AL-512-00-902 IP-EnOcean-Bridge PoE V1
Ethernet to EnOcean Interface – EnoDisc
EnOcean 902 MHz
Part no. 12395
Version 1.12, valid since FW/HW 2.0 / 1.0
© DEUTA Controls GmbH
14.07.2021
Technical data might change
Page 1 of 32
Paffrather Str. 140, 51465 Bergisch Gladbach
Hauptstraße 76, 32479 Hille
info@deuta-controls.de;
www.deuta-controls.net
®
Tel.:+49 2202 285 57- 61
Tel: +49 5734 51466 - 0
Fax:+49 5734 51466 - 28
Advertisement
Table of Contents
Related Manuals for DEUTA Controls EnOcean EnoDisc
Summary of Contents for DEUTA Controls EnOcean EnoDisc
- Page 1 Ethernet to EnOcean Interface – EnoDisc ® EnOcean 902 MHz Part no. 12395 Version 1.12, valid since FW/HW 2.0 / 1.0 © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021 Hauptstraße 76, 32479 Hille...
- Page 2 Manual by third parties that violate pertinent copyright provisions is prohibited. Reproduction, translation, electronic and phototechnical filing/archiving (e.g., photocopying) as well as any amendments require the written consent of DEUTA Controls GmbH, Bergisch Gladbach, Germany. Non-observance will involve the right to assert damage claims.
-
Page 3: Table Of Contents
Repeater / Action ....................12 7.3.3 Repeater / Criterium ..................13 7.3.4 Repeater / Criterium value ................13 © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021 Hauptstraße 76, 32479 Hille Tel: +49 5734 51466 - 0 Technical data might change info@deuta-controls.de;... - Page 4 FCC (United States) Regulatory Statement ..............28 ISED Regulatory Statement ..................28 Dimensions / drawings ....................30 Ordering information ....................31 Revision history ......................32 © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021 Hauptstraße 76, 32479 Hille...
-
Page 5: Validity Of This Documentation
At the same time, data is transferred to / from an automation system via the integrated Ethernet interface. © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021... -
Page 6: External Product Interface
Ensure the AL-512-00-902 IP-EnOcean-Bridge PoE V1 / EnoDisc ® is mounted on a non-conductive surface. If it is not, performance may be adversely affected. © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021 Hauptstraße 76, 32479 Hille... -
Page 7: Technical Data
PoE (nom. 48 V DC) Power consumption Typ. 0.7 W, max. 1.o W Table 5: Technical data / power supply © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021 Hauptstraße 76, 32479 Hille... -
Page 8: Environmental Conditions
EN/IEC 61000-4-5 EN/IEC 61000-4-6 EN 55032 :2012/AC :2013 EN 62368-1:2014 + AC:2015 Table 9: Technical data / standards and guidelines © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021 Hauptstraße 76, 32479 Hille... -
Page 9: Functional Description In Detail
As an example, the following picture shows data received via EnOcean, using the software tool Dolphin View. Same data will be transferred by Ethernet. © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021 Hauptstraße 76, 32479 Hille... -
Page 10: The Enodisc ® Webserver
EnOcean data received and send by the EnoDisc can be analyzed by the EnOcean monitor on this page. For each message, following data are recorded in a new line: © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021... -
Page 11: Repeater" / Enocean Repeater Configuration
This mode is a selective repeater mode which allows to define which kind of message should be repeated. More than one rule can be defined. © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021... -
Page 12: Repeater / Action
(“Repeat”) or explicitly avoid (“Do not repeat”) to repeat the selected telegram type. Figure 2: Repeater mode selection / Action force or block © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021... -
Page 13: Repeater / Criterium
(EURID) will be repeated. Figure 3: Repeater / Criterium 7.3.4 Repeater / Criterium value Depending on the selected criterium, a value has to be selected / entered: © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021 Hauptstraße 76, 32479 Hille... -
Page 14: Table 10: Repeater Criterium
Minimum signal strength (dBm) Source address EURID in HEX (0xnnnnnnnn) Table 10: Repeater criterium Figure 4: Repeater / Value dropdown for telegram type © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021 Hauptstraße 76, 32479 Hille... -
Page 15: Add Or Remove Rules For The Repeater
Figure 6: Repeater criterium value source / destination address 7.3.5 Add or remove rules for the repeater Using the “+” and “-“ buttons, you can add or remove rules from the list. © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021... -
Page 16: Setup" / Ethernet And Enocean Interface Properties
System time of the PC = hh:mm Password to enter = mm:hh Note: The colon is part of the password and must be entered. Figure 7: Password protection © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021 Hauptstraße 76, 32479 Hille... -
Page 17: Device Properties
Sensitivity of EnOcean receiver: -90 .. -102 dbm (default: -96 dbm) • 7.4.2.1 Freetext To identify the device, a free text can be entered (up to 19 characters). © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021 Hauptstraße 76, 32479 Hille... - Page 18 To store, the according button has to be pressed once. All three parameters will be changed at the same time. Figure 9: IP address selection / static or DHCP © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021...
