Carefree of Colorado OMEGA II Quick Start Manual

RV
C C
OMPONENT HECK
C
OMPONENT
•
Case Assembly
•
End Cap, LH
•
End Cap, RH
•
Pull Strap Assembly
(The rubber grommet is installed on the pull strap assembly.)
I S
NSTALLING THE TRAP
1. Extend the slide-out room completely.
2. (Detail A) Remove the four (4) screws that hold the
case onto the arms. Then remove the case.
3. Pull the awning down and secure using one of the side
tie-down straps.
4. (Detail B) Slide the unused tie-down strap and the
center pull strap off the roller.
5. Slide the new center pull strap into the slot and
center on the rollbar.
6. Slide the tie-down strap into the slot of the rollbar.
The strap can be moved horizontally along the
rollbar to align with the existing strap catch.
7. Retract the awning to the vertical position.
I C
NSTALLING THE ASE
Lower Groove
End Cap
Stow Clip
C
Detail
8. (Detail C) Slide the stow clip into the lower groove of the case.
9. Install the end caps with the supplied screws.
10. Slide the clip to the area of the pull strap and secure using the # 6 setscrew.
11. Lift the case up to the top of the ladders or platforms used during assembly.
NOTE: The slot in the case is in the lower half of the case.
12. (Detail D) Thread the center pull strap through the slot and plastic bezel in the case. It will be necessary to squeeze the
rubber grommet at the end of the strap to get it through.
13. (Detail E) Lift the case up and press onto the arms. Center the case over the roller and
orient the case by aligning the existing mounting holes with the holes in the case.
14. Ream the mounting holes out to 7/32" then secure the case to the arms using two (2)
3/16" pop rivets on each end.
S S
TOWING THE TRAP
When the awning is open, the pull strap will hang down loosely. Use the pull cane and
press the pull strap grommet into the clip to keep the strap from flopping.
052509-001r1
O
MEGA

Models:

Purpose:

Summary of Work: This action consists of removing and replacing the case; and,
L
IST
Case
Pull Strap
II P
ULL
Omega II
The center pull strap has been improved to provide the user
improved accessibility.
removing and replacing the center pull strap.
Q C
TY OMPONENT
•
1
Clip, Strap
•
1
Set Screw
•
1
Screws
•
1
3/16" Pop Rivets
Case
A
Detail
Plastic
Bezel
Rubber
Grommet
D
Detail
1
S U
TRAP PGRADE
Slot
Center
Pull Strap
Detail
E
Detail
Clip
Pull Cane
C
AREFREE
K
IT
Q
TY
1
1
10
4
Outside
Tie Strap
B
OMEGA011
3/16"
Pop Rivet
OMEGA008
Pull Strap
Grommet
Omega013
March, 2005
