 3.3 Computer-Controlled Operation .....................
MU1 | User Manual INTRODUCTION The Micromanipulator has been developed within the last decade in close cooperation with leading scientists, who are specialized in microsensor measurements. Please read carefully this manual before starting to use the device. Packing List Please check that all following items are included in your package: •...
MU1 | User Manual Overview Figure 2: Overview of the micromanipulator The Micromanipulator has been developed for performing automized microprofile measurements with microsensors. It consists of a compact manual micromanipulator for the x-, y-, and z-axis, supplemented with a high-precision motorized slide (0.1 µm resolution) for the z-axis.
MU1 | User Manual SAFETY GUIDELINES PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE STARTING TO WORK WITH THIS DEVICE • Before connecting the device to the mains voltage, please ensure that the operating voltage stated on the power supply corresponds to the mains voltage.
Page 7
MU1 | User Manual THIS DEVICE MAY ONLY BE OPERATED BY QUALIFIED PERSONAL: This device is only intended for use in the laboratory by qualified personal according to this instruction manual and these safety guidelines! Keep this device out of the reach of children!
Handle with care! Mounting and Adjustment Please follow these steps for mounting the Micromanipulator MU1: 1. Release the tilting screws and open the tilting mechanism. Screw the...
Page 9
MU1 | User Manual 3. Fasten the tilting screws. 4. By releasing the tilting screws and the mounting screw, the mounting angle and the position of the micromanipulator can be adjusted. Ensure to fasten the screws carefully, if the desired position is reached.
MU1 | User Manual Power Supply and Manual Motor Control 1. Ensure that the manual control knob is in its centre position (feel the slight "click"!). Otherwise the motor might start moving, when the power supply is plugged in. 2. Plug in the power supply connector.
Page 12
MU1 | User Manual 4. Turn the control knob in order to move the motor. Clockwise turning lets the motor move down, counter-clockwise turning will let move it up. The motor speed is proportional to the turning angle. In order to stop again, turn the knob back into its centre position.
MU1 | User Manual MAINTENANCE PRECAUTION: The performance of the depends strongly on the conditions of its precision mechanics. Ensure that its parts are kept free from dirt, dust, liquids and other contaminants! Be aware, that aquariums aerated with bubble stones will deposit a fine spray of water drops in the surrounding.
Page 15
Under humid conditions you should leave the power supply connected (green LED on) even if you do not perform any measurements. That way the motor will provide a constant heating within the housing of the MU1, lowering the risk of water condensation.
MU1 | User Manual TECHNICAL SPECIFICATIONS Feature Specification Dimensions 275 mm x 95 mm x ca. 220 mm Weight 1.9 kg Travel range x-axis (manual) 25 mm Travel range y-axis (manual) 20 mm Travel range z-axis (manual) 37 mm + 10 mm fine adjustment...
Page 17
MU1 | User Manual Control software Freeware download Profix: https://www.pyroscience.com Mounting adapter M6 screw, 10 mm length Sensor mount Clamp for microsensors from 6.5 mm to 12 mm Adapter for thin sensors Clamp for two microsensors from 0.5 mm to 3 mm...
