Securnet HSCN - Quick Start Guide – Router Cisco 927 4P LTE
Package Contents
•
1 x Cisco 927 router
•
1 x Router Power Supply and plug
•
1 x ADSL cable for router (lilac or
white)
•
1 x Microfilter (not required if socket
has integrated filter. Below shows
examples of integrated filter socket)
•
1 x
4G aerial connected left connector
when looking at ports.
4G aerial
connected left
connector
when looking
at ports.
Router power supply
Please connect to
dedicated socket
rather than extension.
© 2021 IQVIA Ltd. All rights reserved.
Testing Steps
1. Contact PSL Service Desk on +44 (0) 1257 235940 to assist with set up.
2. Ensure that the router is powered and 4G Aerial is securely connected to the left hand
side as you look at the back of the router.
3. Connect the ADSL cable to the ADSL port on the integrated filter faceplate or use filter
if the BT socket only has one phone connection. The other end connects to the
ADSL/VDSL port on the router.
4. Connect LAN cable from switch to the yellow labelled LAN ports on the router.
5. The router will take up to 10 minutes to obtain a session.
6. System LED (5), xDSL CD LED (10), xDSL DATA LED (13) and LAN port will be illuminated
green.
7. On the PC, check that the IP address assigned is within the subnet indicated in TPSAT
with the router by running "ipconfig" from the command prompt.
8. Test internet access and EPS.
9. In TPSAT service desk will refresh the router status. This will take up to 5 minutes to
complete. Service desk check RSSI level on the router.
10. Change MTU to 1300 on the machines at site.
11. If RSSI below -110 dB test fail over by disconnecting ADSL cable from router. Fail over
will take up to 5 minutes. Only EPS, ordering and remote support will work on 4G.
12. If -110 dB or limited service displayed in TPSAT router will need to be re-positioned to
attain a signal.
13. Reconnect ADSL cable and confirm that internet and ADSL are working using
broadband.
14. Place old router into box that new routers arrived in ready for return.
15.
LAN Switch for computers Netgear
Phone Socket (BT
NTE)
BT telephone socket
requiring micro
filter.
4G SIM card
slot for Micro
SIM.
ADSL cable
BT telephone socket
with integrated
filter
