Summary of Contents for Nemo ID-18-3Li-50
-
Page 2: Functional Description And Specifications
Functional Description and Specifications Intended Use The Nemo Submersible Impact Driver is intended to carry out fastening applications both underwater and on dry land. The torque on the driver gives you the power you need to drive in large or long screws, and its ¼... - Page 3 Battery Charger Model XVE-2100400 Approximate charging time 45 minutes Charging output voltage Charging input voltage 100V – 240V Safety Warnings Warning: Read all safety warnings and instructions, and save them for future reference. Failure to adhere to these warnings can result in serious injury and damage to equipment.
- Page 4 Caution: Under no circumstances should the power tool be opened for repairs or any other purpose by anyone other than an after-sales service technician authorized by Nemo Power Tools. Opening the power tool invalidates the manufacturer warranty. ♦ Use power tools, accessories, and tool bits in accordance with...
- Page 5 Rechargeable Battery Safety ♦ Use only the battery pack supplied with your power tool. ♦ When the battery pack is not in use, keep it away from other metal objects like paper clips, coins, keys, nails, screws, which can make a connection from one terminal to another. ♦...
- Page 6 Getting Started with the Impact Driver Your Nemo Submersible Impact Driver (IW-18-3Li-50) includes the following main components: Charging the Battery The Li-ion batteries are supplied partially charged, and must be charged to full capacity using the battery charger provided before using the impact driver for the first time.
- Page 7 A battery can be charged at any time without reducing its service life. This is because the battery charger detects the charging condition of the battery, and charges it with the optimum current according to its temperature and voltage. This lengthens the life of the battery, and leaves it fully charged when stored in the charger.
- Page 8 Inserting a Battery into the Impact Driver 1. Set the rotational direction switch to the middle position. Caution: To minimize the risk of accidental activation, always ensure the rotational direction switch is in the neutral (middle) position before performing any maintenance work on the impact driver, as well as during transport and storage.
- Page 9 Inserting or Removing a Driver Bit or Socket Bit 1. Set the rotational direction switch to the middle position. Caution: To minimize the risk of accidental activation, always ensure the rotational direction switch is in the neutral (middle) position before performing any maintenance work on the impact driver, as well as during transport and storage.
- Page 10 Pressurizing the Impact Driver for Underwater Use Your impact driver can be used in any wet conditions, and can be submerged and used underwater at depths of up to 164 ft ( 50m ) . Before submerging the impact driver to any depth, it must be pressurized.
- Page 11 2. Attach a pump, such as the hand pump supplied with the impact driver, to the valve. 3. Pressurize the impact driver according to the depth to which you are going to submerge it, as follows: Depth in meters Depth in feet Pressure Up to 5m 16 feet...
- Page 12 Best Practices for Underwater Operation Your Nemo Submersible Impact Driver is designed to be waterproof, so that it can be used both on land and underwater. To obtain the maximum serviceable life of your impact driver, adhere to the following best practices when using the impact driver underwater: ♦...
-
Page 13: Operating The Impact Driver
Operating the Impact Driver Switching the Impact Driver On or Off ♦ Press the On/Off trigger, and keep it pressed. You can increase the speed of the impact driver by increasing the pressure on the switch. To switch off the impact driver, release the On/Off trigger. -
Page 14: Maintenance
Caution: Under no circumstances should the impact driver be opened for repairs or any other purpose by anyone other than an after-sales service technician authorized by Nemo Power Tools. Opening the impact driver invalidates the manufacturer warranty. Transporting the Impact Driver For maximum protection, always transport your impact driver secured in its carrying case, with the battery removed. - Page 15 Caution: Under no circumstances should the impact driver or accessories be opened for repairs or any other purpose by anyone other than an after-sales service technician authorized by Nemo Power Tools. Opening the impact driver invalidates the manufacturer warranty.
- Page 16 Problem: The battery charger is warm to the touch. Possible Cause Corrective Action Continuous or repetitive No corrective action is required as charging cycles without a this does not indicate a fault with break may cause the the battery charger. charger to warm up.
- Page 17 excessive load , may shut down prematurely . This is a built-in safety feature. If the battery contacts are not damaged , recharging the battery for a short period ( even a few minutes ) will reset the battery`s electronics and restore the battery voltage to the voltage level before it shut down.
- Page 18 Disclaimer : Nemo Power Tools Ltd reserves the right to change the contents of this manual at any time without prior notice . Nemo Power Tools Ltd www.nemopowertools.com...
