Summary of Contents for Avid Power AHCAP068
- Page 1 MODEL: AHCAP068 DOUBLE CYLINDER DIGITAL AIR COMPRESSOR Operator's Manual SAVE THIS MANUAL You will need this manual for safety instructions, operating procedures and warranty. Put this manual and the original sales receipt in a safe dry place for future reference.
-
Page 2: Safety Instruction
SAFETY INSTRUCTION 1. Inspect unit before each use. 2. The metal compressor cylinder will heat up during operation. Do not touch the cylinder head or fittings with bare hands during or immediately after use. 3. Only hold the unit by the carrying handle. 4. -
Page 3: Technical Specifications
ATTENTION 1. The product only can be used on DC 12V power source and it can’t be used directly on AC 110V, AC 220V, DC 24V, DC 36V. 2. Avoid over-inflating, never exceed the recommended pressure. Items over inflated may burst and cause serious injury. Allow device to cool for 10 minutes after 15 minutes of continuous operation. -
Page 4: Function Description
FUNCTION DESCRIPTION 1. Handle 2. On/Off Switch 3. LED Switch 4. LED Light 5. Valve Cover Storage 6. Cigarette Lighter 7. Air Nozzle 8. Air Hose 9. Digital Display... - Page 5 HOW TO INFLATE CAR TIRE Step 1 The vehicle is in the safe state of parking and 滚滚长江东逝水 starts the engine. Step 2 Plug the power cord into the cigarette lighter socket of the vehicle or connect the clamps to car battery(Red+/Black-).
- Page 6 HOW TO INFLATE CAR TIRE Step 4 Press the "I" switch to start the inflation pump, and when the preset air pressure value is reached, the automatic shutdown will be performed. Press the switch to "O" and turn off. Step 5 Press the switch to start the light.
-
Page 7: Replace The Fuse
HOW TO INFLATE CAR TIRE To prevent blowing fuse, please turn on the pump before connecting it to tire valve stems. To prevent compressor damage: if compressor shuts off automatically, allow to cool for 10 minutes before restarting. Compressor shuts off to prevent overheating damage. - Page 8 ATTACHMENTS Bike Valve Adapter Tapered Nozzle Sport Balls Needle 1 x2.5m Air Hose 1 x Power Cord with Battery Clamps 1 xCarry Bag For inflating sport balls like basketball, football, etc. The following two pictures shows how to hoop up the nozzle to air chuck.
-
Page 9: Troubleshooting
TROUBLESHOOTING Problem Possible Cause Solution The inflator The preset pressure Adjust the preset pressure does not setting may be below setting to a higher pressure. start. the actual pressure of the item you are inflating. The power cord is not Plug the power cord into plugged.
Need help?
Do you have a question about the AHCAP068 and is the answer not in the manual?
Questions and answers
Reset circuit breaker ahcap068
The manual states that if the circuit breaker is tripped, you should reset it. However, it does not provide specific steps for resetting the circuit breaker on the Avid Power model AHCAP068. Therefore, the exact method to reset the circuit breaker cannot be determined from the provided information.
This answer is automatically generated
When attempting to remove the inflator of usage, the top portion of the cigarette lighter (Part 6) is stuck in the cigarette lighter adaptor connection in my vehicle. Is there another top of part (Part 6) that can be sent so that I can use it in another vehicle? Does the inflator have a warranty? Thank you.