- Page 19 Figure 10: Set EnOcean receiver sensitivity 7.4.2.5 EnoDisc Firmware update Firmware of the device can be updated at any time via Ethernet. Push the button “Firmwareupdate” to start. © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021 Hauptstraße 76, 32479 Hille...
- Page 20 Figure 12: EnoDisc entering bootloader mode When bootloader mode has been started, the page will show the actual properties, and also the actual firmware version. © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021...
- Page 21 If a new firmware should be loaded, select the new bin-file from your PC, and push the button “Update”. To exit from the bootloader, you can push “Cancel” at any time. Figure 14: Start firmware update © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021...
- Page 22 You can check for the new SW version in the table shown on the page “Home”. Figure 16: Firmware updated with success © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021...
-
Page 23: Supported Eep's (Enocean Equipment Profiles)
EEP, since contents of the messages are not interpreted. As a result, the EnoDisc is in principle a transparent bi-directional gateway between EnOcean and Ethernet. © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021... -
Page 24: Installation And Maintenance / Service
Check if you should drill a hole fir the Ethernet cable in advance, as shown in the following picture. © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021... - Page 25 Connect / mount the two housings with a rotation of approx. 10°. Use an LSA tool to setup the electrical connection. Take care to connect cable according to the colours as marked on the connector. © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021...
- Page 26 Page 26 of 32 Connect the controller board of the EnoDisc ® with the Connector board. Close the housing. © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021 Hauptstraße 76, 32479 Hille Tel: +49 5734 51466 - 0 Technical data might change info@deuta-controls.de;...
-
Page 27: Device Labels
IP-ENOCEAN-BRIDGE POE / LSA / EnoDisc / PN: 12395 Made in Germany MAC-Address: 00:00:00:00:00:00 SN: 0000026177 © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021 Hauptstraße 76, 32479 Hille Tel: +49 5734 51466 - 0 Technical data might change info@deuta-controls.de;... -
Page 28: Fcc (United States) Regulatory Statement
1 . This device may not cause interference. 2. This device must accept any interference, including interference that may cause undesired operation of the device. © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021... - Page 29 1. L’appareil ne doit pas produire de brouillage; 2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021...
-
Page 30: Dimensions / Drawings
AL-512-00-902 IP-EnOcean-Bridge PoE V1 Product manual Page 30 of 32 12 Dimensions / drawings Diameter: 110 mm; Height: approx. 38 mm when mounted © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021 Hauptstraße 76, 32479 Hille... -
Page 31: Ordering Information
0°C - 45°C storage temp.: -20°C - 70°C, humidity: 5 - 90% RH, non- condensing; connector: LSA IDC connector; © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021 Hauptstraße 76, 32479 Hille... -
Page 32: Revision History
FCC / IC logos from label, added 11 for ISED ------------ End of document ----------- © DEUTA Controls GmbH Paffrather Str. 140, 51465 Bergisch Gladbach Tel.:+49 2202 285 57- 61 14.07.2021 Hauptstraße 76, 32479 Hille Tel: +49 5734 51466 - 0 Technical data might change info@deuta-controls.de;...
