AKO -59840 Instructions

5984H012 Ed.02
Instructions
AKO-59840
AKO-59841

Warnings

-If the device is used without adhering to the manufacturer's instructions, the device safety requirements could be compromised. Only probes supplied by AKO should
be used for the appliance to operate correctly.
-The device should be installed in a place protected from vibrations, water and corrosive gases, where the ambient temperature does not exceed the value indicated in the
technical data.
-For the reading to be correct, the probe should be used in a place without heat influences apart from the temperature you want to measure or control.
-Avoid installing the device on metal walls or near devices that may cause radio emissions.
-AKO-59841x devices should NEVER be operated without installing the external antenna.
-This device can be fitted with any antenna provided it has a gain of less than 9.2 dBi and there is a minimum distance between it and any person or animal of more than 20 cm.
-This device must always be installed in an area where a minimum distance of 20 cm from the human body is ensured, to guarantee compliance with human exposure to
electromagnetic fields.
-Any type of antenna used with the equipment must comply with the limits established in the radio interface of the member estates and the following documents: Commission
Decision 2010/267/EU of 6 May 2010, ECC Decision (09)03 of 30 October 2009 and CEPT Report 30 of 30 October 2009.
-This device is powered by a non-rechargeable battery, if it runs out it must be replaced with the model AKO-58030. The dead battery cannot be disposed of
i
with household waste, it must be taken to a select collection point. NEVER try to recharge the battery, perforate or hit the battery or immerse it
in liquids or dispose of the battery with fire.

Installation

Installation conditions: Install the device away from draughts and condensation. Do not locate it close to evaporators, condensers or other items that may
produce electromagnetic noise. If it is installed in a chamber, locate it as close as possible to the door. If it is installed inside a cabinet or any other piece of
furniture, locate it as close as possible to its door.
2
1
x2
Ø 2,8 mm
4

Description

GB
Temperature monitor from -200 to 100 ºC with built-in NBIoT communication. Logs temperature data and transmits it
to the cloud (akonet.cloud). Both the configuration and monitoring of the data are carried out in the cloud itself.

Display and analysis of the logged data

Both the display of the logged data and the device configuration must be done in
The portal also allows you to analyse the stored data using graphs, statistics and operating indicators. For more
information visit akonet.cloud.

Declaration of conformity

AKO Electromecánica S.A.L. hereby declares that the type of radioelectric device AKO-5984xx (Temperature monitor,
external PT1000 probe, battery and built-in NB-IoT) is in accordance with Directive 2014/53/EU.
The full text of the EU conformity declaration is available at the following Internet address:
http://help.ako.com/en/manuals/declaracion-ue-de-conformidad
V2
Option A
Fixing by screws
3
+ x2
Ø 5 mm
Only
AKO-59841x
Option B
Fixing by adhesive
3 6
m m
7 0
m m
3
.2
3
.1
5
akonet.cloud.
3
.3
