Panther Series – ED107 PolyDAC(X) MIDI-CV
Construction of the ED107 requires the assembly of a 8 pcbs.
Constructors should refer to the Component Overlay and the Bill Of Materials for the current value of all
components as well as our General Construction Notes.

ED107A - Voice Board (x4)

1. Mount the 2 surface-mount devices U101 and U102
2. Fit all remaining components to the board excluding the LED D101
3. Mount the board on to the front panel and tighten all nuts,
4. Carefully form the LED legs (D401 and D504), insert them in to the pcb,
5. Align the LEDs with their panel holes and once positioned, solder in to place,
6. The module is now ready for calibration

ED107B - Column 5

1. Fit all components to the board. Note that the 2 jacks J101 & J103 will need to be 'forced' in to position

ED107C - Column 6

1. Fit all components except J101, J102 & D102

Panther Support - Column 7

1. Fit all components

Main Board

1. Mount the surface-mount device U203
2. Fit all components

Module Assembly

1. Fit the 2 MIDI Sockets to the Front Panel ensuring that a flat of the nut is parallel to the side edges of
the Front Panel
2. Insert the lens mounts in to the Front Panel
3. Mount ED107C
4. Use pieces of tinned copper wire (spent resistor legs are fine) to wire the MIDI sockets to the pcb
5. Form LED D102 and mount to the board
6. Mount the first ED107A in the VOICE 4 column
7. Mount LED D101 and solder in to place
8. Repeat for VOICE 3, VOICE 2 and then VOICE 1
9. Install ED107B and the Panther Support Board
10. Mount the Main Board ensuring that seven headers are correctly aligned

CALIBRATION

Dipswitch S101 is used to provide various options for the ED107 - PolyDAC (X). The
current assignments are as follows (using firmware V3.9 or greater) :-
Switch #1: unused
Switch #2: unused
Switch #3: unused
Switch #4: OFF = Normal operation, ON = TEST mode allowing calibration of the DAC
output.
elby_designs@ozemail.com.au
Elby Designs - Laurie Biddulph
9 Follan Close, Kariong, NSW 2250, Australia
1 of 2
http://www.elby-designs.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Panther Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Elby Designs Panther Series

  • Page 1 Panther Series – ED107 PolyDAC(X) MIDI-CV Construction of the ED107 requires the assembly of a 8 pcbs. Constructors should refer to the Component Overlay and the Bill Of Materials for the current value of all components as well as our General Construction Notes.
  • Page 2 The red stripe on the power cable represents pin 1 (–12V rail) on the IDC connector. All Panther Series boards used a boxed 16-way IDC header with a polarising key. Pin 1 on the power connector is towards the bottom edge of the board.
