Owner's Operation and Instruction Manual
Please read this entire manual be-
fore you install and use your new
heater. Failure to follow instructions
may result in property damage,
bodily injury, or even death.
THIS MANUAL WILL HELP YOU TO OBTAIN EFFICIENT, DEPENDABLE SERVICE FROM THE HEATER, AND ENABLE YOU TO
ORDER REPAIR PARTS CORRECTLY. KEEP IN A SAFE PLACE FOR FUTURE REFERENCE.
French version is available for download from the United States Stove Company website: http://www.usstove.com/
La version française est disponible pour téléchargement à partir du site United States Stove Company: http://www.usstove.com/
MODEL: 2200IE
Fireplace Insert
Masonry Fireplace Insert or Zero-Clearance (metal) Fireplace Insert
SAFETY TESTED TO UL 1482 and ULC-S628
U.S. Environmental Protection Agency
Certified to comply with 2015 particulate emissions standards.
DO NOT use this appliance in a mobile home, manu-
factured home, trailer, or tent.
CAUTION!
SAVE THESE INSTRUCTIONS
United States Stove Company
227 Industrial Park Road
South Pittsburg, TN 37380, USA
If this heater is not properly installed, a
house fire may result. For your safety,
follow the installation instructions. Con-
tact local building or fire officials about
restrictions and installation in your area.
P.O. Box 151
1-800-750-2723
SAFETY NOTICE:
852497-4805E
Advertisement
Table of Contents
Related Manuals for United States Stove Country Hearth 2200IE
Summary of Contents for United States Stove Country Hearth 2200IE
- Page 1 ORDER REPAIR PARTS CORRECTLY. KEEP IN A SAFE PLACE FOR FUTURE REFERENCE. French version is available for download from the United States Stove Company website: http://www.usstove.com/ La version française est disponible pour téléchargement à partir du site United States Stove Company: http://www.usstove.com/ United States Stove Company 227 Industrial Park Road P.O.
- Page 2 You’ve purchased a heater from North America’s oldest manufacturer of wood burning products. By heating with wood you’re help- ing to CONSERVE ENERGY! Wood is our only Renewable Energy Resource. Please do your part to preserve our wood supply. Plant at least one tree each year. Future generations will thank you. The instructions pertaining to the installation of your wood stove comply with UL-1482 and ULC-S628 standards.
- Page 3 2200IE DIMENSIONS 27 1/32 [686.6 mm] 26 11/32 [669.0 mm] 13 5/32 [334.5 mm] 44 7/32 [1123.0 mm] 6.00 INSIDE 22 1/4 [565.0 mm] 21 13/16 [554.0 mm] 4 11/16 [118.8 mm] 15 1/2 [394.0 mm]...
-
Page 4: Pre-Installation Requirements
PRE-INSTALLATION REQUIREMENTS 6. Fireplace Opening Dimensions. FIREPLACE CONDITION AND A. Minimum Width ....... 29˝ [737mm] ZERO CLEARANCE REQUIREMENTS B. Minimum Height ......23˝ [584mm] A masonry fireplace must meet minimum code require- ments, National Fire Protection Association, (NFPA) 211, C. Minimum Depth ......14˝ [356mm] or the equivalent for a safe installation. -
Page 5: Floor Protector
PRE-INSTALLATION REQUIREMENTS a. Existing fuel-fired equipment shows evidence of The chimney must also meet minimum and maximum back puffing, smoke roll-out, inefficient operation, cross sectional requirements. For that reason a continu- or excessive smell in the living area. ous 6˝ stainless steel liner from the flue collar to the top of the chimney is required. - Page 6 ASSEMBLY INSTRUCTIONS TOOLS AND MATERIALS REQUIRED FOR INSTALLATION TOOLS MATERIALS • Pencil (NOTE: The following items are NOT included with your stove.) Flooring Protection: as specified herein. • 6 foot Folding Ruler or Measuring Tape Chimney Liner: Continuous stainless steel chimney liner •...
- Page 7 ASSEMBLY INSTRUCTIONS 11. Bolt the top panel (1) to the side panels (2 and 14) so 15. The surround assembly is held in place with two the top surfaces are flush to one another using items springs at the top of either corner of the appliance 3 and 4.
