Frankfurt Laser Company FLTT Series Manual

300m / 500m vcsel illuminator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
300m / 500m VCSEL Illuminator
Model No.: FLTT-XXX-Y.YW-Z00m
Manual

Advertisement

Table of Contents
loading

Summary of Contents for Frankfurt Laser Company FLTT Series

  • Page 1 300m / 500m VCSEL Illuminator Model No.: FLTT-XXX-Y.YW-Z00m Manual...
  • Page 2 And you are also appreciated to place this manual at hand to know about the operation procedures at any time. Frankfurt Laser Company provides accurate and reliable information to any user, however, the loss caused by any user misunderstanding and any factor by third party is not undertaken by FLC.

  • Page 3: Table Of Contents

    Content 2 Introduction ............................4 Introduction ..........................4 Relevant conventions in this user manual ................4 Safety Notices .......................... 4 3 Product Descriptions & Applications ..................... 8 Product Appearance ......................... 8 Product description ........................9 Feature ............................. 9 Applications ..........................9 4 Specifications ............................

  • Page 4: Introduction

    2 Introduction Introduction Thank you for purchasing our products and hope you will satisfy our products. This user manual describes the functions, operation steps, precautions, and service maintenance of the product. To ensure that you use this product effectively, please read this user manual thoroughly before using it.
  • Page 5 beam light sources, which may cause electric shock or blindness. • Only use the power cord provided in the product box. If the power cord is not included, only the power cord and plug specified in the "Power Cord Specifications" should be used. Failure to use this power cord may result in fire or electric shock.
  • Page 6 warning, it may cause fire or electric shock. • If the machine is dropped or the cover is damaged, please do not continue to use it. In this case, please turn off the power switch immediately, unplug the power cord from the power socket, and call the service technician for repair.
  • Page 7 • Unplug the power plug from the socket at least once a year and clean the area between the plug terminals. Dust accumulated between the plug terminals may cause a fire. • When unplugging the power cord, please hold the plug. Pulling on the power cord directly may damage it and cause fire or electric shock.

  • Page 8: Product Descriptions & Applications

    Laser radiation warning At the top of the case symbol Warning symbol At the top of the case or in the front of the case 2.3.3 Usage environment and precautions • There are no user-replaceable parts in the case, please contact FLC for repairs. •...

  • Page 9: Product Description

    Product description This laser illuminator is designed with independent patented technology and self-developed VSCEL chips. To ensure the reliability of the laser illuminator, a unique photoelectric isolation design is adopted. To facilitate integration, standard interface parameters such as power supply and control signals are adopted.

  • Page 10: Specifications

    Machine vision • Gesture recognition • Display • Medical applications • Freckle and hair removal • 4 Specifications Spec Parameters There may be some changes between sample and drawing， thus，the actual spec please refer to the sample that you received. And if any inquires please contact us. Parameters Values Unit...

