Summary of Contents for OTC OTC200
- Page 1 BEST QUALITY 100% GUARANTEED OTC200 INSTALATION MANUAL OTC Quality Products Model 866 558 3200 info@otcquality.com OTC200 www.otcquality.com...
- Page 2 4 1/2” 3 1/2” 2 1/16” Model OTC200 1 3/32” Rubber Washer Lock Nut M24X 1.5 Sensor Cable Faucet Hose Plug to Solenoid Valve 1 7/8” Tools Needed Plug to Battery or AC adapter 1/2” 14 2 13/16” www.otcquality.com...
- Page 3 OTC200 INSTALATION MANUAL Rubber washer Faucet Disc Rubber Washer Lock Nut Sealing Gasket Lock Nut Sensor Cable Sensor Cable Insert faucet shank through sink hole Place washer and locknut onto shank Tighten locknut Mark holes for valve and install on...
- Page 4 OTC200 INSTALATION MANUAL Mark holes for batteries Connect Faucet hose case holder and install on wall Insert the batteries case into case holder OPTIONAL: 110V AC power supply Align marks located on solenoid plug and push rmly. Power plug does not require alignment, Plug and push rmly.
- Page 5 OTC200 INSTALATION MANUAL Battery Replacement Use All New, good quality Note allignment AA batteries of marks Use Phillips screw Open the case and Place new batteries Close the case aligning driver to remove remove the old inside case in the order...
- Page 6 OTC200 INSTALATION MANUAL OPTIONAL EQUIPMENT OTC-210 OTC-215 ATV-3 Matching Electronic Wall Mount Electronic Automatic Toilet Valve Soap Dispenser Soap Dispenser AUV-3 A-12910 A-19000 Automatic Urinal valve Adjustable under sink AC Adapter mixing valve A-10400 A-10800 A-13000 Lavatory drain Grid Type with 4”...