-
Page 8: Chimney Specifications
CHIMNEY SPECIFICATIONS This appliance must be connected to a listed Stainless Steel Should you have a problem with inadequate draft, you should Liner, that meets UL1777, which extends from the collar to the contact a licensed heating and cooling contractor for assistance chimney cap according to the specifications listed on the previ- in solving the problem. -
Page 9: Fuel Recommendations
FUEL RECOMMENDATIONS WOODSTOVE UTILIZATION This heater is designed to burn natural wood only. Higher efficiencies and lower emissions generally result when burning air dried seasoned hardwoods, as compared to softwoods or to green or freshly cut hardwoods. DO NOT BURN: Garbage;... -
Page 10: Testing Your Wood
OPERATING INSTRUCTIONS If your wood hisses and water or vapor escapes at the ends of CAUTIONS: HOUSE FIRE HAZARDS the piece, your wood is soaked or freshly cut (green). Do not use this wood in your stove. Large amounts of creosote could •... -
Page 11: Adding Fuel
OPERATING INSTRUCTIONS is reset from wide open to the desired operating setting. If the each. The third fire should be at a temperature of approxi- flames do not continue to burn, open the air control to re-es- mately 500 F for 20 minutes. Provide adequate cross ventila- tablish the secondary flames then slowly reset the air control tion to clear any smoke or odor caused by initial firings. -
Page 12: Operational Tips
OPERATING INSTRUCTIONS place your next fuel load into the appliance (make sure no em- • Be considerate of the environment and only burn dry bers or ashes block the LPAO). Leave the door air inlet control wood in the wide open position for 15–20 minutes. •... -
Page 13: Chimney Maintenance
CHIMNEY MAINTENANCE 4. A small hot fire is preferable to a large smoldering one CAUTION: that can deposit creosote within the heating system. SLOW BURNING FIRES FOR EXTENDED USE OR 5. Establish a routine for the handling of fuel, wood BURNING GREEN WOOD MAY CAUSE EXCESSIVE burner and firing technique. -
Page 14: Service Hints
SERVICE HINTS ASH REMOVAL AND DISPOSAL Gasket and Glass cleaning products are available at local retail home centers. Manufacturers of cleaning products Whenever ashes get 3 to 4 inches deep in your firebox or for wood stoves include, A.W. Perkins Co. (www.awper- ash pan, and when the fire has burned down and cooled, kins.com) or Rutland Products (www.rutland.com). -
Page 15: Repair Parts
REPAIR PARTS Part No. Description Qty. Part No. Description Qty. 891990 Retainer, Tube 69660 Complete Door Assembly 88158 Fiber Board, Front 88066 5/8” Rope Gasket 6 ft. 88159 Fiber Board, Rear 891813 Door Glass 88160 Fiber Blanket 88174 Gasket-Flat, Glass (3/16T x 3/8W) 6 ft. - Page 16 FLOOR PROTECTOR The stove must be placed on solid concrete, solid masonry, or when installed on a combustible floor, on a Type 2 floor protector listed to standard UL 1618 with a minimum R value of 1.2 or equivalent. The floor protector is required to provide heat, live ember, and ash protection and must be of a non-combustible, continuous solid surface to protect against infiltration of live embers and ash.
- Page 17 NOTES...
-
Page 18: How To Order Repair Parts
INFORMATION AS SHOWN IN THIS LIST: 1. THE PART NUMBER 2. THE PART DESCRIPTION 3. THE MODEL NUMBER: 2200IE 4. THE SERIAL NUMBER:____________________ UNITED STATES STOVE COMPANY 227 INDUSTRIAL PARK ROAD P.O. BOX 151 SOUTH PITTSBURG, TN 37380, USA 800-750-2723... - Page 19 WARRANTY INFORMATION CARD Name______________________________________ Telephone #: (_____)_____________ City______________________________________ State_______ Zip_________________ Email Address ____________________________________________________________ Model # of Unit_____________________________ Serial #___________________________ Fuel Type: qWood qOther ______________________ qCoal qPellet qGas Place of Purchase (Retailer)___________________________________________________ City__________________________________________ State_______ Zip_________________ If internet purchase, please list website address___________________________________ Date of Purchase __________________________________________________________ Reason for Purchase: qAlternative Heat...
- Page 20 Ê É Fold Here Fold Here Fold Here PLACE STAMP HERE United States Stove Company P.O. Box 151 South Pittsburg, TN 37380...
