NEXTAV PTT-R16 User Guide
Specifications:
Bluetooth version：V4.0
Transmission distance：5m
：2.4GHz
RF Frequency
Bluetooth RF Spec：Class 2
RF Power：4dB
Standby time：800 hours
Working
time：500 hours
Charge Time：Less than 3hours
Charge Power：DC5.0V/500mA
Battery Capacity：200mAh
Color：Black
Operating Temperature: -15℃~45℃
Storage
Temperature:： -25℃~60℃
1
Advertisement
Table of Contents
Related Manuals for Nextav PTT-R16
Summary of Contents for Nextav PTT-R16
- Page 1 NEXTAV PTT-R16 User Guide Specifications: Bluetooth version：V4.0 Transmission distance：5m ：2.4GHz RF Frequency Bluetooth RF Spec：Class 2 RF Power：4dB Standby time：800 hours Working time：500 hours Charge Time：Less than 3hours Charge Power：DC5.0V/500mA Battery Capacity：200mAh Color：Black Operating Temperature: -15℃~45℃ Storage Temperature:： -25℃~60℃...
- Page 2 Basics 1. Power on: Press and hold PTT Button for 5 seconds (Red /Blue LED light flashes). 2. Power off: Press and hold PTT Button for 5 seconds. The device will be automatically powered after 10 minutes if there is no smart phone connected to it.
- Page 3 User Guide for Zello App Android Make sure that your phone’s Bluetooth is turned on; Press and hold PTT key for 5 seconds to switch on the PTT Button; ” in the lower right Launch the Zello app. Go to Options / Push-to-talk buttons / , click on the Blue icon“...
- Page 4 User Guide for Zello App Make sure to switch on your iPhone’s Bluetooth; Press and hold for about 5 seconds to switch on the PTT button; Go to → Options → Push-to-talk buttons → Add New Device Launch the Zello app.
