LCD Monitor User Manual
D2269V
/D2369V
/D2369V/D2769V
W
H
H
LED Backlight
www.aoc.com
©2012 AOC.All Rights Reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D2269V and is the answer not in the manual?

Questions and answers

Related Manuals for AOS D2269V

Summary of Contents for AOS D2269V

  • Page 1 LCD Monitor User Manual D2269V /D2369V /D2369V/D2769V LED Backlight www.aoc.com ©2012 AOC.All Rights Reserved.

  • Page 2: Table Of Contents

    Safety ..................................3 National Conventions ............................3 Power ................................4 Installation ................................5 Cleaning ................................6 Other .................................. 7 Setup ..................................8 Contents in Box ..............................8 Setup Stand & Base ............................9 Adjusting Viewing Angle ........................... 10 Connecting the Monitor ............................ 11 Adjustin ................................

  • Page 3: Safety

    Safety National Conventions The following subsections describe notational conventions used in this document Notes, Cautions, and Warnings Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in italic type. These blocks are notes, cautions, and warnings, and they are used as follows: NOTE: A NOTE indicates important information that helps you make better use of your computer system.

  • Page 4: Power

    Power The monitor should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company. The monitor is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin. This plug will fit only into a grounded power outlet as a safety feature.

  • Page 5: Installation

    Installation Do not place the monitor on an unstable cart, stand, tripod, bracket, or table. If the monitor falls, it can injure a person and cause serious damage to this product. Use only a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with this product.

  • Page 6: Cleaning

    Cleaning Clean the cabinet regularly with cloth. You can use soft-detergent to wipe out the stain, instead of strong-detergent which will cauterize the product cabinet. When cleaning, make sure no detergent is leaked into the product. The cleaning cloth should not be too rough as it will scratch the screen surface.

  • Page 7: Other

    Other If the product is emitting a strange smell, sound or smoke, disconnect the power plug IMMEDIATELY and contact a Service Center. Make sure that the ventilating openings are not blocked by a table or curtain. Do not engage the LCD monitor in severe vibration or high impact conditions during operation. Do not knock or drop the monitor during operation or transportation.

  • Page 8: Setup

    Setup Contents in Box Monitor Base 3D Glasses CD Manual Analog Cable Cable Audio Cable Power Cable HDMI Cable Not all signal cables (VGA and HDMI cables) will be provided for all countries and regions. Please check with the local dealer or AOC branch office for confirmation.

  • Page 9: Setup Stand & Base

    Setup Stand & Base Please setup or remove the base following the steps as below. Setup: Remove:...

  • Page 10: Adjusting Viewing Angle

    Adjusting Viewing Angle For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor's angle to your own preference. Hold the stand so you will not topple the monitor when you change the monitor's angle. You are able to adjust the monitor's angle from - 3.5°...

  • Page 11: Connecting The Monitor

    Connecting the Monitor Cable Connections In Back of Monitor and Computer : D2369V /D2769V Pow e r Earphone Audio port D-Sub port HDMI1 port HDMI2 port To protect equipment, always turn off the PC and LCD monitor before connecting. Connect the power cable to the AC port on the back of the monitor. Connect one end of the 15-pin D-Sub/HDMI port to the back of the monitor and connect the other end to the computer's D-Sub/HDMI port.
  • Page 12 Connecting the Monitor Cable Connections In Back of Monitor and Computer : D2369V/D2269V Pow e r D-Sub port DVI port To protect equipment, always turn off the PC and LCD monitor before connecting. Connect the power cable to the AC port on the back of the monitor.
  • Page 13 Wall Mounting Preparing to Install An Optional Wall Mounting Arm. This monitor can be attached to a wall mounting arm you purchase separately. Disconnect power before this procedure. Follow these steps: Remove the base. Follow the manufacturer's instructions to assemble the wall mounting arm. Place the wall mounting arm onto the back of the monitor.

  • Page 14: Adjustin

    Adjusting Setting Optimal Resolution Windows 8 For Windows 8: Right click and click All apps at the bottom-right of the screen. Click “Control Panel". Set the “view by” to “Category”. Click Appearance and Personalization.  ...
  • Page 15 Click DISPLAY. Set the resolution SLIDE-BAR to 1920x1080 or 2560x1080.

