Summary of Contents for Awoco TOP30A
- Page 1 IN YOUR KITCHEN 48” 36” 30” GAS RANGETOP INSTALLATION GUIDE AND USER MANUAL APPLICABLE MODELS: TOP30A, TOP36A, TOP48A.
-
Page 2: Important Note
INSTALLATION GUIDE AND USER MANUAL Thank you for choosing Awoco products. We are very proud of our products and are completely committed to provide you with the best coo- king experience. Your satisfaction is our top priority. Please read through this manual prior to installation, it contains important information to help you properly use &... -
Page 3: Important Instructions
Features and specifications are subject to change at any time without notice. Visit awoco.com for the most up-to-date information. To ensure the safe use of Awoco equipment, please take note of the following types of highlighted information throughout this guide: •... -
Page 4: What To Do If You Smell Gas
By opening a window, using a ventilating hood or fan can minimized the exposure to these substances. Proper Installation Awoco gas rangetop must be properly installed and grounded by a qualified technician in accordance with the National Fuel Gas Code ANSI Z223.1-latest edition, and the National Electrical Code ANSI/NFPA No.70-latest edition. - Page 5 INSTALLATION GUIDE AND USER MANUAL WARNING! • DO NOT store any flammable materials such as paper, cloth, plastic and flammable liquids on or near the rangetop. • Do not store explosives, such as aerosol cans, on or near the rangetop. •...
-
Page 6: Installation Instructions
INSTALLATION GUIDE AND USER MANUAL Installation Instructions Be sure the rangetop is professionally installed and grounded by a qualified technician. It is the responsibility of the technician to make certain that your rangetop is properly installed. Damages caused by improper installation are not covered by the warranty. -
Page 7: Installation Clearances
INSTALLATION GUIDE AND USER MANUAL GAS LINE SHUT-OFF VALVE • To reduce the possibility of gas leaks, apply Teflon tape or a thread compound approved for use with LP or Natural gases to all threaded connections. • Install a manual gas line shut-off valve in the gas line in an easy-to-access location outside the range in the gas piping external to the appliance for the purpose of turning on or shutting off gas to the appliance. -
Page 8: Electrical Requirements
36” (91.4 cm) counter height. ELECTRICAL REQUIREMENTS Awoco Gas Rangetop requires 110 volts, 50/60 Hz electrical supply to operate the ignition system. The power cord is a 3-prong grounding plug. The plug must be plugged into a mating outlet. -
Page 9: Product Dimension
INSTALLATION GUIDE AND USER MANUAL PRODUCT DIMENSION Make sure the counter top cutouts follow the dimensions given in the illustration below. The material of the cabinet below the rangetop must be non-combustible. 30” Rangetop 36” Rangetop... - Page 10 INSTALLATION GUIDE AND USER MANUAL 48” Rangetop CONNECTING THE GAS TO THE RANGETOP This rangetop is designed to be used with natural gas or liquid propane gas and operate at a pressure of 4” of water column on natural gas or 10” of water column on propane gas (LP). ...
-
Page 11: Surface Burner Ignition
INSTALLATION GUIDE AND USER MANUAL In an easily accessible location, install a service manual gas shut-off valve. Be sure everyone operating the rangetop knows where and how to shut off the gas supplied to the rangetop. Use a flexible gas line to connect to the 1/2” fitting located at the bottom of the rangetop. When all connections have been made, be sure all rangetop controls are in the off position and turn on the main gas supply valve. -
Page 12: Using The Griddle
INSTALLATION GUIDE AND USER MANUAL FOR THE MODELS WITH GRIDDLE (OPTIONAL) Before Using the Griddle: Clean the griddle thoroughly with warm, soapy water to remove dusts or any protective coating. Rinse with clean water and wipe off, dry with soft, clean and lint-free cloth. ... -
Page 13: Troubleshooting Tips
TROUBLESHOOTING TIPS Troubleshooting Issue Possible Cause Solution Check that the burner parts are clean, dry Burner parts or igniters may be wet, Burners will not light. and correctly assembled. Check that the dirty or misaligned. igniters are clean and dry. Top burner will not stay lit.
