- Page 1 GuardDog® Series INSTALLATION, OPERATION, & MAINTENANCE MANUAL WRG-100 WRG-200 WRG-200N WRG-300 WRG-400 WRG-400P WRG-600 WRG-700P CONTENTS Important Notes Installation Instructions, Wiring Diagrams, Dimensional Drawings Operation and Maintenance Warranty...
- Page 2 SPD will perform best (faster response time) with the shortest wire length possible. Do not use wire nuts, kernies, etc. when installing SPD. Never install the SPD without utilizing mounting feet. Do not modify the SPD in any way. The SPD may be damaged and void the warranty. ©2020 MAXIVOLT...
- Page 3 Connect SPD lead conductors in accordance with wiring diagrams on page 4. Energize and ensure blue lights are on and primary protection lights are off. Note: Appropriate conduits and fittings must be used to maintain NEMA 4X rating. ©2020 MAXIVOLT...
- Page 4 WRG-200 WRG-200N WRG-300 WRG-400 WRG-400P WRG-600 WRG-700P Primary Protection - NORMALLY OFF - CONTACT MAXIVOLT IF ON ® Surge Protective Device 240/120 VAC Split Ø 3 Wire EQUIPPED WITH ® REMOTE MONITORING Secondary Protection - NORMALLY ON - CONTACT MAXIVOLT IF OFF...
- Page 5 GUARD DOG® SERIES INSTALLATION, OPERATION, & MAINTENANCE MANUAL DIAGRAMS WIRING WRG-100 Primary Protection - NORMALLY OFF - CONTACT MAXIVOLT IF ON Phase A ® Control Power Source (Primary) Surge Protective Device 240/120 VAC Split Ø 3 Wire Phase B Normally Open (NO) Output (Primary)
- Page 6 Primary Protection Level Means of Indication: Primary lights are red in color and are normally off. Action: Visually confirm all three lights are ‘off’ . If any lights are ‘on’ , call Maxivolt @ 1-800-583-4773. Secondary Protection Level Means of indication: Secondary lights are blue in color and are normally on.
- Page 7 Texas 79106, attention Warranty Claim. To obtain information on warranty performance, call toll free: 1-800-583-4773. A Warranty Information Form should be filled out and included in the package contain- ing the WRG Series Unit. This form can be requested from MVC, Inc. at the toll free number listed above. ©2020 MAXIVOLT...
- Page 8 MANUAL ABOUT Established over three decades ago, Maxivolt is a pioneer in the power quality industry with over a century of combined experience. Maxivolt manufactures specialized technology and provides value-added services custom-tailored to extend the life and protect the operational integrity of electrical and electronic equipment.