  • Page 16: Windows Vista

    Windows Vista For Windows Vista: 1 Click START. 2 Click CONTROL PANEL. 3 Click Appearance and Personalization. 4 Click Personalization...
  • Page 17 5 Click Display Settings. 6 Set the resolution SLIDE-BAR to Optimal preset resolution .

  • Page 18: Windows Xp

    Windows XP For Windows XP: 1 Click START. 2 Click SETTINGS. 3 Click CONTROL PANEL. 4 Click Appearance and Themes. 5 Double click DISPLAY.

  • Page 19: Windows Me/2000

    6 Click SETTINGS. Optimal preset resolution 7 Set the resolution SLIDE-BAR to Windows ME/2000 For Windows ME/2000: 1 Click START. 2 Click SETTINGS. 3 Click CONTROL PANEL. 4 Double click DISPLAY. 5 Click SETTINGS. 6 Set the resolution SLIDE-BAR to Optimal preset resolution...

  • Page 20: Hotkeys

    Hotkeys D2369V /D2769V D2369V/D2269V Source/Auto/Exit Source/Auto/Exit 2D/3D /< 2D/3D /< 4:3 or wide / > Volume/ > Menu/Enter Menu/Enter Power Power Menu/Enter Press to display the OSD or confirm the selection. Power Press the Power button to turn on/off the monitor.

  • Page 21: Osd Setting

    OSD Setting Basic and simple instruction on the control keys.       Press the MENU-button to activate the OSD window. Press or to navigate through the functions. Once the desired function is highlighted, press the < > MENU-button to activate it . press or to navigate through the sub-menu functions.

  • Page 22: Luminanc

    Luminance MENU Press (Menu) to display menu.   MENU Press to select (Luminance), and press to enter. < >   MENU Press to select submenu, and press to enter. > <...
  • Page 23 Press to adjust. >   < AUTO Press to exit D2369V /D2769V Brightness 0-100 Backlight Adjustment Contrast 0-100 Contrast from Digital-register. Standard Standard Mode Text Text Mode Internet Internet Mode Eco mode Game Game Mode Movie Movie Mode Sports Sports Mode Gamma1 Adjust to Gamma 1 Gamma...
  • Page 24 D2369V/D2269V Brightness 0-100 Backlight Adjustment Contrast 0-100 Contrast from Digital-register. Standard Standard Mode Text Text Mode Internet Internet Mode Eco mode Game Game Mode Movie Movie Mode Sports Sports Mode Gamma1 Adjust to Gamma 1 Gamma Gamma2 Adjust to Gamma 2...

  • Page 25: Image Setup

    Image Setup MENU Press (Menu) to display menu. MENU Press to select (Image Setup), and press to enter. < >   MENU Press to select submenu, and press to enter. >  <...
  • Page 26 Press to adjust. >   < AUTO Press to exit Clock 0-100 Adjust Picture Clock to reduce Vertical - Line noise. Phase 0-100 Adjust Picture Phase to reduce Horizontal - Line noise Sharpness 0-100 Adjust picture sharpness H.Position 0-100 Adjust the horizontal position of the picture. V.Position 0-100 Adjust the vertical position of the picture.

  • Page 27: Color Setup

    Color Setup MENU Press (Menu) to display menu. MENU Press to select (Color Setup), and press to enter. < >   MENU Press to select submenu, and press to enter. < >  ...
  • Page 28 Press to adjust. < >   AUTO Press to exit Warm Recall Warm Color Temperature from EEPROM. Normal Recall Normal Color Temperature from EEPROM. Cool Recall Cool Color Temperature from EEPROM. Color setup. sRGB Recall SRGB Color Temperature from EEPROM. Red Gain from Digital-register User Green...

  • Page 29: Picture Boost

    Picture Boost MENU Press (Menu) to display menu. MENU Press to select (Picture Boost), and press to enter. >   < MENU Press to select submenu, and press to enter. < >  ...
  • Page 30 Press to adjust. < >   AUTO Press to exit Frame Size 14-100 Adjust Frame Size Brightness 0-100 Adjust Frame Brightness Contrast 0-100 Adjust Frame Contrast H. position 0-100 Adjust Frame horizontal Position V.position 0-100 Adjust Frame vertical Position Bright Frame on or off Disable or Enable Bright Frame...

