Summary of Contents for Wood-mizer KORNIK ES-1
- Page 1 User Guide Wood-Mizer ® Metal Detector KORNIK ES-1 Part number: MD-ES1 Wood-Mizer ®...
-
Page 2: Table Of Contents
Contents 1. Introduction........................2 2. Technical data.........................3 3. Description of the control panel..................4 4. Preparing the detector for operation................5 4.1. Initial settings....................5 5. Final remarks........................8 Wood-Mizer ®... -
Page 3: Introduction
(VLF). The change in amplitude-phase shift, after adequate processing, activates optic and acoustic alarms. The Wood-Mizer Kornik ES-1 detector has: automatic elimination of background radiation, gain control, volume control, RESET button –... -
Page 4: Technical Data
Detection level signalling Supply status signalling Reset button Dimensions: Height: min. 450 mm, max. 600 mm Diameter of the probe 200 mm Accessories: - Charger - User Guide Operation temperature: 5°C to +40°C Storage temperature: –20°C to +55°C Wood-Mizer ®... -
Page 5: Description Of The Control Panel
1. ON/OFF switch and volume control. 2. Battery status indicator. (If the detector is ready for operation, the LED glows green, and if the batteries must be charged, the LED glows red). 3. Detection level indicator. 4. Gain control potentiometer. 5. RESET button. Wood-Mizer ®... -
Page 6: Preparing The Detector For Operation
Second step – the handle should be gently extended. Third step – in order to lock the arm at the required position, the metal part of the arm with the handle should be turned clockwise, which will clamp the handle. Wood-Mizer ®... - Page 7 Gain Control to the turn the Gain Control close to middle position as shown the maximum position as shown above. above. 6. Position sensor in the air (far from any metal source). 7. Press the Reset button. Wood-Mizer ®...
- Page 8 8.Position the sensor at, or just below the surface of the log or cant to be measured (remember that the minimum distance from large metal objects- such as bed rails- is circa 250mm). 9. Turn the Gain Control down until the alarm stops. 10. Press the Reset button. Wood-Mizer ®...
-
Page 9: Final Remarks
In winter, when there is a difference of temperatures and when you take the device from a warm room into cold conditions, wait 15 minutes before switching the detector on. When bringing the detector in from a cold environment into warm conditions – wait one hour before switching on the detector. Wood-Mizer ®...
