University Sound MM2TC Specifications

SPECIFICATIONS
Frequency Response:
800-5,000 HZ f 5 dB
(see Figure 3)
Power Handling,
8 Hours, 6-dB Crest Factor:
25 watts (500-5,000 Hz pink noise)
Impedance:
16 ohms
Sound Pressure Level at 1 Meter, 1 Watt
Input Average, Pink Noise Band-Limited
from 800-5,000 Hz:
104 dB
Horizontal Beamwidth:
2 kHz (see Figure 2)
Vertical Beamwidth:
2 kHz (see Figure 2)
Directivity Factor R,
10.25 2 kHz
Usable Low-Frequency Limit:
600 Hz
Construction:
Rugged die-cast aluminum case and
transformer housing. Diaphragm is
phenolic impregnated linen-base. All metal
speaker parts are of anodized aluminum
with baked-on acrylic paint. A cable
entrance is provided on the bottom side
Voice-Coil Diameter:
5.1 cm (2.0 in.)
Magnet Weight:
0.93 kg (2.1 Ib) with plates
Magnet Material:
Alnico V
Dimensions,
Height:
25.4 cm (10.0 in.)
Width:
16.4 cm (6.4 in.)
Depth:
Net Weight:
4.0 kg (8.8 Ib)
Shipping Weight:
4.5 kg (10.0 Ib)
DESCRIPTION
The University Sound MM2TC is aconservatively rated 25-watt "submergence-proof'' speaker
designed for wall, ceiling, or bulkhead mounting.
The driver employs a diaphragm with a phenolic impregnated linen-base and 2.0-inch voice coil
with "W" shaped Alnico V magnet structure.
Provisions are made in the housing for installation of a matching transformer such as the
University Sound model 5030 (30 W).
The voice-coil/diaphragm assembly is protected by a special anit-fungicide treatment and is
easily accessible for cleaning by removal of the die-cast reflector on the front of the speaker.
The MM2TC is self-draining and designed to withstand fungus, dust, salt spray, live steam, and
gases. It is built to penetrate high noise levels in boiler rooms, mines, railroads, etc.