  • Page 31: Osd Setup

    OSD Setup MENU Press (Menu) to display menu. MENU Press to select (OSD Setup), and press to enter. < >   MENU Press to select submenu, and press to enter. < >  ...
  • Page 32 Press to adjust. < >   AUTO Press to exit H.Position 0-100 Adjust the horizontal position of OSD V.Position 0-100 Adjust the vertical position of OSD Timeout 5-120 Adjust the OSD Timeout Transparence 0-100 Adjust the transparence of OSD Language Select the OSD language Break reminder if the user continuously work for more Break Reminder...

  • Page 33: Extra

    Extra MENU Press (Menu) to display menu. MENU Press to select (Extra), and press to enter. < > MENU Press to select submenu, and press to enter. < >  ...
  • Page 34 Reset the menu to default Off Timer 0~24hours Select timing to turn off the monitor. Show the information of the main image and Information sub-image source D2369V/D2269V Auto Select to Auto Detect input signal Input Select D-SUB Select Signal Source as Input...
  • Page 35 2D/3D mode : Press the Menu key to enter the OSD menu and select the 2D/3D /DVI input menu. 2D, 2D-3D,3D (SBS), 3D(T/B) modes are available for switchover. When select 2D, 3D SBS), 3D(T/B) mode, the Stereo Index, Convergence and Scene icon in sub tier menu is disable and grey.
  • Page 36 HDMI input mode under 2D: Press the Menu key to enter the OSD menu and select the 2D/3D menu. When select 2D-3D mode, the Stereo Index, Convergence and Scene icon in 3D sub tier menu is able to adjust. . HDMI input mode un r 3D: Press th e Menu key to enter the OSD menu and select Only Auto(3D) is able to select, 2D-3D, 3D（SBS),3D(T/B) mode is the 2D/3D/ menu.

  • Page 37: Exit

    Exit MENU Press (Menu) to display menu. AUTO MENU to exit Press to select (Exit), and press   < > Exit Exit the main OSD...

  • Page 38: Led Indicator

    LED Indicator Status LED Color Full Power Mode Green Active-off Mode Orange...

  • Page 39: Driver

    Driver Monitor Driver Windows 8 Start Windows® 8 Right click and click All apps at the bottom-right of the screen. Click on “Control Panel”. Set the “View by” to “Large icons” or “Small icons”.
  • Page 40 Click on the “Display” icon. Click on the “Change display settings” button. “ Click the Advanced Settings” button. button. Click the “Monitor” tab and then click the “Properties”...
  • Page 41 Click the “Driver” tab. 10. Open the "Update Driver Software-Generic PnP Monitor" window by clicking on “Update Driver... “ and then click the "Browse my computer for driver software" button. 11. Select "Let me pick from a list of device drivers on my computer".
  • Page 42 12. Click the “Have Disk” button. Click on the “Browse” button and navigate to the following directory: X:\Driver\module name (where X is the drive letter designator for the CD-ROM drive). 13. Select the "xxx.inf" file and click the “Open” button. Click the “OK” button. 14.

  • Page 43: Windows 7

    Windows 7 Start Windows® 7 Click on the 'Start' button and then click on 'Control Panel'. Click on the “Display” icon. Click on the “Change display settings” button. “ Click the Advanced Settings” button.
  • Page 44 button. Click the “Monitor” tab and then click the “Properties” Click the “Driver” tab. Open the "Update Driver Software-Generic PnP Monitor" window by clicking on “Update Driver... “ and then click the "Browse my computer for driver software" button.
  • Page 45 Select "Let me pick from a list of device drivers on my computer". 10. Click the “Have Disk” button. Click on the “Browse” button and navigate to the following directory: X:\Driver\module name (where X is the drive letter designator for the CD-ROM drive). 11.

  • Page 46: Windows Xp

    Windows XP 1. Start Windows® XP 2. Click on the 'Start' button and then click on 'Control Panel'. 3. Select and click on the category ‘Appearance and Themes’ 4. Click on the 'Display' Item.
  • Page 47 5. Select the 'Settings' tab then click on the 'Advanced' button. 6. Select 'Monitor' tab - If the 'Properties' button is inactive, it means your monitor is properly configured. Please stop installation. - If the 'Properties' button is active, click on 'Properties' button. Please follow the steps below.
  • Page 48 8. Select the 'Install from a list or specific location [advanced]' radio button and then click on the 'Next' button. 9. Select the 'Don't Search. I will choose the driver to install' radio button. Then click on the 'Next' button. 10.

