Introduction
Video Connection ................................................................................................................................ 2
Power Connection ............................................................................................................................... 2
Safety Earth Connection ..................................................................................................................... 2
Power LED .......................................................................................................................................... 2
Lock LED ............................................................................................................................................. 2
Mode 1 ................................................................................................................................................ 3
Mode 2 ................................................................................................................................................ 3
Dimensions .......................................................................................................................................... 3
Mounting Details .................................................................................................................................. 3
Video ................................................................................................................................................... 6
Environmental ..................................................................................................................................... 6
EMC..................................................................................................................................................... 6
without notice. The information herein is believed to be accurate. No
responsibility is assumed by AMG for its use.
Contents
AMG1321Video
Amplifier
AMG1321 Instruction Sheet D27018-03
2
2
2
3
3
3
4
4
5
6
Advertisement
Table of Contents
Summary of Contents for AMG Systems AMG1321
- Page 1 Product Specification Video ..............................6 Environmental ............................. 6 EMC..............................6 AMG Systems Ltd. reserves the right to make changes to this document Page 1 of 6 AMG1321 Instruction Sheet D27018-03 without notice. The information herein is believed to be accurate. No...
- Page 2 RG59 or other types of 75 ohm cable. It will produce a high a quality video output with no user interaction. The AMG1321 will equalize up to 1600metres of RG59 cable and compensate for high frequency cable losses of up to 60dB at 5MHz.
- Page 3 Amplifier will automatically calibrate its gain to output a high quality compensated video signal. It will maintain this setting, even if the video input connection is removed, until the AMG1321 is re- powered or the slide switch is changed to MODE 2 and back to MODE 1. Note the LOCK light will be illuminated blue when the unit is locked.
- Page 4 AMG1320 – 6 slot 1U 19” Rack Mounting Panel The AMG1320 6 slot 1U 19” Rack Mount Panel can accommodate up to 6 AMG1321 Amplifiers. See below for dimensions (cage nuts, screws and cup washers not provided). AMG Systems Ltd. reserves the right to make changes to this document...
- Page 5 AMG1325 – 16 Way 1U 19” Rack Mounting Power Unit The AMG1325 is a 16 Way 1U 19” Rack Mount Power Unit capable of powering up to 16 AMG1321 Amplifiers. Power Connection Input .............240V AC 50Hz Output Voltage ........+12 volt DC Output Current ........1.1Amp Max per port (PTC short circuit protection on each port)
- Page 6 -61dB (1000 metre) Environmental Dry Heat and Vibration......TR2130C:2002 Standard ..........EN50293:2012 AMG Systems Ltd. reserves the right to make changes to this document Page 6 of 6 AMG1321 Instruction Sheet D27018-03 without notice. The information herein is believed to be accurate. No...
