- Page 1 MULTI-NETWORK CABLE TESTER MODEL TCT-255 Elenco Electronics, Inc. 150 W. Carpenter Avenue Wheeling, IL 60090 (847) 541-3800 www.elenco.com e-mail: elenco@elenco.com Instruction Manual Elenco Electronics, Inc. Copyright © 2001 Elenco Electronics, Inc. REV-A 753067 Revised 2002...
- Page 2 ITEMS INCLUDED WITH MODEL TCT-255 Cable Tester Terminator F to BNC Adapters (2) Cable Tester Model TCT-200 Soft Vinyl Case MAINTENANCE GENERAL MAINTENANCE To clean, wipe the case with a damp cloth and detergent (do not use abrasives or solvents).
- Page 3 (S) 8 (S) 8 INTRODUCTION The TCT-255 Cable Tester is a convenient instrument for testing different unshielded wiring schemed communication cable with RJ-11 and RJ-45 connectors and coax cable. This tester can be used for testing cables before and/or after they are installed. The tester offers easy operation by having to push only one button.
- Page 4 OPERATION INSTRUCTIONS 1. Connect one end of the cable to be tested to the terminator and the other end to the cable tester. 2. Push the TEST (power) button and read the result. Good Pair: Two vertical and one single blinking LEDs. The location of the single LED indicates a straight or cross-pinning for the pair.