  • Page 49: Windows 2000

    Windows 2000 Start Windows® 2000 Click on the 'Start' button, point to 'Settings', and then click on 'Control Panel'. Double click on the 'Display' Icon. Select the 'Settings' tab then click on 'Advanced...'. Select 'Monitor' - If the 'Properties' button is inactive, it means your monitor is properly configured. Please stop installation. - If the 'Properties' button is active.

  • Page 50: I-Menu

    i-Menu Welcome to “i-Menu” software by AOC. i-Menu makes it easy to adjust your monitor display setting by using on screen menus instead of the OSD button on the monitor. To complete installation, please follow the installation guide.

  • Page 51: E-Saver

    e-Saver Welcome to use AOC e-Saver monitor power management software! The AOC e-Saver features Smart Shutdown functions for your monitors, allows your monitor to timely shutdown when PC unit is at any status (On, Off, Sleep or Screen Saver); the actual shutdown time depends on your preferences (see example below). Please click on "driver/e-Saver/setup.exe"...

  • Page 52: Screen

    Screen+ Welcome to "Screen+" software by AOC, Screen+ software is a desktop screen splitting tool, it splits the desktop into different panes, each pane displays a different window. You only need to drag the window to a corresponding pane, when you want to access it. It supports multiple monitor display to make your task easier. Please follow the installation software to install it.

  • Page 53: Troubleshoot

    Troubleshoot Problem & Question Possible Solutions Make sure the power button is ON and the Power Cord is properly connected Power LED Is Not ON to a grounded power outlet and to the monitor. Is the power cord connected properly? Check the power cord connection and power supply.
  • Page 54 3D Troubleshooting for D2369V Ghost images that appear when viewing 3D effects may be a result of the following: 1. the display unit has not been adjusted to its optimum resolutio n o f 1920* 1080 a t 60HZ ; if a customer complains that they are unable to locate the resolution-1920*1080, a non-standard VGA cable is possibly being used (clock and data cables have been cancelled and as a result, EDID/DDC displayed can not be read), or the graphics adapter driver is abnormal.
  • Page 55 Precautions when viewing 3D videos View 3D videos within an effective viewing distance and viewing angle. 3D effects may not be available beyond the effective viewing distance and viewing angle. For the sake of your health , do not watch 3D videos or video game screens for a long time , otherwise you may develop eye strain.

  • Page 56: Specification

    Specification General Specification D2269V Model name D2269V Driving system TFT Color LCD Viewable Image Size 546.20mm Diagonal Pixel pitch 0.08265*RGB(H)mm x 0.24795 (V)mm Panel Video R, G, B Analog lnterface ,DVI Separate Sync. H/V TTL Display Color 16.7M Colors Dot Clock...
  • Page 57 D2369V Model name D2369V Driving system TFT Color LCD Viewable Image Size 584.20mm Diagonal Pixel pitch 0.0884*RGB(H)mm x 0.2652 (V)mm Panel Video R, G, B Analog lnterface ,HDMI Separate Sync. H/V TTL Display Color 16.7M Colors Dot Clock 170MHz Horizontal scan range 30kHz to 83kHz Horizontal scan Size(Maximum) 509.18mm...
  • Page 58 D2369V Model name D2369V Driving system TFT Color LCD Viewable Image Size 584.20mm Diagonal Pixel pitch 0.0884*RGB(H)mm x 0.2652 (V)mm Panel Video R, G, B Analog lnterface ,DVI Separate Sync. H/V TTL Display Color 16.7M Colors Dot Clock 170MHz Horizontal scan range 30kHz to 83kHz Horizontal scan Size(Maximum) 509.18mm...
  • Page 59 D2769V Model name D2769V Driving system TFT Color LCD Viewable Image Size 686mm Diagonal Pixel pitch 0.1038*RGB(H)mm x 0.3114 (V)mm Panel Video R, G, B Analog lnterface ,HDMI Separate Sync. H/V TTL Display Color 16.7M Colors Dot Clock 170MHz Horizontal scan range 30kHz to 83kHz Horizontal scan Size(Maximum) 597.888mm...

