OWNER'S MANUAL
G2082 MOBILE GAS BARBECUES
USE ONLY THE HOSE AND HOSE CONNECTOR PROVIDED!
If a replacement is necessary, please contact either our Customer Service Department or your
local dealer.
The use of unauthorised parts can create unsafe conditions and environment.
Picture of appliance
Dansk manual finds på moreland.dk
Advertisement
Related Manuals for FERVERD G2082
Summary of Contents for FERVERD G2082
- Page 1 OWNER’S MANUAL G2082 MOBILE GAS BARBECUES USE ONLY THE HOSE AND HOSE CONNECTOR PROVIDED! If a replacement is necessary, please contact either our Customer Service Department or your local dealer. The use of unauthorised parts can create unsafe conditions and environment.
- Page 2 Technical Information: APPLIANCE Jiang Men City Hong Hua Metal Prodcuts Co., Limited MANUFACTURED BY: APPLIANCE CODE: G2082 TOTAL HEAT INPUT: 5.50 kW (400 g/h) (ALL GAS CATEGORIES) GAS CATEGORY: 3+(28-30/37) 3B/P(30) TYPES OF GAS: Butane Propane LPG GAS MIXTURES GAS PRESSURE:...
- Page 3 IMPORTANT: Read the following instructions carefully and be sure your barbecue is properly installed, assembled and cared for. Failure to follow these instructions may result in serious bodily injury and/or property damage. If you have any questions concerning assembly or operation, consult your dealer or LPG Gas Company.
- Page 5 Description Figure Description Figure Q'TY Q'TY Spark Electrode ， Rear Burner Lid Handle Control Panel Gamel I Right Shelf Assembly Warming Rack Wheel Axle Cooking grid Huff Caster Flame Tamer Transverse Leg Gamel II Burner Front Cloth Clip Lid Support Axle Side Shelf,Left Body Side Shelf,Right...
- Page 6 STEP 1 Front Left Front Right Back Left Back Right M6X40 4Pcs STEP 2 Front Left Back Left Back Right Front Right Part 28 Clip 2PCS Part 23 Wheel Axle 2Pcs...
- Page 7 STEP 3 M5X10 3Pcs STEP 4 M4X10 4Pcs...
- Page 8 STEP 5 STEP 6 Hooks 6Pcs M6X10 8Pcs Part 13 STEP 7 M5X30 4Pcs M5X10 4Pcs M5Nut 8Pcs...
- Page 9 STEP 8 M5X30 4Pcs M5Nut 4Pcs STEP 9 M5X30 2 Pcs M5 Mutter 2 Pcs...
- Page 10 STEP 10 M5X10 6Pcs M5Nut 4Pcs STEP 11 fix the lid with "Lid Support Axle and Clip" Clip 2PCS Part 28 Part 9 Lid Support Axle 2PCS...
- Page 11 STEP 12 hang the greacy cup STEP 13 fix the front cloth and front basket Front Cloth...
- Page 12 STEP 14 connect the hose (not included)
- Page 13 ONNECTING THE GAS CYLINDER TO THE APPLIANCE This appliance is only suitable for use with low-pressure butane or propane gas or LPG mixtures, fitted with the appropriate low-pressure regulator via a flexible hose. The hose should be secured to the regulator and the appliance with hose clips. This barbecue is set to operate a 28 mbar regulator with butane gas and a 37 mbar regulator with propane gas 30 mbar for LPG mixtures, or 37 mbar for LPG mixtures, or 50 mbar for LPG mixtures.
-
Page 14: To Check For Leaks
Fit the hose to the appliance using a spanner to tighten it onto the connection thread. If the hose is replaced it must be secured to the appliance and regulator connections with hose clips. Disconnect the regulator from the cylinder (according to the directions supplied with the regulator) when the barbecue is not in use. - Page 15 Warning: If the burner fails to ignite, turn the control knob off (clockwise) and also turn the cylinder valve off. Wait five minutes before attempting to relight with ignition sequence. CLEANING AND CARE CAUTION: All cleaning and maintenance should be carried out when the barbecue is cool and with the fuel supply turned OFF at the gas cylinder.
