- Page 1 Core 4 Dante™ PoE+ 4 x 30 W / Mid-Span Distributor User’s manual V1.1 - 03/2020...
- Page 2 User’s manual - Core 4 V1.1 03/2020...
- Page 3 CORE 4 - USER MANUAL Page 1. Carton Contents 2. Introduction 3. Example of use 4. Technical specifications 5. LED indicators 6. Operation of the dip-switches for the Power over Ethernet (PoE) function 7. Overview User’s manual - Core 4 V1.1...
- Page 4 - 1 user manual 2. Introduction The Dante™ PoE+ Core 4 distributor offers one 10/100 Mbit/s connection port on the front panel and four 10/100 Mbit/s PoE+ ports on the rear panel. The power activation for each output is performed by dip-switches on the front panel. The power available on each port is 30 W.
- Page 5 44 × 160 × 122 mm (H x L x P) Weight 0.80 kg Operating temperature range 0 to 40°C Storage temperature range -20°C to 90°C Humidity 10 to 90% (non-condensing) Certifications FCC Classe B, CE User’s manual - Core 4 V1.1 03/2020...
- Page 6 PoE ports. The device will automatically power off and on again if the total PoE consumption exceeds the available PoE budget. If this happens, it is advisable to turn off a PoE port. User’s manual - Core 4 V1.1 03/2020...
- Page 7 Mains power indicator diode LEDs for individual indication of PoE power presence and operation of each output port PoE Activation Dip-Switch for each output port Input port connector (Uplink) Output Connectors Mains power connector User’s manual - Core 4 V1.1 03/2020...
