ELECTRONIC ROULETTE KIT
MODEL AK-300
Instruction & Assembly Manual
Elenco
®
Electronics, Inc.
Copyright © 2005, 1997 by Elenco
®
Electronics, Inc. All rights reserved.
Revised 2005
REV-D
753031
No part of this book shall be reproduced by any means; electronic, photocopying, or otherwise without written permission from the publisher.
Advertisement
Table of Contents
Related Manuals for Elenco Electronics AK-300
Summary of Contents for Elenco Electronics AK-300
- Page 1 ELECTRONIC ROULETTE KIT MODEL AK-300 Instruction & Assembly Manual Elenco ® Electronics, Inc. Copyright © 2005, 1997 by Elenco ® Electronics, Inc. All rights reserved. Revised 2005 REV-D 753031 No part of this book shall be reproduced by any means; electronic, photocopying, or otherwise without written permission from the publisher.
-
Page 2: Parts List
If you are a student, and any parts are missing or damaged, please see instructor or bookstore. If you purchased this roulette kit from a distributor, catalog, etc., please contact Elenco (address/phone/e-mail is at the back of this manual) for additional assistance, if needed. DO NOT contact your place of purchase as they will not be able to help you. - Page 3 IDENTIFYING RESISTOR VALUES Use the following information as a guide in properly identifying the value of resistors. BAND 1 1st Digit Color Digit Black Brown Orange Yellow Green Blue Violet Gray White IDENTIFYING CAPACITOR VALUES Capacitors will be identified by their capacitance value in pF (picofarads), nF (nanofarads), or µF (microfarads). Most capacitors will have their actual value printed on them.
- Page 4 INTRODUCTION Electronic Roulette (roo-let) replaces the ivory ball with a circuit of flashing light emitting diodes (LED’s). Red LED’s are arranged in a circle next to a black or red number and two green LED’s are positioned next to “0” and “00”. When the switch is pushed, the LED’s light one after another, in a sequence that represents the movement of the ivory ball.
- Page 5 THE PULSE GENERATOR Assume that part of the sand from the “Timer Glass” in Figure 2 is poured into a bucket as shown in Figure 3a. When the bucket has enough sand, it will flip and dump as shown in Figure 3b. Each time it flips, it closes switch X2, sending the battery voltage to the Ring Counter and it strikes the “Drum”...
- Page 6 THE SOUND CIRCUIT In the sound generator circuit, a 500Hz oscillator is always running. This oscillator is represented by the spinning wheel in Figure 4a. No sound is heard because the spinning wheel is not hitting the drum. When the bucket in Figure 3 dumps sand, the lever arm pushes the spinning wheel against the stop and the small balls on the spinning wheel hit the drum, producing a high frequency sound (Figure 4b).
- Page 7 CONSTRUCTION Introduction The most important factor in assembling your AK-300 Electronic Roulette Kit is good soldering techniques. Using the proper soldering iron is of prime importance. A small pencil type soldering iron of 25 - 40 watts is recommended. The tip of the iron must be kept clean at all times and well tinned.
- Page 8 ASSEMBLE COMPONENTS TO THE PC BOARD Identify and install the following parts as shown. After soldering each part, place a check Space the LED’s with a paper clip (use size shown below) so that they are 1/4” off of the PC board. U1 - 16-pin Socket U1 - 4017 Integrated Circuit (see Figure B)
- Page 9 ASSEMBLE COMPONENTS TO THE PC BOARD Identify and install the following parts as shown. After soldering each part, place a check Space the LED’s with a paper clip (use size shown below) so that they are 1/4” off of the PC board. 1/4”...
- Page 10 ASSEMBLE COMPONENTS TO THE PC BOARD Identify and install the following parts as shown. After soldering each part, place a check 1/4” LED Spacer (Actual Size) 2-56 Hex Nut Flat Washer Buzzer Scotch Tape Battery Holder 2-56 x 5/16” Screw D1 –...
-
Page 11: Component Check
COMPONENT CHECK Make sure that all components have been mounted in their correct places. Make sure that the LED’s have been installed correctly. The flat side of the LED’s should be in the same direction as shown on the top legend. Make sure that diodes D39 - D43 have not been installed backwards. - Page 12 OPERATING INSTRUCTIONS CHART A Strategies Explanation A) Single Straight Chips on a number from 1-36 including 0 and 00. B) Split Chips on two numbers vertically or horizontally next to one another. C) Street Chips on three numbers horizontally in one line. D) Corner Chips on four numbers vertically and horizontally next to one another.
-
Page 13: Schematic Diagram
RULES FOR PLAYING ROULETTE The object of the game is to increase the value of your chips more than any other player. Chips with gold centers are worth $100.00, green centers = $25.00, red centers = $5.00, and white centers are worth $1.00. -
Page 14: Word Glossary
WORD GLOSSARY Capacitor An electrical component that can store electrical pressure (voltage) for periods of time. Cold Solder Joint Occurs because insufficient heat was applied or the connection was moved before the solder had set. Connection looks crystalline, crumbly, or dull. Flux A substance that is used to cleanse the surface of oxide... - Page 15 Complete with PC Board and Instruction Book Space War Gun 0-15V Power Supply K-10 K-11 Rapid fire or single shot with 2 A low-cost way to supply voltage flashing LED’s. to electronic games, etc. 0-15VDC @ 300mA. Requires 9V battery LED Robot Blinker Digital Bird K-17...
- Page 16 QUIZ 1. In electronics, a capacitor is a . . . A. - counter. B. - generator. C. - light emitting device. D. - storage device. 2. The Timer Circuit is used to . . . A. - turn power on. B.
