BFH1
BLACK FIREPLACE HOOD
INSTALLATION INSTRUCTIONS
WARNING: Fireplace hood becomes very
hot during fireplace operation. Do not touch
fireplace hood. Severe burns could occur.
Questions, problems, missing parts? Before returning to your retailer, call
our customer service department at 1-866-573-0674, 8:00 am - 4:45 pm EST,
Monday through Friday or email contact@usaprocom.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Procom BFH1
- Page 1 BFH1 BLACK FIREPLACE HOOD INSTALLATION INSTRUCTIONS WARNING: Fireplace hood becomes very hot during fireplace operation. Do not touch fireplace hood. Severe burns could occur. Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-866-573-0674, 8:00 am - 4:45 pm EST,...
-
Page 2: Replacement Parts List
Hardware Contents AA Metal Screws BB Masonry Screws If any of these pieces are missing or damaged call ProCom Heating, Inc. at 1-866-573-0674 for referral information. PREPARATION Before beginning assembly of product, make sure all parts are present. Compare parts with package contents lists. - Page 3 ASSEMBLY INSTRUCTIONS SIZING THE FIREPLACE HOOD TO THE FIREPLACE OPENING OR GLASS DOOR FRAME The fireplace hood assembly is adjustable from 28" to 48". The hood assembly must be opened wide enough to cover the entire Measurement ”A” fireplace opening. The hood can be opened Fireplace Opening wider if desired.
- Page 4 ASSEMBLY INSTRUCTIONS INSTALLING HOOD TO MASONRY FIREPLACE Follow the instructions below that best de- scribes your fireplace. Masonry With Glass Doors 1. Loosen clamps that hold glass door frame to fireplace. Slide the mounting brackets (E) behind the glass door frame (see Figure 5).
- Page 5 ASSEMBLY INSTRUCTIONS 3. Use the 4 masonry screws (BB) provided 4. Slide fireplace hood assembly (A) over to fasten the brackets to the lintel (see mounting brackets (E). See Figure 10. Figure 9). Lintel Figure 9 IMPORTANT: Tape must be removed before operating the fireplace.
- Page 6 ASSEMBLY INSTRUCTIONS Installing Into Manufactured Manufactured Fireplace Fireplace Opening 1. Discard the mounting brackets. 2. Place the fireplace hood assembly (A) inside fireplace opening (see Figure 12). 3. Hold the fireplace hood assembly (A) in Approximate Screw place and drill 4 holes through the hood Locations and into the channel on the fireplace opening (see Figure 13).
-
Page 7: Replacement Parts
REPLACEMENT PARTS Note: Use only original replacement parts. This will protect your warranty coverage for parts replaced under warranty. PARTS UNDER WARRANTY Contact authorized dealers of this product. If they can’t supply original replacement parts, call Customer Service toll free at 1-866-573-0674 for referral information. When calling Customer Service or your dealer, have ready: •... -
Page 8: Limited Warranty
We make no other warranty, expressed or implied. LIMITED WARRANTY ProCom Heating, Inc. warrants this product to be free from defects in materials and components for ONE (1) year from the date of first purchase, provided that the product has been properly installed by a qualified installer in accordance with all local codes and instructions furnished with the unit, operated and main- tained in accordance with all applicable instructions.