  • Page 60: Preset Display Modes

    Preset Display Modes HORIZONTAL VERTICAL Resolution STAND FREQUENCY(kHz) FREQUENCY(Hz) 640x480@60Hz 31.469 59.940 640x480@72Hz 37.861 72.809 640x480@75Hz 37.500 75.00 800x600@56Hz 35.156 56.250 800x600@60Hz 37.879 60.317 SVGA 800x600@72Hz 48.077 72.188 800x600@75Hz 46.875 75.000 1024x768@60Hz 48.363 60.004 1024x768@70Hz 56.476 70.069 1024x768@75Hz 60.023 75.029 1280x1024@60Hz 63.981 60.020...

  • Page 61: Pin Assignments

    Preset table for the HDMI 3D mode 3D Format Resolution Refresh Rate Frame Packing 1080p 24Hz Frame Packing 720p 50/60Hz Side-by-Side(Half) 1080p 50/60Hz Side-by-Side(Half) 1080i 50/60Hz 720 p Side-by-Side(Half) 50/60Hz Top-and-Bottom 1080p 50/60Hz Top-and-Bottom 1080p 24Hz Top-and-Bottom 720p 50/60Hz 480p 60Hz Frame Packing 480p...
  • Page 62 Pin No. Signal Name Pin No. Signal Name Pin No. Signal Name TMDS Data 2+ TMDS Data 0 DDC/CEC Ground TMDS Data 2 Shield TMDS Clock + +5V Power TMDS Data 2 TMDS Clock Shield Hot Plug Detect TMDS Data 1+ TMDS Clock TMDS Data 1Shield TMDS Data 1...

  • Page 63: Plug And Play

    Plug and Play Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities.

  • Page 64: Regulation

    Regulation FCC Notice FCC Class B Radio Frequency Interference Statement WARNING: (FOR FCC CERTIFIED MODELS) NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 65: Weee Declaration

    WEEE Declaration Disposal of Waste Equipment by Users in Private Household in the European Union. This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste.Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment.The separate collection and recycling of your waste equipment at the time of disposal will help to conserve natural resources and ensure that it is recycled in a manner that protects human health and the environment.
  • Page 66 WEEE/E-Waste declaration for India This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste.Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment.The separate collection and recycling of your waste equipment at the time of disposal will help to conserve natural resources and ensure that it is recycled in a manner that protects human health and the environment.

  • Page 67: Service

    Service EU WARRANTY FOR AOC MONITORS LIMITED THREE-YEAR WARRANTY* For AOC LCD Monitors sold within Europe, AOC International (Europe) B.V. warrants this product to be free from defects in material and workmanship for a period of Three (3) years after the original date of consumer purchase.

  • Page 68: Warranty Statement For North & South America (Excluding Brazil)

    Warranty Statement for North & South America (excluding Brazil) WARRANTY STATEMENT for AOC Color Monitors Including those Sold within North America as Specified Envision Peripherals, Inc. warrants this product to be free from defects in material and workmanship for a period of three (3) years for parts &...
  • Page 69 ALL EXPRESS AND IMPLIED WARRANTIES FOR THIS PRODUCT (INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE) ARE LIMITED IN DURATION TO A PERIOD OF THREE (3) YEARS FOR PARTS AND LABOR AND ONE (1) YEAR FOR CRT TUBE OR LCD PANEL FROM THE ORIGINAL DATE OF CONSUMER PURCHASE.
  • Page 70 Only for AOC branded monitors sold within the continental United States. All AOC monitors are now covered by the EASE Program. If your monitor malfunctions at any time branded during the first three months, AOC will provide a replacement monitor within 72 hours after you are approved for our program.

  • Page 71: Congratulations

    Congratulations! This product is designed for both you and the planet! TCO Development works for sustainable IT - manufacture, use and recycling of IT products reflecting environmental, social and economic responsibility. TCO Certified is a third party verified program, where every product model is tested by an accredited impartial test laboratory.

This manual is also suitable for:

D2369vD2769v
