6" 5.5 AMP CUT-OFF SAW
This product can expose you to chemicals including
LEAD/CADMIUM/DEHP, which is known to the State
of California to cause cancer and birth defects or
other reproductive harm. For more information go
to www.P65Warnings.ca.gov.
Please carefully read and save these instructions before attempting to assemble, maintain, install, or operate this product.
Observe all safety information to protect yourself and others. Failure to observe the instructions may result in property
damage and/or personal injury. Please keep instructions for future reference.
For warranty purchases, please keep your dated proof of purchase. File or attach to the manual for safe keeping.
For Customer Service, Call 1-800-348-5004
or e-mail customerservice@focus-ontools.com
WARNING
*Actual product may vary slightly
33015
11/2017
Advertisement
Table of Contents
Summary of Contents for Steel Core 33015
- Page 1 Observe all safety information to protect yourself and others. Failure to observe the instructions may result in property damage and/or personal injury. Please keep instructions for future reference. For warranty purchases, please keep your dated proof of purchase. File or attach to the manual for safe keeping. For Customer Service, Call 1-800-348-5004 33015 11/2017 or e-mail customerservice@focus-ontools.com...
-
Page 2: General Tool Safety Warnings
GENERAL TOOL SAFETY WARNINGS Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. 1. KEEP GUARDS IN PLACE and in working order. 2. - Page 3 13. DON’T OVERREACH. Keep proper footing and balance at all times. 14. MAINTAIN TOOLS WITH CARE. Keep tools sharp and clean for best and safest performance. Follow instructions for lubricating and changing accessories. 15. DISCONNECT TOOLS before servicing; when changing accessories, such as blades, bits, cutters, and the like.
-
Page 4: Cut-Off Saw Safety Warnings
6. Repair or replace damaged or worn cord immediately. 7. This tool is intended for use on a circuit that has an outlet that looks like the one illustrated above in 125 V~ 3-Prong Plug and Outlet. The tool has a grounding plug Grounding that looks like the plug illustrated above in 125 V~ 3-Prong Plug and Outlet. -
Page 5: Vibration Safety
14. Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury. -
Page 6: Specifications
SPECIFICATIONS Electrical Rating 120VAC / 60Hz / 5.5A Motor No Load Speed 5,000 RPM Max. Accessory Diameter 6" Arbor Size 7/8" FUNCTIONS Handle Safety Button Stationary (on other side Guard of handle) Trigger Swing Guard Angle Guide Vise Clamp Vise Knob Cut-Off Wheel (not included) - Page 7 TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION: Release the pressure and unplug the tool from its electrical outlet before assembling or making any adjustments to the tool. TO PREVENT SERIOUS INJURY: DO NOT OPERATE WITH ANY GUARD DISABLED, DAMAGED, OR REMOVED. INSTALLING A CUT-OFF (GRINDING) WHEEL 1.
-
Page 8: Using The Vise
7. Install the new Grinding Wheel onto the Spindle. Replace the Outer Flange onto the Spindle; thread the Arbor Bolt onto the Spindle and tighten them in place with the Sleeve Wrench. 8. For wheels with paper gaskets (blotters) or metal gaskets: Slip the grinding wheel onto the Arbor with the gasket first. -
Page 9: Maintenance And Servicing
GENERAL OPERATING INSTRUCTIONS CAUTION! Friction from cutting will heat both the Wheel and the workpiece. Be careful when handling the workpiece and do not overwork the Cut-Off Saw as the Wheel can become damaged from overheating. 1. Release the Safety Chain and guide the Housing to rest at its full upward position. 2. -
Page 10: Troubleshooting
CUT-OFF WHEEL STORAGE AND HANDLING 1. Handle Cut-Off Wheels carefully to prevent dropping or bumping. Do not use wheels that have been dropped or bumped. 2. Store Cut-Off Wheels in shelves, racks, boxes, or drawers. Storage area must be kept dry, and above freezing. -
Page 11: Parts List
PARTS LIST PARTS LIST REF# Description REF# Description QT'Y QT'Y M5 wing blot 5x14 Hexagonal screw side cover Ф5 spring washer Outer Flange Nut Terminal Inner Flange Ф5x12 s/t screw spring Ф5 spring washer sapport/base plate grinder cover Iron sheet output shaft machine foot 2.9x10 semi sirclekey... -
Page 12: Assembly Diagram
ASSEMBLY DIAGRAM customerservice@focus-ontools.com 1-800-348-5004...