  • Page 11: Communication Protocol

    Communication interface RS232/RS485/TTL Communication protocol Pelco_D Baud rate 9600 Signal Control cathode Black Signal Control Voltage Communication Protocol 4.2.1 PELCO-D Communication Protocol (Command parameters: The default standard rate is 9600bpsm, no parity, 8 data bits, 1 stop bit) Communication methods (232, TTL, 485 can be selected) Attention: In the process of switching the laser, please note that the time interval between turning on the laser and turning off the laser should be at least 150ms, otherwise the laser can only receive the first command.
  • Page 12 4.2.1.2 Set the motor speed FF01 AA 01 P1 P2 EE  P1 P2: It is the high and low eight bits of the speed information, P1 is the high 8 bits of the speed information, P2 is the low 8 bits of the speed information, the range of “P1 P2”...
  • Page 13 FF 01 AA 1D 04 B0 EE，give command to set Baud rate as 1200 FF 01 AA 1D 09 60 EE，give command to set Baud rate as 2400 FF 01 AA 1D 12 C0 EE，give command to set Baud rate as 4800 FF01 AA 1D 2580 EE，give command to set Baud rate as 9600 FF 01 AA 1D 4B 00 EE，give command to set Baud rate as 19200 4.2.1.7 Command summary...
  • Page 14  Query the motor position: FF 01 AA E6 00 02 EE 4.2.1.8 Correspondence between motor position and light spot divergence angle Motor Beam P1,P2 Motor Beam Motor Beam P1,P2 P1,P2data position angle data position angle position angle data 00 00 44．34 00 4B 14．81...
  • Page 15 4.2.2.1 Command summary  LD power switch control AA 55 06 01 FF 10 01 02 16 AA 55 06 01 FF 10 02 02 17  LD power adjustment control AA 55 06 01 FF 11 00 02 16 AA 55 06 01 FF 11 01 0217 AA 55 06 01 FF 11 02 02 18 AA 55 06 01 FF 1103 02 19...
  • Page 16 AA 55 06 01 FF 12 03 02 1A AA 55 06 01 FF 12 04 02 1B AA 55 06 01 FF 12 05 02 1C AA 55 06 01 FF12 06 02 1D AA 55 06 01FF 12 07 02 1E AA 55 06 01 FF12 08 02 1F AA 5506 01 FF 12 09 02 20 AA 55 0601 FF 12 0A 02 21...
  • Page 17 AA 55 06 01 FF 12 2E 02 45 AA 55 06 01 FF 12 2F 02 46 AA 55 06 01 FF 12 30 02 47 AA 55 06 01 FF 12 31 02 48 AA 55 06 01 FF 12 32 02 49 AA 55 06 01 FF 12 33 02 4A AA 55 06 01 FF 12 34 02 4B AA 55 06 01 FF 12 35 02 4C...
  • Page 18 4.2.2.2 Case Study  LD power switch control: AA 55 06 ADDR FF 10 DATA SUM1 SUM2 Head: AA 55 Length: 06 --- The number of all bytes after this byte Slave Address: ADDR FF --- slave address (1~C8) and master address (FF) Command: 10 Data: DATA --- 1 mean power on, 2 mean power off CheckSum: SUM1, SUM2...
  • Page 19 Data: DATA --- The host requests the slave to respond (FF) The slave responds to the host request (EE) Slave machine starts or resets and answers normally without error (01) Slave data packet receiving timeout response (02) Slave command bit received error response (03) Slave data bit received error response (04) LD power detection error response (05) Set up ongoing response (20)

  • Page 20: Installation And Connection Diagram

    Installation and Connection Diagram 4.3.1 Mechanic Schematic 4.3.2 Connection Schematic Connection of power supply line (6 PIN) Connection of control line (12 PIN) Manual Zoom (-) Power Anode (+) Manual Zoom (+) (NC) Power Anode (+) (NC) Power Anode (+) Photosensor anode Photosensor cathode Power Anode (-)

  • Page 21: Operation

    5 Operation Preparation before starting Installation: Before installation, please refer to the preface, safety matters and usage 5.1.1 environment and precautions. Connection: 5.1.2 5.1.2.1 Connect and install the laser output collimator on the front panel of the laser to the user's target system;...
  • Page 22 To protect your legal rights, please pay attention to the following information: 6.1.1 When purchasing the machine, please fill in the warranty card in a complete, correct and true manner with the supplier or the company’s sales. 6.1.2 Please keep the warranty card and purchase invoice properly. 6.1.3 Please bring the original warranty card and invoice when repairing it (invoice and warranty card must be filled out by the company or the vendor and stamped with the official seal, and must not be altered, otherwise it will be invalid);...

  • Page 23: Pack List

    7 Pack List Items Descriptions Qty. 300m(500m) VCSEL illuminator User’s manual 8 Application This product is designed with independent patented light intensity homogenization technology and original imported laser chip. To ensure the reliability of the laser illuminator, a unique photoelectric isolation design is adopted. To facilitate integration, standard interface parameters such as power supply and control signals are used.

  • Page 24: Annex

    Issues Product Name Item no. Malfunction description Frankfurt Laser Company An den 30 Morgen 13 61381 Friedrichsdorf Germany Reworking code is valid within 30 days after confirmed by fax or email. You are appreciated that you send back the repairing product with repair form with full information.
