Optiview EM Series Quick Start Manual

VR Embedded DVR series: EM, LT and PRO series
REMOTE CONTROL
The remote control interface is shown as in Figure 2-7.
Button Number
1
2
3
4
5
Name
Address
Multiple-window
0-9 number key
Record
Auxiliary key
Same Function from the DVR Front Panel
Press to input DVR serial number to enable user to
control DVR. DVR Serial number will be the DVR
address.
Multiple window
switch button as in the front
panel labeled as (MULT)
Input password, channel or switch channel. Shift is the
button to switch the input method.
Used to control record function
a. One-window monitor mode, click this button to
display assistant function: PTZ control and image
color.
b. Backspace function: in numeral control or text
control, press it for 1.5 seconds to delete the
previous character before the cursor.
c. In motion detection setup, working with Fn and
direction keys to configure settings.
d. In text mode, click it to switch between numeral,
English character(small/capitalized) and etc.
e. In HDD management interface, you can click it to
switch HDD record information and other
information
