Odyssey STAR BLAZER LE-313 User Manual

USER GUIDE
OPERATING INSTRUCTIONS
This unit is ready to be used. Multi-colored beams will chase amongst each other to audio (bass) sounds in music via the internal
microphone. Make sure the effect is installed and operated in a well ventilated area with fan vents clear of obstacles. For the
ultimate effect, fog or haze must be used in order to see the colorful beams. Although the unit is fan cooled the duty cycle
must be applied.
CAUTION
The lens area will get hot during normal operation of unit. After operation allow sufficient time to cool down before handling
or moving the unit.
IMPORTANT!
Never open the unit when in use. Always disconnect the power cord from the power source when replacing lamps or servicing
the unit. Always replace fuse and /or lamp with the exact same type.
LAMP REPLACEMENT
Remove Lamp cover from the main body of the unit. Gently remove the old lamp, Then, using a clean cloth or glove, carefully
insert the new lamp into the ceramic socket. NEVER TOUCH A NEW LAMP WITH YOUR BARE HANDS or FINGERS (oil and dirt
on your skin will damage the bulb).
TROUBLESHOOTING
1. If the effect does not turn on
WARNING
CAUTION:
UNPLUG UNIT
To avoid electrical shock unplug
unit before servicing!
For Lamp Replacement:
Only use exact same voltage &
lamp type
For service contact your local authorized ODYSSEY dealer or call 626.334.0800
www.ODYSSEYGEAR.com
page 1
Thank you for choosing Odyssey Lighting. These lighting effect
features have preinstalled lamps and are ready to be used.
IMPORTANT!
Please read this User Guide before attempting to operate unit.
a) try plugging into an outlet you know is working.
b) check fuse & make sure it is not blown
IMPORTANT IMPORTANT
DUTY CYCLE
fingers. Oil from your fingers will
This device must be operated
on a duty cycle.
Failure to comply may result in
extreme damage to unit and
may void warranty.
STAR BLAZER
NEVER TOUCH
any Halogen Lamp with bare
shorten lamp life. Never move
fixture until lamp has enough
time to cool. Lamps are not
covered under warranty.
LE-313
Specifications
Beam Spread: Medium
Lenses: 1 per unit
Beams: Multi
Bulb: 1 per unit
Lamp: 12V 100W (FCR)
Color: Multi
Sound Active: Yes
Fuse: 3 Amp
Power: 120V
Remote Switch: Green LED "on"=
sound active,
LED "off"= black out
Duty Cycle: Continuous
Warranty: 90 Days
Width: 10.5"
Height: 7.5"
Depth: 10"
Package Weight: 18 lbs.
STAR BLAZER System 1- Master Fixture, 3-Slave Fixture,
3-XLR Data cable & 1-Remote Switch
