homezone Caira 1700-KH Assembly Instructions

Caution: Please read instructions thoroughly before unpacking assembly parts.Sharp,exposed staple tips can
cause injury,therefore,for your protection, please remove any exposed staple used in packing.
1. We recommend that you assemble this product with the assistance of another person; this will make
the assembly easier, and will help eliminate damage to the product or injury to persons during assembly.
2. Be sure to check all packing materials carefully for small parts that may have come loose inside the
carton during shipment.
3. Please do not over tighten screws or bolts
4. Please put all parts on a non-abrasive floor before assembly, and follow the assembly steps to
assemble your newly purchased product correctly and efficently.

HARDWARE LIST OF HEADBOARD

SKETCH
NO.
1
Flat Washer
2
Spring Washer
3
JCBC Bolt
4
JCBC Bolt Ø5/16"*1-1/2'
5
Allen Wrench (4mm)

HARDWARE LIST OF FOOTBOARD

SKETCH
NO.
6
Flat Washer
7
Spring Washer
8
JCBC Bolt
9
Allen Wrench
10
Wood screw
ASSEMBLY INSTRUCTIONS FOR
1700-KH King Headboard
1700-KF King Footboard Storage
1700-Q/KR Queen/king side Rail
Q'TY
COMPONENT
Ø5/16"*19mm 8pcs
Ø5/16"
8pcs
Ø5/16"*2' ' 6pcs
' 2pcs
1pcs
Q'TY
COMPONENT
2pcs
Ø1/4"*19mm
Ø1/4" 2pcs
Ø1/4"*30mm
2pcs
(4mm) 1pc
14pcs
switches turn
on and off
lights
PAGE 1 of 2
PART LISTS
NO
DESCRIPTION
A
Headboard panel
B
Headboard leg (KD)
C
Headboard bottom rail
D
Footboard Storage
E
Side Rails
F
Roll Slats
Support leg
G
with leveler
H
Bottom Roll Slats
I
Power outlet
Power outlet
I
QTY
1pc
2pcs
L=1 R=1
1pc
1pc
2pcs
13pcs
3pcs
1pc
2pcs
MADE IN VIET NAM
