  • Page 1 RP-1716DR2 | RP-1724DR RP-SW16P | RP-SW24P 16/24-Port 10/100Mbps Switch Quick Installation Guide V1.0...

  • Page 2: Before You Start

    Before You Start Package Contents 16/24-Port 10/100Mbps Switch Quick Installation Guide Power cord Rack Mount Kit If any of the contents are missing, please contact your dealer. Installation Requirements A computer with a network adapter installed Cat-5e or Cat-6 Network Cable The surface must support at least 1,5 Kg for the Switch.

  • Page 3: Hardware Installation

    Hardware Installation 1. Connect the AC Power Adapter to the 16/24-Port 10/100Mbps Switch then to a power outlet. 3. Connect a CAT-5e or CAT-6 RJ-45 network cable from the computer to an available Ethernet port of the 16/24-Port 10/100Mbps Switch Notice The cable distance between 16/24 port Switch and other IEEE802.3 compatible network device should not exceed 100 meter.

  • Page 4: Technical Specifications

    Storage – 5% to 90% RH Diagnostic LEDs Power, Link/ACT,100M Power Supply Internal universal switching power 100~240VAC, 50/60Hz 280 x 161 x 44 m (RP-1716DR2, RP-1724DR) Dimensions 440 x 200 x 44 m (RP-SW16P, RP-SW24P) Certification FCC Part 15 Class A, CE Hardware Troubleshooting This chapter contains information to help you solve problems.
  • Page 5 RP-1716DR2 | RP-1724DR RP-SW16P | RP-SW24P 16/24-Port 10/100Mbps Switch Guia de Instalação Rápida V1.0 P/N:41AR-171624DR-A00...

  • Page 6: Antes De Iniciar

    Antes de Iniciar Conteúdo da Embalagem 16/24-Port 10/100Mbps Switch Guia de Instalação Rápida Cabo de alimentação Suportes de Montagem com parafusos Se qualquer um dos conteúdos acima estiver faltando, favor contatar o seu revendedor. Requisitos Mínimos Computador com adaptador de rede instalado Cabo de rede Cat-5e ou Cat-6 Superfície deve suportar no mínimo 1,5 Kg A tomada elétrica deve estar a no máximo 1,82 metros (6 feet) do Switch.

  • Page 7: Instalação Do Hardware

    Instalação do Hardware 5. Conecte o Cabo de Alimentação ao 16/24-Port 10/100Mbps Switch então a uma tomada elétrica. 4. Conecte um cabo de rede RJ-45 CAT-5e ou CAT-6 do computador a uma porta Ethernet diisponível no 16/24-Port 10/100Mbps Switch Aviso A distância do cabo entre o interruptor de porta e outros 16/24 IEEE802.3 compatível dispositivo de rede não deve exceder 100 metros.

  • Page 8: Especificações Técnicas

    Armazenamento - 5% a 90% RH LEDs de Diagnóstico Power, Link/ACT,100M Adaptador Externo de Tensão Fonte interna universal 100~240VAC, 50/60Hz 280 x 161 x 44 m (RP-1716DR2, RP-1724DR) Dimensões 440 x 200 x 44 m (RP-SW16P, RP-SW24P) Certificação FCC Part 15 Class A, CE Solução de problemas de hardware...
