Summary of Contents for LAEGENDARY LGD240 DUAL
- Page 1 TOUCH AC/DC FAST INPUT SCREEN CHARGE 3.2 COLOR LCD UP TO 3X FASTER...
-
Page 2: Table Of Contents
Batteries Info and Max Charge Current ..........9 Program for LiPo/Lilo/LiFe/LiHV ............10 Program for NiMH/NiCd ................11 Program for PB(lead-Acid) ..............12 Program for Smart Batteries ..............12 Main Menu ....................13 Settings ......................14 Monitor/Calibration ...................15 Memory ......................16 Error Information ..................17 Warranty Information ................18 www.LAEGENDARY.com... - Page 3 LAEGENDARY of any and all liability associated with its use. If you as the user do not accept liability of Usership, LAEGENDARY requests that you do not use this product. Do not open any of the enclosed materials.
-
Page 4: Introduction
Introduction INTRODUCTION Thank you for purchasing the LAEGENDARY LGD240 Dual charger. This charger features innovations that make charging batteries easier and safer than ever. If you have any questions or concerns about your charger, please contact our customer support team for fast, friendly answers and solutions. -
Page 5: Caution And Notes
Children require adult supervision while using this charger. www.LAEGENDARY.com... - Page 6 DO NOT expose the charger to water or moisture. ALWAYS store battery packs safely out of the reach of children and pets. If the charger power cord is damaged, it must be replaced by LAEGENDARY in order to avoid a hazard.
-
Page 7: Accesories
Accessories ACCESSORIES Balance Charging Place x1 Battery Case x1 Adaptor Board Set x2 Cable Set x2 AC Cord x1 Extra Cable x1 www.LAEGENDARY.com... -
Page 8: Specifications
Specifications SPECIFICATIONS Product Model LGD240 DUAL Power Distribution AC Input Voltage 100-240V DC Input Voltage 11-18V Charge power AC INPUT (CH1+CH2=150W) DC INPUT (120W*2) Charge current 0.1-10A*2 Discharge current 0.1-2A*2 Lipo/Lilo/LiFe/LiHV 1-6cells*2 NiCd/NiMH 1-15cells*2 2-20V*2 Smart Battery I/II/III*2 Net weight 1.1lb... -
Page 9: Batteries Info And Max Charge Current
Discharge Voltage: Cut o Level: 3.0V/cell or higher or higher Voltage Level: 3.8V/cell Voltage Level: 2.0V/cell LiFe Max Charge Voltage:4.35V/cell Max Charge Voltage:2.45V/cell Discharge Voltage: Cut o Level: 3.2V/cell Discharge Voltage: Cut o Level: 1.5V/cell or higher or higher www.LAEGENDARY.com... -
Page 10: Program For Lipo/Lilo/Life/Lihv
PROGRAM FOR LiPo/Lilo/LiFe/LiHV BATTERIES Example 1: LiPo Battery Charge Step1. Enter the Menu and select LiPo Battery Type (Image 1). Step2. Select “BALANCE CHARGE” mode and set the correct battery parameters (Image 2). LGD240 DUAL Image 1 Image 2 Image 3 NOTE: 1. -
Page 11: Program For Nimh/Nicd
PROGRAM FOR NiMH/NiCd BATTERIES Example 2: NiMH Battery Charge Step1. Enter the Menu and select NiMH Battery Type (Image 7) Step2. Select “CHARGE” mode and set the correct battery parameters (Image 8) LGD240 DUAL Image 7 Image 8 Image 9 NOTE: Image 9 shows charging parameters and graphic for NiMH charge current and voltage. -
Page 12: Program For Pb(Lead-Acid)
PROGRAM FOR PB(lead-Acid) BATTERIES Example 3: PB battery charge Step1. Enter the Menu and select PB Battery Type (Image 11) Step2. Select “CHARGE” mode and set the correct battery parameters (Image 12) LGD240 DUAL Image 11 Image 12 Image 13 Step 3: If you often use the same battery, please touch Save icon (Image 5) to enter into Save interface. -
Page 13: Main Menu
Main Menu MAIN MENU LGD240 DUAL Touch Screen 3.2 Inch Touch Screen Controller Security Settings Setting Battery Management, Checking Battery Capacity, Voltage, Balancer Monitor Memory: Save six operation data Memory Calibrate Charger Calibration www.LAEGENDARY.com... -
Page 14: Settings
Settings SETTINGS Step 1. Enter the Menu. Select Settings (Image 18), into set LGD240 DUAL interface (Image 19-21) Image 18 Set the volume of the buzzer. Keep Beep default: Middle, Low/Middle/High/O optional In this menu you can set the cuto input voltage of the power supply of the charger to protect your power supply. -
Page 15: Monitor/Calibration
Monitor/ Calibration MONITOR / CALIBRATION ONE: Enter into Menu, select Monitor (Image 22) and into BATTERY MONITOR (Image 23) LGD240 DUAL LGD240 DUAL Image 22 Image 24 Image 25 Image 23 1) Meter LiXx(LiPo/LiIo/LiFe/LiHV) battery status (Image 24) 2) Meter LiXx(LiPo/LiIo/LiFe/LiHV) battery internal resistance (Image 24) -
Page 16: Memory
Memory MEMORY 1. Enter into Menu, select Memory (Image 28) 2. Select correct icon as exact battery type (Image 29) and select “Modify” icon (Image 30) LGD240 DUAL Image 28 Image 29 Image 30 LGD240 DUAL Image 28 Image 31... -
Page 17: Error Information
External temperature is higher than the setting value, cuto . ERROR! OVER Ext. TEMP CUTOFF Capacity is over the setting value, cuto . ERROR! OVER CAPACITY CUTOFF Time is up to the setting value of Safety Timer, cuto . ERROR! SAFETY TIME OUT CUTOFF www.LAEGENDARY.com... -
Page 18: Warranty Information
This charger is designed and approved exclusively for charge the type of batteries stated in this manual. LAEGENDARY does not accept any liability if the charger is used for any purpose other than the one stated herein. We are not able to ensure that you follow the intructions that come with this charger and we have no control over the methods you employ for using, operating and maintaining this device. - Page 19 Phone: 646 859-1050 E-mail: support@laegendary.com Address: 1440 Falcon Lane, Ho man Estates, IL 60192 www.laegendary.com...
